Danfoss ECtemp 330 Manual de usuario

ECtemp 330 (+5 to +45°C)

Electronic Thermostat

Installation Guide

electricheating.danfoss.com

ECtemp 330 (+5 to +45°C)

Installation Guide2

Danfoss A/S is not liable or bound by warranty if these in-

structions are not adhered to during installation or service.

The English language is used for the original instructions.

Other languages are a translation of the original instructions.

ECtemp 330 (+5 to +45°C)

3Installation Guide

1 Introduction

ECtemp 330 is an electronic thermostat to be installed in

electric cabinets with DIN rail attachment. The thermostat

must be installed via an all-pole disconnection switch. Ei-

ther a ﬂoor sensor or an external room sensor must be used

to measure and control the desired temperature.

The thermostat has a button to adjust the temperature

setting with a scale from +5 to +45°C. An LED indicator

shows standby periods (green light) and heating periods

(red light).

More information on this product can also be found at:

ectemp.danfoss.com

Table of Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . 3

1.1 Technical Speciﬁcations . . . . . . . . . . . 4

1.2 Safety Instructions . . . . . . . . . . . . . . . 5

2 Mounting Instructions . . . . . . . . . . . . . . . 6

3 Settings . . . . . . . . . . . . . . . . . . . . . . . . 7

4 Warranty. . . . . . . . . . . . . . . . . . . . . . . 10

5 Disposal Instruction . . . . . . . . . . . . . . . 12

ECtemp 330 (+5 to +45°C)

Installation Guide4

1.1 Technical Speciﬁcations

Operation voltage 220-240V~, 50Hz

Standby power consumption Max 0.25W

Relay:

Resistive load

Inductive load

Max 16A / 3680W @ 230V

cos φ= 0.3 max1A

Sensing units NTC 15kOhm at 25°C

Sensing values:

0°C

25°C

50°C

42kOhm

15kOhm

6kOhm

Hysteresis ± 0.2°C

Ambient temperature 10°C to +50°C

Lowering in economy periods -5°C

Temperature range +5 to +45°C

Cable speciﬁcation max 1x4mm² or 2x2,5mm²

Ball pressure temperature 75°C

Pollution degree 2 (domestic use)

Type 1C

Storage temperature -20°C to +65°C

IP class 20

ECtemp 330 (+5 to +45°C)

5Installation Guide

Protection class Class II -

Dimensions 86 x 36 x 58mm

Weight 83g

The product complies with the EN/IEC Standard“Automatic

electrical controls for household and similar use”:

• EN/IEC 60730-1 (general)

• EN/IEC 60730-2-9 (thermostat)

1.2 Safety Instructions

Make sure the mains supply to the thermostat is turned oﬀ

before installation.

IMPORTANT: When the thermostat is used to control a

ﬂoor heating element in connection with a wooden ﬂoor or

similar material, always use a ﬂoor sensor and never set the

maximum ﬂoor temperature to more than 35°C.

Please also note the following:

• The installation of the thermostat must be done by an

authorized and qualiﬁed installer according to local

regulations.

• The thermostat must be connected to a power supply

via an all-pole disconnection switch.

• The sensor is to be considered as live voltage. Have

this in mind if the sensor must be extended.

ECtemp 330 (+5 to +45°C)

Installation Guide6

• Always connect the thermostat to continuous power

supply.

• Do not expose the thermostat to moisture, water,

dust, and excessive heat.

2 Mounting Instructions

Please observe the following placement guidelines:

• Install the thermostat in an electric cabinet with DIN

rail attachment or a separate DIN attachment accord-

ing to local regulation on IP classes.

• Do not place the thermostat in a way that it will be

exposed to direct sunlight.

Follow the steps below to mount the thermostat:

1. Click the thermostat on to the DIN rail attachment.

2. Connect the thermostat according to the connection

diagram.

+5°C to

+45°C

ECtemp 330 (+5 to +45°C)

7Installation Guide

The screen of the heating cable must be connected

to the earth conductor of the power supply cable by

using a separate connector.

Note: Always install the ﬂoor sensor in a conduit in

the ﬂoor.

3. Turn on the power supply.

3 Settings

If a ﬂoor sensor is used, please be aware of the following:

• The ﬂoor temperature is measured where the sensor

is placed.

• The temperature of the bottom of a wooden ﬂoor can

be up to 10 degrees higher than the top.

ECtemp 330 (+5 to +45°C)

Installation Guide8

• Floor manufactures often specify the max tempera-

ture on the top surface of the ﬂoor (usually 27-28˚C).

• Always use a ﬂoor sensor to control ﬂoor heating.

Without a ﬂoor sensor, the temperature control may

be less accurate and you risk overheating the ﬂoor.

Thermal

resist-

ance

[m²K/W]

Examples of

ﬂooring

Details Approximate

setting for

25˚C ﬂoor

temperature

0.05 8 mm HDF based

laminate

> 800 kg/m³ 28˚C

0.10 14 mm beech

parquet

650 - 800

kg/m³

31˚C

0.13 22 mm solid oak

plank

> 800 kg/m³ 32˚C

< 0.17 Max. carpet thick-

ness suitable for

ﬂoor heating

acc. to EN

1307

34˚C

0.18 22 mm solid ﬁr

planks

450 - 650

kg/m³

35°C

ECtemp 330 (+5 to +45°C)

9Installation Guide

ECtemp 330 (+5 to +45°C)

Installation Guide10

4 Warranty

A 2-year product warranty is valid for:

• thermostats: ECtemp 330 (+5 to +45°C).

Should you, against all expectations, experience a problem with your Danfoss

product, you will ﬁnd that Danfoss oﬀers Danfoss warranty valid from the date

of purchase on the following conditions: During the warranty period Danfoss

shall oﬀer a new comparable product or repair the product if the product is

found to be faulty by reason of defective design, materials or workmanship. The

repair or replacement.

The decision to either repair or replace will be solely at the discretion of Dan-

foss. Danfoss shall not be liable for any consequential or incidental damages

including, but not limited to, damages to property or extra utility expenses. No

extension of the warranty period following repairs undertaken is granted.

The warranty shall be valid only if the WARRANTY CERTIFICATE is completed

correctly and in accordance with the instructions, the fault is submitted to the

installer or the seller without undue delay and proof of purchase is provided.

Please note that the WARRANTY CERTIFICATE must be ﬁlled in, stamped and

signed by the authorized installer performing the installation (Installation

date must be indicated). After the installation is performed, store and keep the

WARRANTY CERTIFICATE and purchase documents (invoice, receipt or similar)

during the whole warranty period.

Danfoss warranty shall not cover any damage caused by incorrect conditions of

use, incorrect installation or if installation has been carried out by non-author-

ized electricians. All work will be invoiced in full if Danfoss is required to inspect

or repair faults that have arisen as a result of any of the above. The Danfoss

warranty shall not extend to products which have not been paid in full. Danfoss

will, at all times, provide a rapid and eﬀective response to

all complaints and inquiries from our customers.

The warranty explicitly excludes all claims exceeding the

above conditions.

For full warranty text please use QR code
