8 by 8 HDMI V1.3 Matrix
Operation Manual
CMLUX-88S
Disclaimers
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes
no commitment to update or to keep current the information
contained in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
Copyright Notice
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer file, in any form or by any means
- electronic, mechanical, magnetic, optical, chemical, manual,
or otherwise - without express written permission and consent from
Cypress Technology.
© Copyright 2009 by Cypress Technology.
All Rights Reserved.
Version 1.0 August 2009
Trademark Acknowledgments
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
Safety Precautions
Please read all instructions before attempting to unpack or install or
operate this equipment, and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
Always follow basic safety precautions to reduce the risk of
fire, electrical shock and injury to persons.
To prevent fire or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
Never spill liquid of any kind on or into this product.
Never push an object of any kind into this product through
module openings or empty slots, as you may damage parts.
Do not attach the power supply cabling to building surfaces.
Do not allow anything to rest on the power cabling or allow it to
be abused by persons walking on it.
To protect the equipment from overheating, do not block the
slots and openings in the module housing that provide
ventilation.
Revision History
Version No Date Summary of Change
V1 20090805 Preliminary Release
V2 20100510 Rack Installation change
Table of Contents
1
2
2
2
2
3
4
5
5
7
8
8
8
9
9
9
9
10
12
13
I. Rack Installation Guideline ..………...……………...…........….……
1. Introduction ……………………..……………………...…........….…….
2. Applications …………………..………………….……...................…..
3. Package Contents ………………………...........……….................…
4. System Requirements ……………..……….........………............…….
5. Features …………………………………………......……........…...……
6. Specications ………………………………...……..........………....….
7. Operation Controls and Functions ……………...……..............……
7.1 Front Panel ..............................................................................
7.2 Rear Panel .…………………………………..…….......…...….…
8. Remote Control .......................…......……………..........…..…....…...
8.1 IR Costom Code.................…......……………..........…..…....….
8.2 Discrete IR codes for 8x8 HDMI matrix (IR3).........…..…....…...
9. IR Pin Assignment .............................................................................
9.1 IR Receiver ...............................................................................
10. RS-232 Protocols ……………...……........……................................…
10.1 Pin Assignment ......................................................................
10.2 Commands ………...……………….………….........……....…
11. Connection and Installation ….………………….........…..…..…......
12. Acronyms …......................................................................................
AL-Shaped rail x 2 BMounting screws x 4
① Use Mounting screws to
attach the L-Shape rail
to the frame.
② Make sure the L-Shaped rail and the
Mounting screws are properly aligned,
with two screws per L-Shaped rail.
CFlanged screws x 4
③ Slide the device on top of the L-Shaped rails.
CMLUX-88S
A
A
X 4 B
A
B
④ Use four Flanged screws to attach the 8x8 Matrix to the rack frame.
OUT B C D E F G HA
IN 2 3 4 5 6 7 81
POWER EDID LOCK ALL MEMORY RECALLENTER
CMLUX-88S
8x8 HDMI v1.3 MATRIX CC
I. Rack Installation Guideline
1
1. Introduction
The popularity of HDMI products has been increasing for several years and
is now commonly seen in residential and commercial settings. As people
become accustomed to HDMI and use it more often, they acquire multiple
devices and then find that they need something to help them link them
together. So the need for an HDMI matrix that can interconnect multiple
sources and different inputs has become an obsession for some. Well no
need to worry because our “HDMI V1.3 Matrix” is a powerful tool that you can
use to handle all of your HDMI needs. Furthermore the matrix supports HDMI
1.3, HDCP 1.1 and DVI 1.0, and can transfer Deep Color video and bit stream
digital audio with fantastic performance. Lastly the input EDID is independent
allowing each input to switch between TV or the built-in EDID.
2. Applications
Multi-HDMI sources with multi-HDMI display controls
Event entertainment integration
Multi-task project presentation
Showroom display
Advertisement display control
3. Package Contents
8 by 8 HDMI V1.3 Matrix
Remote Control CR-71 with battery
24V DC power adaptor
Power cord
User Manual
2 x 2 - Shape holder
4. System Requirements
HDMI input device(s) and HDMI output device(s) with HDMI cables.
2
5. Features
HDMI 1.3, HDCP 1.1 and DVI 1.0 compliant
Supports digital video formats in Deep Color 10 bits and new lossless
compressed (Dolby TrueHD, Dolby Digital Plus and DTS HD Master Audio)
digital audio
The HDMI input is compensated, clock/phase adjusted and jitter free so
all the user sees is a high quality HDMI signal.
