SC&T HKM01-4K Manual de usuario

Smart Cabling & Transmission Corp. V1.0

HDMI/ KVM Extender Series

User Manual

Model : HKM01-4K

4K HDMI USB/Audio/RS232/IR CAT5e KVM Extender 140M with

Fiber

User Manual

HKM01-4K

Introduction

HKM01-4K is a 4K HDMI KVM extender that use a cost-effective Ethernet cable to send HDMI, USB, Analog

audio, RS232, and IR signals with transmission distance up to 140 meters. Its TX unit has an HDMI loop out

port for an extra HDMI display. The built-in 4 USB2.0 ports at RX unit allow you to control the connected

HDMI device at remote end. The KVM extender can perfectly apply to the broadcasting system, digital

signage, home network integration, industrial control...etc.

Features

Resolutions up to 4K 30Hz 4:4:4.

Signal extension up to 120M over CAT5e, 140M over CAT6.

60KM over single mode fiber optic.

Built-in local loop out for an extra HDMI display at TX side.

Built-in 4 USB ports at RX unit.

Supports bi-directional analog audio transmission for microphones and headphones.

Supports IR, RS232 transmission and EDID management.

Workable with SR01X (IP repeater) for longer distance.

Diagram

User Manual

HKM01-4K

Panel View

HKM01T-4K

No.

Interface

Function

SFP Connector

To insert a SFP transceiver module

LINK/ACT

To indicate the status of SFP link and data transmission

RJ45 Connector

To connect HKM01T-4K/ HKM01R-4K

HDMI IN

To connect a HDMI source

HDMI LOOPOUT

To connect a HDMI display

Power Supply

To plug in DC 5V power adapter

Power/LINK

To indicate the status of Power and LINK

Rotary Switch

To set up the grouping function

RS232

To connect a RS232-command-controllable device

IR Tx

To connect an IR emitter

LINE OUT

To connect a 3.5mm jack for a speaker

LINE IN

To connect a 3.5mm jack for a microphone

USB HOST

To connect an USB-B cable

User Manual

HKM01-4K

HKM01R-4K

No.

Interface

Function

HDMI OUT

To connect an HDMI display

MIC IN

To connect a 3.5mm jack for a microphone

IR Rx

To connect a 3.5mm jack for an IR receiver

Internal IR receiver

To receive IR signal

USB

To connect an USB-A cable

LED Indication

LED Color

Status

Power

Green On/ Off

Power On/ Off

Fiber Connection

Blue On/ Off

Fiber Linked/ Unlinked

RJ45 Connection

Green On/ Off

RJ45 Linked/ Unlinked

RJ45 Connection

Yellow On

Data Transferring

User Manual

HKM01-4K

Bottom View

HKM01T-4K HKM01R-4K

No.

Interface

Function

Tx Button 1

To set up EDID

Tx DIP Switch

To set up Groups, RS232, and EDID

Rx Button 1

To check the status of MAC, IP, Baud Rate and EDID

Rx Button 2

To set up Baud Rate parameters

Rx DIP Switch

To set up Groups and to enable RS232 transmission

RJ45 Pin Define

Color

Data

Orange-white

DATA0 +

Orange

DATA0 -

Green-white

DATA1 +

Blue

DATA2 +

Blue-white

DATA2 -

Green

DATA1 -

Brown-white

DATA3 +

Brown

DATA3 –

User Manual

HKM01-4K

RS232 Pin Define

DB9 (Male)

DB9 (Female)

RxD

TxD

RxD

DTR

GND

DSR

RTS

CTS

Grouping

1. Set up the switch of Tx and Rx (HKM01T/R-4K) to choose a group.

2. Set up the Channel

a. The channel of Tx and Rx in a same group should be the same.

3. Remove the power and plug it in again.

SWITCH

Group / Settings

SW 1

Group 0

OFF↑

Group 1

ON↓

(Up to 32 pairs of Tx and Rx can be set)

User Manual

HKM01-4K

RS232 Setting

Refer to the instructions below to adjust the DIP switch.

