Danfoss REP24 Manual de usuario

REP24 24V electronic dial setting thermostat

with proportional output

and manual heat cool selection

Installation and Instructions

2

INDEX

Installation 3-9

Specication 3

Mounting 4-5

Wiring 6

DIL switch settings 7

Mounting 8

Locking & Limiting 9

User Instructions 10-12

Setting the temperature 10

Frost Protection 10

Standby Mode 10

Understanding your thermostat 11

Index

3

Specication

Features REP24

Power supply 24 Vac, ± 15%

Control Output 0-10 Vdc

Control Method P + I

Proportional Band 2° K

Temperature range 10-30°C

Maximum ambient temperature 45°C

Control pollution Degree 2

Design standard EN 60730-2-9

Rated impulse voltage 2.5kV

Ball hardness test 75°C

Dimensions (mm) 85 wide x 86 high x 42 deep

Installation Instructions

4

Mounting

Mounting

5

Fix at a height of 1.5m approx from the oor, away from

draughts or heat sources such as vents, heating elements or

direct sunlight.

Mounting

Mounting

6

Wiring

1

B

A234

24 Vac

0V 24V 0V V out

output

0-10V

ELECTRONICS

Wiring

7

DIL switch settings

Slide the DIL switches to the settings required.

HEAT - proportional output will activate if temperature is below

the setpoint. Frost protection mode is available (see page 10 ).

COOL -

proportional output will activate if temperature is above

the setpoint. Frost protection not available in cooling mode.

MOT -

Motorised valve actuator selection.

WAX -

Wax valve actuator selection.

MOT WAX

Heat Cool

DIL switch settings

Sw. On

8

Mounting

Mounting

9

Locking & Limiting

Locking - setting the thermostat at a temperature which

cannot be altered by the user.

Limiting - allowing the user to alter the temperature within

a predened range, which is less than the full range of the

product (i.e. between 18-22°).

Locking & Limiting

10

Setting the temperature

Turn setting dial to required temperature.

Frost Protection

To activate frost protection, turn the dial below 10°C. Frost

protection becomes active at 8°C. If the temperature in the

room drops below 8°C then the output will activate.

When frost protection is activated the right LED will turn

orange.

Standby Mode

In cooling mode, the standard frost protection is not available;

instead there is standby mode. When the dial is turned past

10°C the unit enters standby mode and cooling will be inactive

until dial is turned up past 10°C.

Display / Setting the temperature

User Instructions
