CYP EL-8100V Manual de usuario

EL-8100V

Advanced 4K Multi-Format to HDMI/HDBaseT Presentation

Switch (with HDMI, USB-C and VGA inputs)

OPERATION MANUAL

DISCLAIMERS

The information in this manual has been carefully checked and is

believed to be accurate. CYP (UK) Ltd assumes no responsibility for any

infringements of patents or other rights of third parties which may result

from its use.

CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be

contained in this document. CYP (UK) Ltd also makes no commitment to

update or to keep current the information contained in this document.

CYP (UK) Ltd reserves the right to make improvements to this document

and/or product at any time and without notice.

No part of this document may be reproduced, transmitted, transcribed,

stored in a retrieval system, or any of its part translated into any language

or computer file, in any form or by any means—electronic, mechanical,

magnetic, optical, chemical, manual, or otherwise—without express

written permission and consent from CYP (UK) Ltd.

Version 1.1

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or operate

this equipment and before connecting the power supply. Please keep the

following in mind as you unpack and install this equipment:

• Always follow basic safety precautions to reduce the risk of fire,

electrical shock and injury to persons.

• To prevent fire or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts inside

the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU if

it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sufficient space for air to circulate around the unit.

• Please completely disconnect the power when the unit is not in use

to avoid wasting electricity.

VERSION HISTORY

REV. DATE SUMMARY OF CHANGE

RDV1 2021/04/20 Preliminary release

CONTENTS

1. Introduction..................................................1

2. Applications ..................................................1

3. Package Contents ......................................... 2

4. System Requirements ..................................2

5. Features.........................................................3

6. Operation Controls and Functions ..............4

6.1 Front Panel.............................................................4

6.2 Rear Panel...............................................................5

6.3 Remote Control....................................................7

6.4 IR Cable Pinouts ...................................................8

6.5 RS-232 Pinout and Defaults.............................8

6.6 OSD Menu..............................................................9

6.7 WebGUI Control ................................................ 26

6.7.1 Status and Video Tab............................28

6.7.2 Audio and System Tab .........................32

6.8 Telnet Control..................................................... 37

6.9 Serial and Telnet Commands........................ 37

7. Connection Diagram ..................................63

8. Specications..............................................64

8.1 Technical Specifications ................................. 64

8.2 Video Specifications......................................... 66

8.3 Audio Specifications........................................ 68

8.3.1 Digital Audio ...........................................68

8.3.2 Analogue Audio.....................................69

9. Acronyms.....................................................72

1. INTRODUCTION

This 5 by 2 multi-format scaling switcher provides HDMI, USB-C,

HDBaseT, and VGA inputs which can be freely selected for output at a

scaled resolution of the user’s choosing over the mirrored HDMI and

HDBaseT outputs. The HDMI and USB-C ports support resolutions up

to 4K@60 (4:4:4, 8-bit) while the HDBaseT output supports automatic

colour subsampling of 4K50/60(4:4:4) sources to 4K50/60(4:2:0). The VGA

inputs support resolutions up to WUXGA. The HDBaseT output provides

a great solution to extend your audio and video up to 100 meters over a

single run of Cat.6A cable as well as providing PoH power to compatible

HDBaseT transmitters and receivers.

This unit also includes multiple analogue stereo audio inputs and a

microphone input (with support for optional 48V phantom power) along

with an analogue stereo output to provide a range of audio routing and

mixing flexibility. The included audio DSP engine also provides auto-

gain functionality, allowing for the mic source to be mixed with the audio

from one of the video sources while reducing the background audio level

in order to enhance the primary audio source. The ability to switch back

and forth between mixed and non-mixed audio greatly simplifies the

presentation experience.

A trigger input interface is also provided to allow the easy addition of a

remote control keypad, or other trigger-supporting products, which can

be installed within a podium or within a table in a conference room or

classroom. This interface can allow the user to activate functions with

the simple press of a button. Standard control is available via front panel

buttons with an OSD, WebGUI, Telnet, and RS-232 making it exceptionally

versatile.

2. APPLICATIONS

Analogue and digital source integration

Upscaling low resolution video for high-definition displays

Conference centers

Lecture halls

Schools and universities

3. PACKAGE CONTENTS

1× HDMI/USB-C/VGA to HDMI/HDBaseT Scaler

1× 24V/5A DC Power Adapter

1× Remote Control (CR-192)

1× IR Blaster Cable

1× IR Extender Cable

1× 3.5mm to 9-pin D-sub Male Cable

1× 6-pin Terminal Block

1× Shockproof Feet (Set of 4)

1× Operation Manual

4. SYSTEM REQUIREMENTS

HDMI/USB-C source equipment such as media players, video game

consoles, or set-top boxes.

VGA source equipment such as PCs, laptops, or set-top boxes.

HDMI receiving equipment such as an HDTV, monitor, or audio

amplifier.

Analogue audio receiving equipment such as headphones, an audio

amplifier, or powered speakers.

A compatible HDBaseT receiver with PoH support is recommended.