1. Check the bottom of the receiver (HKM01R-4K).

2. Press Button 1 to select a Baud Rate.

a. 115200 (Default), 57600, 38400, 19200, 14400, 9600, 4800, 2400, 1200bps.

3. Press Button 2 to choose parameter.

4. Press Button 1 again to confirm the change.

EDID Setting

1. Remove all the HDMI cables.

2. Set up the DIP switch of Tx (HKM01T-4K).

3. Push the button at the bottom of the transmitter (HKM01T-4K).

Tx (HKM01T-4K)

SWITCH

Function

Settings

SW2

RS232 On

(Default)

OFF↑

SW3

OFF↑

Rx (HKM01R-4K)

SWITCH

Function

Settings

SW2

RS232 On

(Default)

OFF↑

SWITCH

EDID Mode / Settings

SW4

1080p 2CH

(Default)

ON↓

Copy

the resolution

from Rx side

OFF↑

Copy

the resolution

from loop out side

ON↓

SW5

ON↓

OFF↑

Button

User Manual

HKM01-4K

Digital /Analog Audio Conversion

Function

Transmitter

LINE IN

Transmitter

LINE OUT

Receiver

MIC IN

Receiver

LINE OUT

Description

Analog Bypass

Analog Audio IN, Analog Audio OUT

(Monitor Audio Muted)

Audio

Embedder

Analog Audio IN, HDMI Audio OUT

Audio

Extractor

HDMI IN, Analog Audio OUT

(support LPCM 2CH, monitor

muted)

HDMI Bypass

HDMI IN, HDMI Audio OUT

O = Connected X = Disconnected

※When the receiver's “LINE OUT” or “MIC IN is connected, the sound of monitor will be automatically muted.

Trouble Shooting

We strongly recommend using high quality CAT5e, CAT6 UTP/STP/FTP cable. Improper installation

may cause unstable connection, and video & audio interruption.

The highest data rate can be 850Mbps, which might affect other devices at the same LAN.

Either UTP or SFP can be used as transmission medium.

When the cable of external IR receiver connects to RX, the front panel IR will be disabled.

Analog audio of Rx (MIC IN) is mono sound for microphone only, not stereo audio (Line in)

Output power of USB is up to 500mA per port, 1500mA in total.

RS232 does not support hardware handshake.

Package Includes

Item

Amount

HKM01T-4K (Transmitter)

1 pc

HKM01R-4K (Receiver)

1 pc

DC 5V2A Power Adapter

2 pcs

IR Emitter Cable

1 pcs

USB A to B cable

1 pcs

Screw

8 pcs

Screw plug

8 pcs

Rubber gasket

2 pcs

User Manual

HKM01-4K

Specification

ITEM NO.

HKM01T-4K

HKM01R-4K

Support

Compliance

HDMI 1.4 , HDCP 1.4, USB 2.0/ 1.1/ 1.0

Max. Video Resolution

4K@30Hz

Max. Transmission Distance

120M over CAT5e; 140M over CAT6; 60KM over single mode fiber optic

Audio Format

LPCM7.1@192KHZ

RS232 Baud Rate

115200bps

IR Support

20-60Khz, ±45°, 5M

20-60Khz , ±45°, 5M

Ports & Interfaces

Video Input

1 x HDMI Type A

1 x RJ45, 1 x SFP

Video Output

1 x RJ45, 1 x SFP

1 x HDMI Type A

Video Loop-out

1 x HDMI Type A

Analog Audio Input

1 x (3.5mm) Stereo Phone Jack

1 x (3.5mm) Mono Phone Jack

Analog Audio Output

1 x (3.5mm) Stereo Phone Jack

IR Receiver

1 x (3.5mm) Stereo Phone Jack

IR Emitter

1 x (3.5mm) Stereo Phone Jack

RS232 Interface

1 x DB9 Female

1 x DB9 Male

USB Interface

1 x USB Type B

4 x USB Type A

Power

Power Supply

DC 5V 2A

Power Consumption

1200mA

400mA

Ambient Temperature

Operation

0 to 55℃

Storage

-20 to 85℃

Humidity

Up to 95%

Physical Characteristics

Dimensions

125 x 140 x 30mm

Weight

380g
