OPERATION MANUAL

EL-42S

v1.3 HDMI 4 Way Switcher with

2 Identical Outputs

EL-42S_Manual-EN.indd 1 04/05/2011 16:23:33

Table of Contents

1. Introduction 1

2. Features 1

3. Package Contents 1

4. Operation Controls and Functions 2

4.1 Front Panel Diagram 2

4.2 Rear Panel Diagram 2-3

4.3 Remote Control 3

5. RS232 Pinouts 4

6. Commands Sets 4

7. Connection Diagram 5

8. Specications 5

EL-42S_Manual-EN.indd 2 04/05/2011 16:23:47

Page 1

1. Introduction

The IR Extender and the Repeater set is perfect for controlling IR controlled source

equipment over long distances. Up to ve sources can be controlled using this

extender set. Two sources can be controlled located locally to the repeater, whilst

the remaining three sources can be controlled locally to the extender, which can be

located up to 250m away via CAT5/6 cable. This system allows for the sources to be

controlled by their own original remote controls, from extended distances. A 5-eye

emitter accessory can be supplied for additional control of extra source equipment.

2. Features

• Supports ve outputs (two from the repeater, three from the extender).

• Control source equipment from a distance of up to 250 metres away, via CAT5/6

cable.

• Transmits infrared signals only.

• Allows the use of existing remote controls.

• IR Receiver’s frequency is at 20~60 kHz.

3. Package Contents

• Infrared Extender Box (CIR-03)

• Infrared Repeater Box (CIR-12)

• 1pc IR Eye Receiver cable (CIR-12)

• 5pcs IR Eye blaster cables (3pcs for CIR-03, 2pcs for CIR-12)

• 2pcs 5V DC power supply adaptors

• Operation Manual

EL-42S_Manual-EN.indd 1 04/05/2011 16:23:47

Page 2

4. Operation Controls and Functions

4.1 Front Panel

1. Remote control sensor.

2. HDMI input Select/Indicator: Press the “Input” button sequentially to switch to

your desired input (HDMI 1 to HDMI 4), the LED will illuminate to indicate which

input source is selected

3. POWER Switch/Indicator: Press the “POWER” button to turn on/o the power, the

power LED illuminate in red colour means the power is turned on, when the LED

not illuminate power is turned o.

4.2 Rear Panel

POWERINPUT

4321

SPLITTER

4x2

HDMI 1.3/2.25G

HDMI

1 3 2

RS-232

HDMI OUT HDMI OUT

2 1

HDMI IN

DC 5V

EL-42S_Manual-EN.indd 2 04/05/2011 16:23:48

Page 3

1. HDMI Outputs 1 and 2: Connect each of the output ports to the HDMI display.

When more than one output connected, the HDMI outputs play identical video

signal simultaneously.

2. RS232: 9-pin D-Sub connector for connecting to your PC or other control console

for remote control.

3. HDMI Inputs 1 to 4: Connect each of the input ports to the HDMI or DVI output of

your source equipment such as DVD player or set-top-box.

4. Power: Plug the 5V DC power supply into this unit and connect the adaptor to AC

wall outlet.

1. Power: Press the button to turn on/o the unit.

2. Direct input selector: Press 1, 2, 3 or 4 to select the desired input source.

4.3 Remote Control

CR-23

EL-42S_Manual-EN.indd 3 04/05/2011 16:23:49

Page 4

5. RS232 Pinouts

EL-42S Remote Control Console

PIN Denition PIN Denition

1 NC 1 NC

2 TxD 2 Rx

3 RxD 3 Tx

4 NC 4 NC

5 GND 5 GND

6 NC 6 NC

7 NC 7 NC

8 NC 8 NC

9 NC 9 NC

• EL-42S transmission format:

• Baud Rate: 9600 bps

• Data bit: 8 Bits Parity: None

• Stop Bit: 1 bit

6. Commands Sets

COMMAND

ACTION

“I” + “1” PORT 1 ON

“I” + “2” PORT 2 ON

“I” + “3” PORT 3 ON

“I” + “4” PORT 4 ON

“S” + “1” ENABLE SIGNAL ENHANCE

“S” + “0” DISABLE SIGNAL ENHANCE

“P” + “1” POWER ON

“P” + “0” POWER OFF

EL-42S_Manual-EN.indd 4 04/05/2011 16:23:49

Page 5

7. Connection Diagram

7. Specications

Frequency bandwidth 2.25Gbps (single link)

Input Ports 4 x HDMI female ports

HDCP Version v1.1

Output Port 2 x HDMI female ports

Remote Control Discrete IR remote

Power Supply 5V/2.6A DC (US/EU standards, CE/FCC/

UL certied)

Dimensions (mm) 240 (W) x 104 (D) x 50(H)

Chassis Colour Black

Chassis Material Aluminium

Operating Temperature Operating from 0°C ~ 48°C

Gross Weight (g) 820

Net. Weight (g) 600

EL-42S_Manual-EN.indd 5 04/05/2011 16:23:53
