SC&T HE03-4K Manual de usuario

Smart Cabling & Transmission Corp. V.10_1905301

HDMI over IP Extender Series

User Manual

Model : HE03-4K

4K HDMI CAT5e/6 Extender CAT5e 120M/CAT6 140M

User Manual

HE03-4K

Introduction

HE03-4K is a 4K HDMI extender that can use a cost-effective Ethernet cable to send the signal for up to

140M with resolution up to 4K@30Hz 4:4:4. The built-in EDID button can automatically find the connected

HDMI monitor's best resolution and correctly display wanted video. The extender applies AV over IP

technology that allow itself to work with Ethernet switches to split an HDMI to multiple ones, which can

display one HDMI source on multiple displays at the same time.

Features

Resolution up to 4K@30Hz 4:4:4.

Signal extension up to 120M over CAT5e, 140M over CAT6.

Workable with SR01X (IP repeater) for longer distance.

Workable with Ethernet switch for signal distribution.

Installation View

Support 1 to multiple display over Gigabit Network switch:

User Manual

HE03-4K

Panel View

HE03T-4K HE03R-4K

LED Indication Instruction

Position

Color

Instruction

Front Panel

Green

Power on/off

Front Panel

Blue

TX/RX Linked

RJ45

Green

CAT5e Linked

RJ45

Yellow

Data Transmission

Button Define

HE03R-4K

Button

Function

Short press

Display MAC、IP

Long press 2 seconds

Copy receiver monitor EDID to transmitter.

User Manual

HE03-4K

RJ45 Define

Link Cable (use TIA/EIA-568-B)

1. Orange-white Data 1 +

2. Orange Data 1 -

3. Green-white Data 2 +

4. Blue Data 3 +

5. Blue-white Data 3 -

6. Green Data 2 -

7. Brown-white Data 4 +

8. Brown Data 4 –

Cable

Link cable recommend use high quality CAT5e, CAT6 UTP/STP/FTP cable. The max working distance is 140M

(Max) over CAT6. Poor quality cable or network connection or improper construction will cause unstable

connection, video or sound disruptions, picture noise appears.

Caution

The cabling must away from any equipment with electromagnetic wave, i.e.: microwave, radio

equipment, high voltage.

Trouble Shooting

1. HE03-4K transmission data rate up to 850Mbps Max.

2. Do not recommend to connect general LAN to avoid large video data transmission slow down other

LAN devices. 。

3. When connect with Gigabit Switch, make sure to turn off EEE (Energy-Efficient Ethernet).

Package Include

1 x HE03T-4K Transmitter

1 x HE03R-4K Receiver

2 x DC 5V 2Amp Power Adapter

4 x Screw

4 x Screw Plug

2 x Rubber Gasket

User Manual

HE03-4K

Specification

ITEM

HE03T-4K

HE03R-4K

Support

Compliance

HDCP 1.4

Max. Video Resolution

4K@30Hz 4:4:4

Max. Transmission Distance

120M over CAT5e, 140M over CAT6

Audio Format

LPCM 7.1 @192KHz

Ports & Interfaces

Video Input

1 x HDMI Type A

1 x RJ45

Video Output

1 x RJ45

1 x 7HDMI Type A

Power

Power Supply

DC 5V 2A

Power Consumption

550 mA (Max)

960mA (Max)

Ambient Temperature

Operation

0 to 55℃

Storage

-20 to 85℃

Humidity

Up to 95

Up to 95%

Physical Characteristics

Dimensions

88 x 110 x 30mm

Weight

230g
