CYP PU-8H8HBT Manual de usuario

PU-8H8HBT

HDBaseT™ 8×8 HDMI Matrix over CAT5e/6/7

OPERATION MANUAL

DISCLAIMERS

The information in this manual has been carefully checked and is

believed to be accurate. CYP (UK) Ltd assumes no responsibility for any

infringements of patents or other rights of third parties which may result

from its use.

CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be

contained in this document. CYP (UK) Ltd also makes no commitment to

update or to keep current the information contained in this document.

CYP (UK) Ltd reserves the right to make improvements to this document

and/or product at any time and without notice.

No part of this document may be reproduced, transmitted, transcribed,

stored in a retrieval system, or any of its part translated into any language

or computer le, in any form or by any means—electronic, mechanical,

magnetic, optical, chemical, manual, or otherwise—without express

written permission and consent from CYP (UK) Ltd.

Version 1.1 August 2011

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or operate

this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts inside

the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU if

it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sucient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE SUMMARY OF CHANGE

v1.01 23/11/12 Added IP feature, Corrected Diagrams

CONTENTS

1. Introduction ...........................................1

2. Applications ...........................................1

3. Package Contents ..................................1

4. System Requirements ...........................2

5. Features ..................................................2

6. Operation Controls and Functions .......3

6.1 Front Panel ................................................... 3

6.2 Rear Panel ..................................................... 4

6.3 Side Panel ..................................................... 5

6.4 Remote Control .......................................... 5

6.5 IR Cable Pin Assignment ......................... 6

6.6 RS-232 Pin Assignment............................ 7

6.7 RS-232 and Telnet Commands .............. 8

6.8 Telnet Control .............................................. 9

6.9 Web GUI Control ......................................11

7. Connection Diagram .......................... 13

8. Specications ...................................... 15

9. Acronyms ............................................. 16

1. INTRODUCTION

As the Flagship 8x8 HDBaseT™ Matrix, the PU-8H8HBT solution oers

complete HDBaseT™ convergence. Installers can switch and distribute

up to 8 HDMI sources, 2-Way IR, and PoE to lengths of up to 100m using

CAT5e/6 cable infrastructure. Control of the matrix is via IP, RS-232, IR

remote, or manual selection buttons.

This single box solution will enable an installer to condently integrate an

eight zone multi-room AV system. The PU-8H8HBT is designed to be used

with the PU-507-RX Receiver which can utilise the Power over Ethernet

(PoE) capabilities of the matrix.

2. APPLICATIONS

• Domestic HDMI Matrix System

• Video/TV wall display and control

• Security surveillance and control

• Commercial advertising, display and control

• University lecture hall, display and control

• Retail sales and demonstration

3. PACKAGE CONTENTS

• HDBaseT™ 8×8 HDMI Matrix over CAT5e/6/7

• 9×IR Extender

• 9×IR Blaster

• 2×24 V/6.25 A DC Power Adaptor (1 for PoE)

• 1×IR Remote Control

• Operation Manual

4. SYSTEM REQUIREMENTS

• HDMI equipped source devices, connect with HDMI cables or DVI

equipped source, connect with DVI to HDMI cables

• HDMI equipped displays (TVs or monitors) or HDMI equipped AV

receivers, connect with HDMI cables

• Industry standard CAT5e/6/7 cables

• HDBaseT™ Receivers (i.e. PU-506RX, PU-507RX or PU-1109RX)

5. FEATURES

• Supports all v1.3 HDMI resolutions

• Supports uncompressed video/audio up to 10.2Gbps

• Common supported resolutions: HDTV: 480p, 576p, 720p, 1080i,

1080p, 1080p24; PC: VGA, SVGA, XGA, WXGA, SXGA, UXGA, WUXGA.

• HDMI, HDCP and DVI complaint

• High Denition Audio supported: Dolby TrueHD, Dolby Digital Plus

and DTS-HD Master Audio plus LPCM (up to 192kHz)

• Uncompressed data transfer over single CAT cable (100m - CAT6; 80m -

CAT5e)

• Supports HDMI input up to 15m 1080p 8bit or 10m 1080p 12bit.

• Supports RS-232, 2-Way IR, Manual Selection Buttons, and HDMI CEC

control pass through

• Selectable EDID settings - TV (downstream) and STD (xed).