Supports recall, memory and key lock function
Compatible with all HDMI sources and displays
Supports a wide range of PC and HDTV resolutions from VGA to UXGA
and 480i to 1080p
Supports RS-232 control and firmware upgrading through USB port
Supports IR remote control and IR extender
Dolby Digital, DTS digital audio transmission (32-192kHz Fs sample rate)
Supports LPCM 7.1 channel output from each of the independent HDMI
ports
HDMI cable testing showed that with a resolution 1080p/8bits&10bits the
Input/Output source can be 10/15m(8bit) and 10/10m(10) away
Independent switchable EDID function for choosing which resolution to
display
High performance HDMI 1.3 Matrix with 8 (eight) inputs and 8 (eight)
outputs with a remote control in order to link multiple HDMI sources, such
as movies, music and games, all at the same time.
Supports 38KHz IR extender
4U's rack design for easy installation
Useful hot keys for quick set up
Strong build quality and an intelligent design allow the HDMI V1.3 Matrix
to breathe properly and not overheat
3
6. Specications
Input Ports 8 x HDMI
Output Ports 8 x HDMI
IR Frquency 20~60KHz
Power Supply 24VDC/6.25A (US/EU standards,
CE/FCC/UL certified)
ESD Protection Human body model: ± 10kV (air-gap discharge)
± 6kV (contact discharge)
Dimensions (mm) 482(W) x385(D) x 176(H)
Weight(g) 9500
Chassis Material Aluminum
Silkscreen Color Metal Black
Power Consumption 100W
Operating Temperature 0˚C ~ 40˚C / 32˚F ~ 104˚F
Storage Temperature -20˚C ~ 60˚C / -4˚F ~ 140˚F
Relative Humidity 20~90% RH (no condensation)
4
7. Operation Controls and Functions
The following sections describe the hardware components of the unit.
7.1 Front Panel
① ② ⑩③ ④ ⑤ ⑥ ⑦ ⑧ ⑨
① LCM monitor: This monitor displays your settings information with each
output and input selection.
② IR sensor.
③ POWER: Press this button to turn the system on. Once the system turns on
the LED will turn Green and when entering Standby Mode it will turn Red.
Once the system turns on the LED will turn Green and when entering
Standby Mode it will turn Red.
④ EDID: There will be two selections shown on the LCM: 1. TV mode and
2.Standard Mode, press the number key to first select the desired input
and then press one or two to select the EDID mode. The LED will turn on
when setting the EDID. After the selection is made, press enter key to
confirm. Standard mode means the device will use internal built-in EDID
and TV mode means the device will use TV/display’s EDID. When EDID is
in TV mode,
Notes:
1. When EDID is switched to a TV the device will first detect the HDMI
output source’s EDID from A-D and then record it in the unit regardless
of the HDMI output source from E-H. If the first detected output source is
DVI it will pass on to the next source, until the first HDMI is detected. The
detection priority is HDMI v1.3 > HDMI v1.2 > DVI. In order to ensure all
output is displayable output from E-H must be of a lower standard then
output from A-D.
2. When EDID is on STD, the device will use the built-in EDID
Video Supports < 1080p 10 bits (max)
Audio Supports = PCM2
5
⑤ LOCK: Press this button to lock all the functions and press it again to
release the lock. When LED turns Green, the lock is activated and when it
turns red the key lock has been released.
⑥ ENTER: Press this button after each and every selection to confirm the
setting. If this button is not pressed after 20 seconds the selection will be
cancelled.
⑦ ALL: Press this button to set all the outputs to display with the same input.
After pressing the All button press an input number and then press enter to
confirm the selection.
⑧ MEMORY: Press this button to choose your six pre-set settings. First press
the setting number, and when all the input/outputs are being set, be
sure to press MEMORY to record it into the system. The factory default
settings are 1.12345678, 2.87654321, 3.11223344, 4.55667788, 5.11221122,
6.33443344.
⑨ RECALL: Select this button in order to retrieve your six pre-set settings, then
press enter to confirm your selection.
⑩ OUT A~H & IN 1~8: Press the output source selection button in order to
choose which input port corresponds to the desired output port. First
select your output port from A-H, wait 2 sec, then choose the desired
input port from ports 1-8, pressing enter will confirm your setting. Each
output selection only allows a single input setting each time.
6