The use of Premium High Speed HDMI cables, and industry standard

Cat.6, Cat.6A, or Cat.7 Ethernet cable is highly recommended.

5. FEATURES

HDMI 2.0 and DVI 1.0 compliant

HDCP 1.x and 2.2 compliant

5 video inputs (2×HDMI, 1×USB-C, 2×VGA)

2 mirrored video outputs (1×HDMI, 1×HDBaseT)

Supports switching and scaling of all AV inputs for display over the

mirrored HDMI and HDBaseT outputs

Supports up to 4K UHD (18Gbps, 4K@50/60Hz 4:4:4, 8-bit) digital video

input (HDMI, USB-C) and output (HDMI)

VGA input supports resolutions up to 1080p60/WUXGA (RB)

HDBaseT output supports resolutions up to 4K@60Hz (4:2:0, 8-bit)

or 4K@30Hz (4:4:4, 8-bit). 4K@50/60Hz (4:4:4, 8-bit) output will be

automatically colour space converted to fit within the available

bandwidth

HDBaseT output extends video, audio, and data over a single

Cat.5e/6/7 cable and can reach distances up to 100m/328ft at 4K when

using Cat.6a/7

HDBaseT feature support: HD Video & Audio, 100BaseT Ethernet,

PoH(PSE), and Control (Bi-directional IR/RS-232 pass-through)

Supports pass-through of LPCM 2.0 digital audio

Supports embedding any analogue audio source with any video

source

Audio mixer function allows the mixing of audio from any LPCM 2.0

audio source with the microphone input with auto-gain functionality

Trigger input block supports direct input selection

IR remote control provides discrete input source selection

USB Type-C port provides up to 60W of power to connected devices

Provides PoH (PSE) from the HDBaseT output to power a connected

HDBaseT (PD) receiver (compatible receivers only)

Comprehensive EDID and HDCP management

Controllable via front panel controls with OSD, RS-232, Telnet, WebGUI,

and triggers

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

LOCK

ENTER

SELECT

HDMI

USB-CHDMI

VGA

VGA LOCK

EL-8100V

81 23 4 5 6 7

1POWER LED: This LED will illuminate to indicate the unit is on and

receiving power.

2IR Window: Accepts IR signals from the included IR remote for control

of this unit only.

3ENTER Button: Press to confirm a selection within the OSD or to go

deeper into a menu item.

4MENU Button: Press to enter the OSD menu, or to back out from

menu items.

5-/+ (MINUS/PLUS) Buttons: Press to move up and down or adjust

selections within OSD menus.

Note: Pressing “Menu” and “+” together will reset the output resolution

to XGA@60Hz (1024×768). Pressing “Menu” and “-” together will reset the

output resolution to 1080p@60Hz.

6SELECT Button: Press this button to sequentially switch through the

available inputs.

7LOCK Button: Press and hold for 3 seconds to lock all button functions

on the front panel. Press and hold for 3 seconds again to release the

lock function. The "LOCK" LED will be lit when the front panel is in the

locked state.

8Input & Status LEDs: These LEDs indicate the currently selected

source as well as the current front panel lock state.

6.2 Rear Panel

VGA 2VGA 1LINE INMIC INSERVICE IR OUTIR IN RS232

BYPASS RS-232

LINE OUT

CAT5e/6/7 OUTHDMI OUT

HDMI 2 INHDMI 1 IN

INPUT CONTROL

C12345

LAN

OFF

PHANTOM

VGA 2 INVGA 1 IN DC 24V

USB-C IN

AUDIO IN

3 4 5 6 7 8 9 10 11 12 14

1HDMI 1~2 IN Ports: Connect to HDMI source equipment such as

media players, game consoles, or set-top boxes. DVI sources are

supported with the use of an HDMI to DVI adapter.

USB-C IN Port: Connect to USB Type-C source equipment such as a PC

or laptop. Can provide up to 60W of power to the connected device.

Note: Not all devices with USB Type-C ports can support video output.

Please verify that the intended device supports video output from the USB

Type-C port before connecting it.

VGA 1~2 IN Ports: Connect to VGA source equipment such as a PC or

laptop. YUV sources, such as DVD players, are also supported with the

use of a 15-pin to 3-RCA adapter.

2HDMI OUT Port: Connect to an HDMI TV, monitor, or amplifier for

digital video and audio output.

CAT5e/6/7 OUT Port: Connect to a compatible HDBaseT receiver with

a single Cat.5e/6/7 cable for transmission of all data signals. PoH will

also be supplied to a connected compatible PD receiver.

3SERVICE Port: This slot is reserved for firmware update use only.

4LINE OUT Port: Connect to powered speakers or an amplifier for

stereo analogue audio output.

5MIC IN Port: Connect to a standard microphone using a 6.35mm plug.

Phantom power mics are supported.

6PHANTOM/OFF/ON Switch: Set the switch to“ON”for standard

condenser mics (5V) or “PHANTOM” for professional (48V) phantom

power mics. Set the switch to “OFF” for mics that don’t require

additional power.

Tabla de contenidos

Otros manuales de Cambiar de CYP

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
