Smart Cabling & Transmission Corp. V1.0

V1.0

HDMI Extender Series

User Manual

Model : HE01F-4K

Compact 4K HDMI Fiber Extender

User Manual

HE01F-4K

Introduction

HE01F-4K is an HDMI extender that uses a single fiber optic cable with LC connections to transmit

uncompressed 4K 30Hz HDMI signals, with EDID and HDCP signals supported for both multi-mode and

single-mode fibers. This small compact size allows you to easily finish installation for any audiovisual

applications.

Features

Resolution up to 4K@30Hz.

Transmission distance up to 1KM over single-mode fibers, 300m over multi-mode fibers.

Built-in LC Fiber Connector.

Supports EDID bypass.

Low latency.

Plug & Play, USB powered.

Installation view

Transmission Distance

Fiber Module

Max. Distance

Multi-mode

300 M

Single-mode

1 KM

User Manual

HE01F-4K

Panel view

Interface

Description

HDMI Type-A Connector

To connect an HDMI device

LED Indicator

To indicate power & Link status

LC Optical Connector

To connect a single/ multi-mode fiber cable

Micro USB Connector

To input 5V 2A power

Installation Guide

1. Connect HE01FT-4K (The transmitter) to an HDMI source.

2. Connect the optical fiber cable to HE01FT-4K.

3. Power on HE01FT-4K from the micro-USB port.

4. Connect HE01FR-4K (The receiver) to an HDMI device.

5. Connect the optical fiber cable to HE01FR-4K.

6. Power on HE01FR-4K from the micro-USB port.

LED Indication

Transmitter/Receiver

LED Status

Status

HE01FT-4K

(Transmitter)

Off

Not powered

Red

Powered, but no HDMI input

Purple

Powered and HDMI input detected

HE01FR-4K

(Receiver)

Off

Not powered

Red

Powered, but no data transferred from transmitter

Purple

Powered and data received from transmitter

User Manual

HE01F-4K

Caution

The product DOES NOT support CEC due to EDID pass-through. To support CEC, please contact us

for customization.

This product is designed for indoor applications. If it is desired for outdoor use, please install

additional equipment for waterproof protection and surge protectors to prevent damages

caused by lighting.

Both transmitter and receiver have to be powered through a micro-USB port.

Kindly use high-quality OM3 fiber optic cable or upgrade to OM4 fiber optic cable while using

multi-mode to reach the 300M extension, or the signal would probably degrade causing abnormal

images.

Do not put anything on the power and system cables, place them where they cannot be stepped

on. Please be sure there is nothing resting on any cables.

Avoid using this product close to water places, or near high temperature devices such as radiators,

stoves, etc.

Using standard and certified optical fiber cables to transfer high-resolution video is

recommended.

Shut down the power supply and unplugged all equipment immediately if:

owater or any kind of liquid has been spilled into the product;

othe product has been damaged by external force

othe product does not operate normally as this manual indicates

oPlease contact us for further repair if above conditions happen

What’s In the Package

Item

Qty

HE01FT-4K

x 1

HE01FR-4K

x 1

5V 2A Power Adapter

x 2

Micro USB to USB cable 1M

x 2

User Manual

HE01F-4K

Specification

Model

HE01FT-4K

HE01FR-4K

Compliance

Standard

HDCP 1.4, 3D, DDC

Video Resolution

4K@30Hz 4:4:4

Data Rate

10Gbps

Transmission Distance

1 KM over single-mode fiber

300M over multi-mode fiber

Wavelength

1310nm

1550nm

Ports & Interfaces

Video Input

1 x HDMI Type-A

1 x LC Fiber Connector

Video Output

1 x LC Fiber Connector

1 x HDMI Type-A

Power Input

1 x Micro USB

Power

Power Supply

5V 2A

Power Consumption

< 1.5W

Ambient Temperature

Operation

-20 to 70℃

Storage

-40 to 80℃

Operating Altitude

2000m

Humidity

Up to 95%

Physical Characteristics

Dimension

79 x 20 x 10mm

Weight

52g
