CYP CLUX-42S Manual de usuario

CLUX-42S

4x2 HDMI v1.3

Switcher

Operation Manual

CLUX-42S

TABLE OF CONTENTS

1. Introduction 1

2. Features 1

3. Operation Controls and Functions 2

3.1 Front Panel 2

3.2 Rear Panel 2

4. Remote Control 3

5. RS-232 Remote Control Protocol 3

5.1 RS-232 transmission format 3

5.2 RS-232 command 4

6. Specifications 4

7. Connection and Installation 5

8. Cypress HDMI v1.3 Series 6

1. Introduction

The is a high performance HDMI v1.3 Switcher with remote control. It allows your

various HDMI source to share two HDTV display. Simply pressing one button to

select your desired HDMI source for display on the HDTV.

Each product in this series is compatible to HDMI v1.3 specifications, a

cutting-age technology which defines the support to transfer Deep Color (10-bit

and 12-bit) video and new lossless compressed (Dolby TrueHD, Dolby Digital Plus

and DTS-HD Master Audio) digital audio, with a high bandwidth up to 225MHz.

2. Features

* HDMI 1.3, HDCP1.1 and DVI1.0 compliant Receiver.

* Deep color video up to 12bit, 1080p@60Hz.

* Four HDMI sources to connect up to two HDMI displays simultaneously.

* Supports DVI source and DVI display by using HDMI to/from DVI adaptor

cable.

* Dolby Digital, DTS digital audio transmission (32-192kHz Fs sample rate).

* Supports a wide range of PC and HDTV resolutions from VGA to UXGA and

480i to 1080p.

* HDMI cable distance test with 1080p resolution: Input/Output source can run

up to 30M/5.1CH.

* Full HDCP Compliant..

3. Operation Controls and Functions

3.1 Front Panel

1 Remote Control Sensor.

2 HDMI input Select/Indicator: Press the "Input" button sequentially to switch to

your desired input (HDMI 1 to HDMI 4), the LED will illuminate to indicate

which input source is selected

3 POWER Switch/Indicator: Press the "POWER" button to turn on/off the power,

the power LED illuminate in red color means the power is turned on, when

the LED not illuminate power is turned off.

3.2 Rear Panel

1 HDMI Outputs 1 and 2: Connect each of the output ports to the HDMI

display. When more than one output connected, the HDMI outputs play

identical video signal simultaneously.

2 RS232: 9-pin D-Sub connector for connecting to your PC or other control

console for remote control.

3 HDMI Inputs 1 to 4: Connect each of the input ports to the HDMI or DVI

output of your source equipment such as DVD player or set-top-box.

4 Power: Plug the 5V DC power supply into this unit and connect the adaptor

to AC wall outlet.

POWERINPUT

4321

SPLITTER

4x2

HDMI 1.3/2.25G

HDMI

1 2 3

RS-232

HDMI OUT HDMI OUT

2 1

HDMI IN

DC 5V

1 2 3 4

4. Remote Control

1 Power: Press the button to turn on/off the unit.

2 Direct input selector:

Press 1, 2, 3 or 4 to select the desired input source.

5. RS-232 Remote Control Protocol

The connection between splitter and remote controller with RS-232 modem cable.

ns definition of modem cable

5.1 RS-232 transmission format:

Baud Rate: 9600 bps

Data bit: 8 Bits

Parity: None

Stop Bit: 1 bit

Definition

TxD

RxD

GND

Definition

GND

Splitter Remote Controller



CR-23

5.1 RS-232 transmission format:

Frequency bandwidth

Input port

Output port

Power Supply

Remote Control

Dimensions (mm)

Weight(g)

Chassis Material

Silk Skin Color

Operating Temperature

2.25Gbps (single link)

4x HDMI female ports

2 x HDMI female ports

5VDC/2.6A (US/EU standards, CE/FCC/UL certified)

Discrete IR remote

240(W) x 104(D) x 44(H)

0.8 kgs

Metal

Black

Operating from 0°C ~ 48°C

6. Specifications

RS-232 command Operation

POWER 00

POWER 01

PORT 01

PORT 02

PORT 03

PORT 04

Select power OFF

Select power ON

Select port 1

Select port 2

Select port 3

Select port 4

STB

LCD TV

DVD 1 DVD 3

DVD 2

7. Connection and Installation

Home page: http://www.cypress.com.tw

CYPRESS TECHNOLOGY CO., LTD. 2007.7.9 MPM-CLUX42

8. Cypress HDMI v1.3 Series:

Product Description

CLUX-11S 1x1 HDMI V1.3 Repeater

CLUX-12S 1x2 HDMI V1.3 Splitter

CLUX-14S 1x4 HDMI V1.3 Splitter

CLUX-18S 1x8 HDMI V1.3 Splitter

CLUX-21SY 2x1 HDMI V1.3 Switcher

CLUX-31S 3x1 HDMI V1.3 Switcher

CLUX-31SY 3x1 HDMI V1.3 Switcher

CLUX-41SY 4x1 HDMI V1.3 Switcher

CLUX-41AT 4x1 HDMI V1.3 Switcher with Digital Audio

CLUX-42S 4x2 HDMI V1.3 Switcher

CLUX-110S 1x10 HDMI V1.3 Splitter

CLUX-210S 2x10 HDMI V1.3 Splitter

CLUX-210T 2x10 HDMI V1.3 Splitter with Digital Audio
