CYP CLUX-21N Manual de usuario

CLUX-21N

HDMI 2 to 1 Switcher

Operation Manual

DISCLAIMERS

The information in this manual has been carefully checked and

is believed to be accurate. Cypress Technology assumes no

responsibility for any infringements of patents or other rights of third

parties which may result from its use.

Cypress Technology assumes no responsibility for any inaccuracies

that may be contained in this document. Cypress also makes no

commitment to update or to keep current the information contained

in this document.

Cypress Technology reserves the right to make improvements to this

document and/or product at any time and without notice.

No part of this document may be reproduced, transmitted,

transcribed, stored in a retrieval system, or any of its part translated

into any language or computer le, in any form or by any means—

electronic, mechanical, magnetic, optical, chemical, manual, or

otherwise—without express written permission and consent from

Cypress Technology.

Version 1.1 August 2011

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or

operate this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts

inside the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU

if it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sufcient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE

VS1 19/03/13 First Release

VR2 13/05/13 Auto Detection Behavior

CONTENTS

1. Introduction............................................ 1

2. Applications........................................... 1

3. Package Contents ................................ 1

4. System Requirements............................ 1

5. Features.................................................. 2

6. Operation Controls and Functions....... 3

6.1 Front Panel.........................................3

6.2 Rear Panel .........................................3

7. Connection Diagram ............................ 4

8. Specications ........................................ 5

1. INTRODUCTION

The HDMI 2 to 1 Switcher allows 2 HDMI sources to be connected to

the same HDMI TV/Monitor input. It has both automatic and manual

input selection and a 'last memory' function that remembers the

last input selection used. The EDID bypass function ensures the best

resolution. The switcher is also DVI compatible with the use of DVI to

HDMI adaptor.

2. APPLICATIONS

• Share a single TV/Monitor input between two source devices

• Add HDMI inputs to an AV Receiver

• Home entertainment

3. PACKAGE CONTENTS

• HDMI 2 to 1 Switcher

• 5 V/1 A Power Adaptor

• Operation Manual

4. SYSTEM REQUIREMENTS

Source equipment such as a Games Consoles, Blu-ray Player (or a PC/

Laptop with DVI cables or DVI to HDMI cables) and a monitor or TV

with HDMI cables.

5. FEATURES

• HDMI, HDCP 1.1 and DVI 1.0 compliant

• Supports 24/30/36-bit color depth display

• Supports High Denition audio – Dolby Digital TrueHD and DTS-HD

Master Audio

• Auto Signal Enhancement that improves signal quality for long

distance transmission

• Auto input detection with LED indicators

(When a new incoming source signal is connected, input selection

will automatically switch to that input port)

• Ideal for home theater integration

• EDID bypass

• Supports HDMI 3D signals

• Supports high resolution input:

- PC: VGA, SVGA, XGA, SXGA, UXGA (1600×1200) and 1920×1200

- HDTV: 480i, 480p, 576i, 576p, 720p@50/60, 1080i@50/60 and

1080p@24/50/60

• Easy to install and simple to operate

• Control via front panel buttons

• Last memory on power and input selection

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

INPUT POWER

2x1 HDMI Ver1.3 SWITCHER

1INPUT Button and LED

Press this button to switch between source 1 or 2. The LED will

illuminate to indicate the selected source.

2POWER Button

Press this button to switch on the device, press it again to switch

the device into standby mode.

6.2 Rear Panel

DC 5V

HDMI

OUT

HDMI 2

HDMI 1

132

1HDMI 1/2 IN

Connect to the HDMI source equipment such as a Blu-ray player or

a Set-top Box with HDMI cables or DVI to HDMI cables.

2HDMI OUT

Connect to an HDMI equipped TV/monitor or AV receiver for

display of the selected HDMI source signal.

3DC 5V

Connect the 5V DC power supply to the unit and plug the adaptor

into an AC outlet.

7. CONNECTION DIAGRAM

DC 5V

HDMI

OUT

HDMI 2

HDMI 1

HDMI

Input

HDMI

Output

TV/Monitor

Power

Supply

HDMI

Input

Set-top Box Blu-ray Player

8. SPECIFICATIONS

Video Bandwidth 225 MHz/6.75 Gbps

Input Ports 2×HDMI Female Ports (Type A Connector)

Output Port 1×HDMI Female Port (Type A Connector)

Power Supply 5 V/1 A DC (US/EU standards, CE/FCC/UL

certied)

ESD Protection Human body model:

±8 kV (air-gap discharge)

±4 kV (contact discharge)

Dimension 101 mm (W)×92 mm (D)×25 mm (H)

Weight 196 g

Chassis material Aluminum

Silkscreen Color Black

Operating Temperature 0 ˚C~40 ˚C/32 ˚F~104 ˚F

Storage Temperature −20 ˚C~60 ˚C/−4 ˚F ~ 140 ˚F

Relative Humidity 20~60 % RH (no condensation)

Power Consumption 3.1 W
