IP/ PoE Extender

User Manual

Model : IP09K

Ethernet over CAT5e Extender

User Manual

IP09

Introduction

IP09 is an IP extender that can use a single CAT5e (or greater) cable to send TCP/IP signal to a remote

IP-enabled device, with transmission distance up to 800M and bandwidth up to 100Mbps. Furthermore,

the high bandwidth allows IP09 to send multiple IP signals over one Ethernet cable and split these signals

for different IP devices. It's perfect solution for CCTV security system to extend IP cameras to a remote

NVR for recording.

Features

Signal Extension up to 800M over CAT5e.

Bandwidth up to 70Mbps.

Able to send multiple IP signals over single Ethernet cable.

Supports Auto MDI/MDI-X and full/ half duplex mode.

Built-in 1.5KV (Line to Line) surge protection.

Transmission Distance Chart

The transmission distance report below is tested through the COMMSCOPE 57535-2 (CAT5e 24AWG)

cables.

Mode

Data Rate

Transmission Distance

100BASE-TX

100Mbps

130M

100BASE-T1

100Mbps

300M

Long Reach 100

100Mbps

500M

10BASE-T

10Mbps

250M

Long Reach 10

10Mbps

800M

※The distance may vary by installation conditions, quality of cables, and the performance of

connecting devices.

※10BASE-T / 100BASE-TX and Long Reach 100Mbps mode use 2 pair wire to transmit

※100BASE-T1 and Long Reach 10Mbps mode use 1 pair wire to transmit only

User Manual

IP09

Installation View

(1) Point to Point Transmission

(2) Multi-Camera Video Transmission

(3) Wifi Acess Point Extending Transmission

User Manual

IP09

(4) Extra Long Distance Transmission

(5) Extra Long HDMI Transmission

Panel Review

User Manual

IP09

No.

Interface

Functionality

RJ45 Connector

Port 1；To connect networking devices or another IP09

(Refer to Description 1,2,3)

RJ45 Connector

Port 2；To connect networking devices or another IP09

(Refer to Description 1,2,3)

RJ45 LED

To indicate the network connection status

(Refer to Description 4)

Power Jack

To connect DC12V 0.5A adapter

Power LED Indication

To indicate the power status (Refer to Description 5)

Status Indication

□

1Status : Port 1 mode indication (Refer to Description 6)

□

2Status : Port 2 mode indication (Refer to Description 6)

DIP Switch

To select the desired mode (Refer to Description 7)

Description

1. Link speed of port 1 and 2 must be sync, or they are not able to activate network connection.

2. Once the port 1 and 2 remain unlinked, the IP09 will automatically turn to Power Saving mode.

3. RJ45 Pinout

4. RJ45 LED

Data Rate

LED On

LED Off

LED Blinking

100Mbs

Enable

Disable

Data Transferring

10Mbps

Enable

Disable

Data Transferring

5. Power LED Indication

Green On

Green Off

Light Breathing

Power On

Power Off

Power Saving

(PIN TIA/EIA-568B)

Wire Color

Orange-white

Orange

Green-white

Blue

Blue-white

Green

Brown-white

Brown

User Manual

IP09

6. Status Indication

Blue On

Blue Off

Light Blinking

Blink twice

Long Reach

Ethernet

100BaseT-T1

Hardware Failure

7. Dip Switch Setting:

7.1. Auto Mode / Default (Highly Recommended)

Dip switch 1-2-3-4 all up (OFF)

Auto Mode enable auto negotiation which automatically set up the link speed and

transmssion protocol.

7.2 Auto+EEE Mode

Dip switch 1 down (ON), 2-3-4 up (OFF)

Auto+EEE mode supports Energy-Efficient Ethernet based on Auto Mode.

7.3 Advanced Mode

Please refer to the chart below to manually set up the Link Speed, and Modes

No.

Mode

↑OFF

↓ON

LINK SPEED

10Mbps

100Mbps

ETHERNET

Disable

Enable

100BASE-T1

Disable

Enable

LONG REACH

Disable

Enable

※Link speed of 10Mbps is not supported on 100BASE-T1 mode

Auto-Negotiation Priority

Priority

Mode

1 (Highest)

Long Distance 100Mbps

100BASE-T1

Long Distance 10Mbps

100BASE-TX Full Duplex

100BASE-TX Half Duplex

10BASE-T Full Duplex

7 (Lowest)

10BASE-T Half Duplex

User Manual

IP09

IP09K Package Included

2 x IP09.

2 x DC12V 0.5A Power Adapter.

4 x Screw

4 x Screw Plug

User Manual

IP09

Specification

ITEM NO.

IP09

Support

Compliance

IEEE 802.3 10BASE-T Ethernet

IEEE 802.3u 100BASE-TX Fast Ethernet

IEEE 802.3bw 100BASE-T1 Ethernet

IEEE 802.3 Nway Auto-Negotiation

IEEE 802.3x Full Duplex Operation And Flow Control

IEEE 802.3az Energy Efficient Ethernet

Network Bandwidth

10/ 100Mbps

Max. Transmission Distance

800M at 10Mbps, 500M at 100Mbps

Ports & Interfaces

Input

1 x RJ45

Output

1 x RJ45

Power Interface

2 x (2mm) DC Jack

Power

Power Supply

DC 12V 500mA Regulated

Power Consumption

1W (Max)

Ambient Temperature

Operation

0 to 55℃

Storage

-20 to 85℃

Humidity

Up to 95%

Physical Characteristics

Dimensions

49 x 91.8 x 25mm

Weight

120g

User Manual

IP09