• Compact 2U Rack mount design

• Supports IP control

• Supports 3D signals

• Supports additional IR Control via a master (ALL) Input/Output..

Note:

1. The PoE function is designed for powering compatible receiver units

only—non-PoE receivers will need their own power supply. Receivers of

another brand may not be compatible.

2. Do not connect the LAN/CONTROL port to CAT outputs of this device.

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

POWER LOCK

MENU OUTA 1B2C3D4

E5F6G7H8

2 3 4 5 61

1 LCM : Displays the setting information of each input and output

setting.

2 POWER: Press this button to power the device on/o. The LED will

illuminate green when the power is on, red when it is in 'Standby'

mode.

3 LOCK: Press this button to lock all the buttons on the panel; press

again to unlock. The LED will illuminate green when locked.

4 IR: IR Receiver window (accepts the remote control signal of this

device only).

5 MENU: Press this button to access the LCM menu system, from here

EDID settings can be managed and IP system settings are displayed.

6 1~8/A~H and OUT/IN: Press the OUT or IN button to select the

output or input mode and then press the required number button to

make the selection accordingly.

For example, if outputs A~D need to be set to input 1 and outputs

E~H need to be set to input 2, then the following sequence of button

presses need to be performed:

Press: OUTABCDIN1MENU,

and then press: OUTEFGHIN2MENU.

Note: If the MENU button is not pressed the selection will not be changed.

6.2 Rear Panel

LAN

RS232

SERVICE

IR OUT

IR IN

IR OUT

IR IN

IR OUT

IR IN

ALL A B C D E F G H

CAT5e/6 OUT

IR OUT

IR IN

CAT5e/6 OUT

IR OUT

IR IN

CAT5e/6 OUT

IR OUT

IR IN

CAT5e/6 OUT

IR OUT

IR IN

CAT5e/6 OUT

IR OUT

IR IN

CAT5e/6 OUTCAT5e/6 OUT

IR OUT

IR IN

CAT5e/6 OUT

MAIN 24V

POE 24V

HDMI IN

V+

GND

V+

5 10 111 7

LAN: This port is the link for Telnet and Web GUI controls, connect to an

active Ethernet link with an RJ45 terminated cable (for further details,

please refer to sections 6.8 and 6.9).

Warning: Please do not connect this port directly to the PC/Laptop

as the Telnet function will not work.

RS-232: Connect to a PC or control system with D-Sub 9-pin cable for

the transmission of RS-232 commands.

3 ALL IR OUT: Connect to the IR blaster for IR signal transmission of the

source or display equipment. Place the IR blaster in direct line-of-sight

of the equipment to be controlled.

ALL IR IN: Connect to the IR extender for IR signal reception of the remote

control of this device or the source and display equipment. Ensure that

remote being used is within the direct line-of-sight of the IR extender.

5 SERVICE: Manufacturer use only.

IR OUT A~H: Connect to the IR blasters for IR signal transmission. Place

the IR blaster in direct line-of-sight of the equipment to be controlled.

7 CAT5e/6/7 OUT A~H: Connect from these CAT outputs to the CAT input

port of the receiver units with a single CAT5e/6/7 cable for HDMI Audio/

Video and IR control signal transmission.

HDMI IN 1~8: Connect to the HDMI input source devices such as a DVD

player or a Set-top Box with HDMI cable or DVI to HDMI cable.

IR IN 1~8: Connect to the IR extenders for IR signal reception. Ensure

that the remote being used is within the direct line-of-sight of the IR

extender.

DC 24V MAIN POWER: Plug the 24 V DC power supply into the unit and

connect the adaptor to an AC outlet.

PoE 24V: Plug the 24 V PoE power supply into the unit and connect the

adaptor to an AC outlet. This unit will mainly power PoE (Power over

Ethernet) capaable receiver units.

Warning: Please do not connect the CAT5e/6/7 cable into the

receiver's LAN port.

6.3 Side Panel

Fan Ventilator: These are air ventilation areas, DO NOT block these

areas or cover it with any object. Please allow adequate space around

the unit for air circulation.

6.4 Remote Control

POWER: Press this button to

switch on the device or set it to

standby mode.

IN: Input ports selection 1~8.

OUT: Output ports selection A~H.
