CYP CP-290 Manual de usuario

CP-290

HD/PC/DVI/HDMI

to HDMI Scaler Box

Operation Manual

CP-290

Revision History

Version No Date Summary of Change

V1 20090106 Preliminary Release

Precautions

Failure to follow the precautions described below may cause damage to

PC/DVI to HDMI Scaler Box and void the warranty.

 DO NOT open the case. Doing so will void the warranty. If you ﬁnd

problem with it, please return back to your retailer or seller who will

assist you or provide you with solution.

 DO NOT use third-Party AC adapter or power cord. Doing so may

damage PC/DVI to HDMI Scaler Box.

 DO NOT bump, jar or drop contents of the products as it may

damage it and result in warranty void.

 DO NOT set any liquids or beverages on the drive as they may

damage PC/DVI to HDMI Scaler Box.

Table of Contents

1. Introduction…………………………………………………........……….

2. Applications..………………………………………………................….

3. Package Contents…………....…………………..............................…

4. System Requirements........……………………….…………........…….

5. Features…………………………………………….......……........………

6. Operation Controls and Functions…………………………………….

6.1 Front Panel ...............................................................................

6.2 Rear Panel ………………………………………….........….….…

7. Specications……………………………………………...........………..

8. Connection and Installation…………………………….........……..…

9. Supports Resolution………………………..……………...........…….…

1. Introduction

This Scaler Box is design to display your PC/HD images on the LCDTV

with better viewing image. It can upscale PC/DVI input sources to HDMI

output for wide-range PC/HD resolutions; PC/DVI/HD/HDMI Supports

XGA/UXGA/720p/1080p. This unit allows user to select a variety of output

resolutions/format, color space and adjust for the best picture quality.

Further, it also transfer sounds through HDMI for users to enjoy both HD images

and sounds consistently.

2. Applications

 Individual home use

 Classroom presentation

 Meeting demonstration

 Gaming entertainment playing

3. Package Contents

 HD/PC/DVI/HDMI to HDMI/DVI Scaler Box

 Power adaptor

 Operation Manual

4. System Requirements

 PC/DVD/Blue Ray and LCD TV/Monitor.

 D-SUB/ 3RCA to D-SUB, DVI/HDMI to DVI-D cable for linking source input &

image output to TV.

 Coaxial or audio phone jack cable for linking the digital or analog

audio sounds.

5. Features

 HDMI 1.3, HDCP 1.1 and DVI 1.0 compliant.

 Supports PC/HD resolution input: HDMI: 480p~1080p50/60

DVI : VGA~WUXGA

PC : VGA~WUXGA

HD : 480i~1080p50/60Hz

 Scale PC/HD/DVI/HDMI resolutions to XGA/UXGA/720p/1080p

resolutions.

 Supports PC/HD&DVI/HDMI to HDMI output.

 Transfer L/R and coaxial sounds to HDMI.

 Input and output selection bottons for quick and easy function

choose.

①DVI-D/HDMI: Connect the PC input DVI (29 pin) port to the DVI-D/HDMI

output port of your HDMI source equipment such like PC.

Resolution: VGA~ WUXGA ; 480p~1080p50/60

Note: DVI-D input can only take Digital signal.

HDMI input 12bit, output 8 bit only.

②PC/HD: Connect the PC input D-Sub (15-pin) port to the D-Sub output

port of your source equipment such like PC or a D-Sub to 3RCA to your

source equipment like DVD player.

PC Resolution: VGA~ WUXGA

Component Resolution: 480i~1080i, 1080P 50/60

③Power: Plug the 5VDC power supply into the unit and connect the

adaptor to AC wall outlet.

Note: Output timing 1080p 50Hz may not be supported by some TV with

input 576i/p@50, 720p50 and 1080i50.

6. Operation Controls and Functions

6.1 Front Panel

1 2 3

PC/HD

DC 5V

VIDEO IN

6.1 Rear Panel

①Coaxial: Connect the coaxial audio cable from source device.

②L/R: Connect the L/R phone jack from the source device.

③HDMI out: Connect the HDMI cable to LCD TV or Monitor.

④Audio: input audio switching button for selecting coaxial or L/R audio

signal. Simply push the button and the selection menu will display on the TV.

⑤Video: input video switching button for selecting DVI or PC/HD video

signal. Simply push the button and the selection menu will display on the TV.

⑥Output Timing: output resolution selectable on 720p / 1080p / XGA /

UXGA. Simply push the button and the selection menu will display on the

TV.

Note: A. Only when HDMI signal is send the selection of audio under HDMI

will appear on the display and the audio will Supports PCM2ch.

B. By pushing both Audio & Video buttons the output will switch to XGA.

C. By pushing both Audio & Timing buttons the output will switch to

720p.

COAXIAL

AUDIO VIDEO TIMING

L/R

AUDIO IN INPUT OUTPUTHDMI

OUT

2 3 4 5 6

Input ports 1 x PC

1 x DVI-D

1 x Coaxial/Audio

1 x L/R Audio

Output port 1 x HDMI

Power Supply 5V/1A DC (US/EU standards, CE/FCC/UL certiﬁed)

Dimensions (mm) 160(D) x 102(W) x 25(H)

Weight(g) 332

Chassis Material Aluminum

Silkscreen Color Silver

Operating Temperature 0°C ~ 40°C

Power Consumption 3.5w

7. Specications

8. Connection and Installation

PC MONITOR

DVD LCD TV

9. Supports Resolution

PC/HD

DVI/HDMI

Blu-Ray

DVI

HDMI

Note 1 : This scaler doesn't Supports 50/60Hz frame rate conversion; therefore

50Hz PC resolutions may not be compatible with all displays.

Note 2 : The timing of 1080p 50Hz output signal is very critical; therefore it may

not be compatible with all displays.

Input Output

Resolution Vertical Rate Resolution/Vertical Rate

VGA

60Hz

UXGA/60Hz

XGA/60Hz

720P/60Hz

1080P/60Hz

SVGA

XGA

SXGA

WXGA

UXGA

WSXGA

WUXGA

480i/480p

1080i

1080p

576i/576p

50Hz

UXGA/50Hz (note 1)

720p XGA/50Hz (note 1)

1080i 720P/50Hz

1080p 1080p/50Hz (note 2)

20090110 MPM-CP290

Home page: http://www.cypress.com.tw

CYPRESS TECHNOLOGY CO., LTD.
