Cutter Installation Instructions
This PF8 Cutter Installation Instructions describes how to install a cutter
module in your PF8 printer. Your shipping contents include these items:
• One cutter module
•Twoscrews
• Two mounting brackets (one for the PF8d and another for the PF8t)
• These instructions
This kit must only be installed by an authorized service
technician. Intermec assumes no responsibility for personal
injury or damage if the installation is performed by an
unauthorized person.
Dieser Satz darf nur von einem autorisierten
Wartungstechniker installiert werden. Intermec übernimmt
keine Verantwortung für Verletzungen oder Sachschäden, falls
die Installation von nicht autorisiertem Personal durchgeführt
wird.
The discharge of electrostatic energy accumulated on the
human body, clothing, or other surfaces can damage or
destroy the printhead or electronic components used in these
printers. Avoid touching the electrical connectors when
installing the cutter module.
Die Entladung von elektrostatischer Energie, die im
menschlichen Körper, in Kleidungsstücken oder auf anderen
Oberflächen gespeichert ist, kann den Druckkopf oder
elektronische Komponenten dieser Drucker beschädigen oder
zerstören. Vermeiden Sie, die Steckverbinder nicht berühren.
Warnung
Installing the Cutter on the PF8d
1Disconnect power and place the printer on a flat surface.
2Open the top cover by pressing the cover open buttons on either side of
the top cover.
3Remove the front cover piece.
4Place the mounting bracket in the front cover space.
The electronics compartment contains high voltage
components. Always disconnect the power cord before
opening the electronics compartment.
Im Elektronikfach gibt es Komponenten, die hohe
Spannungen führen. Immer das Netzkabel abziehen, bevor
das Elektronikfach geöffnet wird.
Warnung
5Holding the mounting bracket in the slot, tip the printer up and tighten
the screws to attach the mounting bracket to the printer.
6Push the cutter electrical connector through the cable access hole.
7Put the cutter on the mounting bracket.
8Turn the printer over and tighten the screws to hold the cutter in place.
9Open the bottom case cover to access the main board of the printer.
Note: You can use a coin or a screwdriver to open the bottom case
cover.
10 Plug the electrical connector into the main board.
11 Close the bottom case cover. Your printer is now able to print on media
for cut-off operation. Refer to the PF8d/PF8t User’s Guide
(P/N 934-011-xxx) for instructions on loading media for cut-off
operation.
Note: There are two sockets on the main board, one is for the
stripper and the other is for the cutter. Check the pin
configuration of the socket before plugging in the connector.
Installing the Cutter on the PF8t
1Disconnect power and place the printer on a flat surface.
2Open the top cover by pressing the cover open buttons on either side of
the top cover.
3Press the green locking buttons and open the ribbon rewind mechanism.
4Push in the cover piece locks. Lift and remove the front cover piece.
5Attach the mounting bracket to the printer.
The electronics compartment contains high voltage
components. Always disconnect the power cord before
opening the electronics compartment.
Im Elektronikfach gibt es Komponenten, die hohe
Spannungen führen. Immer das Netzkabel abziehen, bevor
das Elektronikfach geöffnet wird.
Warnung
6Plug the cutter connector into the cutter socket.
7Put the cutter in the front cover space. First, insert the left side of the
cutter module and then the right side.
Note: There are two sockets on the board, one is for the stripper
and the other is for the cutter. Check the pin configuration of the
socket before plugging in the connector.
8Hold the cutter module in place and tighten the screws.
9Your printer is now able to print on media for cut-off operation. Refer to
the PF8d/PF8t User’s Guide for instructions on loading media for cut-off
operation.
PF8 Cutter Installation Instructions
*931-044-001*
P/N 931-044-001
Worldwide Headquarters
6001 36th Avenue West
Everett, Washington 98203
U.S.A.
tel 425.348.2600
fax 425.355.9551
www.intermec.com
©2007 Intermec Technologies
Corporation. All rights reserved.
