CYP CPRO-3D42S Manual de usuario

CPRO-3D42S

4 by 2 HDMI Switcher with HEAC

Operation Manual

DISCLAIMERS

The information in this manual has been carefully checked and

is believed to be accurate. Cypress Technology assumes no

responsibility for any infringements of patents or other rights of third

parties which may result from its use.

Cypress Technology assumes no responsibility for any inaccuracies

that may be contained in this document. Cypress also makes no

commitment to update or to keep current the information contained

in this document.

Cypress Technology reserves the right to make improvements to this

document and/or product at any time and without notice.

No part of this document may be reproduced, transmitted,

transcribed, stored in a retrieval system, or any of its part translated

into any language or computer le, in any form or by any means—

electronic, mechanical, magnetic, optical, chemical, manual, or

otherwise—without express written permission and consent from

Cypress Technology.

Version 1.1 August 2011

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or

operate this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts

inside the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU

if it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sufcient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE

VS1 09/02/12 First Release

VR2 06/03/12 CEC function on output 1 only

CONTENTS

1. Introduction............................................ 1

2. Applications........................................... 1

3. Package Contents ................................ 1

4. System Requirements............................ 1

5. Features.................................................. 2

6. Operation Controls and Functions....... 3

6.1 Front Panel ........................................3

6.2 Rear Panel.........................................4

6.3 Remote Control................................5

6.4 RS232 Protocol and Command......6

7. Connection Diagram ............................ 7

8. Specications ........................................ 8

9. Acronyms ............................................... 9

1. INTRODUCTION

This is a high performance HDMI™ Switcher with four HDMI inputs &

two outputs HDMI™ Switcher, the output ports support Audio Return

Channel (ARC) from a compaitble ARC TV and HDMI Ethernet

Channel (HEC) following the HDMI v1.4 specication.

The HDMI Switcher provides an S/PDIF link from the HDMI signal and

output through the ARC port to an AVR amplier to get audio from

the sink.

The HEC feature adds a network connection to the HDMI link 100 Mbps

Ethernet connection. Using an HDMI with HEAC cable allows for the

convenient integration of internet capable HEAC Televisions into the

end user’s home network system.

2. APPLICATIONS

• Simultaneously display a HDMI source on 2 TVs/displays

• Connect internet capable devices through HEC to network routers/

modems

• Connect network attached media streaming devices to

compatible HEAC TV

• Showroom displays

• Educational demonsrations

• Commercial usage

3. PACKAGE CONTENTS

• 4 × 2 HDMI Switcher with HEAC

• 5 V/2.6 A DC power supply adaptor

• Operation Manual

4. SYSTEM REQUIREMENTS

• Source equipment with HDMI output connector(s)

• Displays TV with HDMI HEAC input connector(s)

5. FEATURES

• Supports multiplexed HDMI 4-input and 2-output

• Two output ports supporting Ethernet Channel (HEC) and Audio

Return Channel (ARC) following the HDMI v1.4 specication

• HDMI v1.4 supports:

-Audio Return Channel (ARC)

-3D

- HDMI Ethernet Channel (HEC), enabling high-speed, bi-directional

networking at up to 100 Mb/sec

• Deep Color support 36/30/24-bit

• EDID optiions include Standard, TV or Lock EDID feature

• Supports CEC bypass on HDMI OUT 1

• Audio support:

-HDMI 1.4 compatible audio interface

-S/PDIF pass through

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

INPUT TVSTD LOCK POWEREDID

3D2CH 4321

BITSTREAM

LPCM 5.1/7.1

1 52 3 4

IR Remote Control Sensor

Audio/3D Content Indicator

The system will automatically detect incoming audio/video signal

type and the green LEDs will illuminate accordingly.

Input Selection

Press input button to select input source, the Blue LED will illuminate

accordingly. If none of the LEDs are illuminated then no input

has been selected, this is to allow the device to access the ARC

feature alone.

EDID Selection

The EDID control button selects

between using the EDID from the

display attached to Output 1/TV or

using the onboard EDID/STD (the

Green LED will illuminate accordingly).

When the EDID button is pressed for

longer then 3 seconds, the RED LED will

illuminate to indicate that the EDID is already locked to STD or TV

EDID as you selected accordingly. When EDID is set on STD audio

will support PCM 2CH, video modes supported are listed in the

table above.

Power Button

Press this button to switch on the device or press it again to set it to

standby mode.

8 10 12

RGB 

Y444   

Y422 

XvYCC   

6.2 Rear Panel

DC 5V

HDMI IN

RS-232

HDMI OUT

12 12 1234

ETHERNET

SPDIF/ARC

OUT

1 2 3 4

RS-232

This slot is to connect with a PC or control system with D-sub 9pin

cable for RS-232 control. For detail RS-232 commands please refer

to Section 6.4.

HDMI OUT 1~2/ARC 1~2/ETHERNET 1~2

HDMI/HEAC equipped TVs or displays will pass the Ethernet and

Audio signals via HDMI v1.4 cable back to the HDMI Output port,

the splitter will separate the Ethernet and audio, and will output

audio from the ARC and bi-directional data streams through the

Ethernet ports. If the display has a built-in tuner or an attached

DVD player, audio content can be sent “upstream” from the TV

back to the audio system to be output in multi-channel audio.

The HDMI Switcher can use the HDMI Ethernet Channel (HEC) to

consolidate video, audio and data streams into a single HDMI

cable connection to an Ethernet Hub/modem in order to access

the internet and also incorporates a dedicated data channel

into the HDMI link, enabling high-speed, bi-directional networking

at up to 100 Mb to control and search from the sink (please see

Section 6 for connection diagram). The HDMI output number is

correspondingto ARC and Ethernet output number.

Note 1: Be sure to connect devices with a suitable HDMI cable

designed to support the Ethernet Channel functionality, either the

standard HDMI cable with Ethernet or High Speed HDMI cable with

Ethernet.

Note 2: When the HDMI output has both Audio and ARC at the

same time the ARC will be the prioritized.

HDMI INPUT 1~4

Connect to HDMI or DVI sources equipment such as DVD player or

set-top-box for input video and audio sending.

Note A: This system was tested with 24 AWG cables. If using cables

of another specication, the performance of this system may vary.

Note B: Cable distance tested with a Sony PS3 and 40″ Samsung

LED UA40B700 12-bit LCD TV.

Note C: Figures provided in this manual are for reference only,

actual gures may vary depending on the source equipment

and display being used along with the type of cables and their

specications.

Power

Plug the DC 5 V power supply into the unit and connect the

adaptor to an AC wall outlet.

6.3 Remote Control

1Power button

Press to switch On the device, press it again to

set the device in standby mode.

2INPUT 1~4

Press the desire input button to select the input

source.

6.4 RS232 Protocol and Command

CPRO-3D42S

►

◄

Remote Control Console

PIN Denition PIN Denition

1 NC 1 NC

2Tx 2Rx

3Rx 3Tx

4 NC 4 NC

5 GND 5 GND

6 NC 6 NC

7 NC 7 NC

8 NC 8 NC

9 NC 9 NC

Baud Rate: 9600 bps

Data bit: 8-bits

Parity: None

Stop bit: 1-bit

Flow Control: None

Command Action

POWER 00 Power Off (standby)

POWER 01 Power On

PORT 11 Output Select Input 1

PORT 12 Output Select Input 2

PORT 13 Output Select Input 3

PORT 14 Output Select Input 4

PORT 00 No Input Selection (for ARC)
