CDPS-UH4H1HFS

4×1 HDMI 4K UHD Switcher

with Control System Center

Operation Manual

DISCLAIMERS

The information in this manual has been carefully checked and

is believed to be accurate. Cypress Technology assumes no

responsibility for any infringements of patents or other rights of third

parties which may result from its use.

Cypress Technology assumes no responsibility for any inaccuracies

that may be contained in this document. Cypress also makes no

commitment to update or to keep current the information contained

in this document.

Cypress Technology reserves the right to make improvements to this

document and/or product at any time and without notice.

No part of this document may be reproduced, transmitted,

transcribed, stored in a retrieval system, or any of its part translated

into any language or computer le, in any form or by any means—

electronic, mechanical, magnetic, optical, chemical, manual, or

otherwise—without express written permission and consent from

Cypress Technology.

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or

operate this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts

inside the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU

if it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sufcient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE

VR0 10/11/15 Preliminary release

VS1 07/03/17 Updated text/diagrams

CONTENTS

1. Introduction......................................................1

2. Applications.....................................................1

3. Package Contents ..........................................1

4. System Requirements......................................2

5. Features............................................................2

6. Operation Controls and Functions.................3

6.1 Front Panel ................................................. 3

6.2 Rear Panel.................................................. 4

6.3 Remote Control......................................... 6

6.4 IR Cable Pin Assignment........................... 6

6.5 RS-232 Protocol.......................................... 7

6.6 RS-232 and Telnet Commands ................ 7

6.7 Telnet Control .......................................... 13

6.8 WebGUI Control ...................................... 15

6.8.1 Routing Settings.............................. 16

6.8.2 Audio Settings................................. 17

6.8.3 EDID Settings................................... 17

6.8.4 Macro Settings ............................... 18

6.8.5 Command Settings........................ 19

6.8.6 Network Settings ............................ 20

6.8.7 System Settings............................... 21

7. Connection Diagram ....................................22

8. Specications ................................................23

8.1 Technical Specications ........................ 23

8.2 Video Specications............................... 24

8.3 Audio Specications............................... 25

9. Acronyms .......................................................26

1. INTRODUCTION

This 4×1 HDMI 4K UHD Switcher allows you to select between four HDMI

sources and route your selection to a single HDMI display. Additionally,

stereo audio is extracted, output, and amplied, without the need for

a dedicated amp, via speaker connections on the back of the unit

making it ideal for small events or classrooms. The included control

system functionality provides access not only to direct but also indirect

control interfaces for all of your devices. Direct control methods such

as IR, RS-232, relay and DC triggers allow users to maintain traditional

styles of control over devices while indirect device control is possible

using Telnet, allowing users to control newer, more complicated,

devices. The operation of the system can be easily managed through

the included WebGUI by connecting with your PC, laptop or even a

mobile device such as a tablet.

2. APPLICATIONS

• Home Theater with Smart Home Control

• Showroom Display with Kiosk Controls

• Security/Alarm Monitoring and Control

• Classrooms

3. PACKAGE CONTENTS

• 1×4 by 1 HDMI 4K UHD Switcher

• 1×Remote Control (CR-153)

• 1×IR Blaster Cable

• 1×3.5mm to 9-pin D-sub Female Connector

• 2×3-pin Terminal Blocks

• 1×5-pin Terminal Block

• 1×8-pin Terminal Block

• 1×24V/3.75A Power Adaptor

• 1×Power Cord

• 1×Operation Manual

4. SYSTEM REQUIREMENTS

• HDMI input source equipment such as media players, video game

consoles or set-top boxes.

• HDMI receiving equipment such as HDTVs, monitors or audio

ampliers.

• Trigger input source equipment such as motion detection cameras,

TVs, power switches, etc.

• An active internet connection from a switch or router for control of

Ethernet devices.

• The use of “Premium High Speed HDMI” cables is highly

recommended.

5. FEATURES

• HDMI with 3D and 4K UHD support, DVI 1.0 compatible

• Supports HDCP 1.4 for all HDMI inputs and outputs

• Supports resolutions up to 4K UHD: 3840×2160@24/25/30Hz &

3840×2160@50/60Hz (YUV 4:2:0), 4096×2160@24/25/30Hz &

4096×2160@50/60Hz (YUV 4:2:0)

• Supports HDMI data rates from 300Mbps up to 3Gbps and “Deep

Color” up to 1080p w/ 36-bit color

• Supports auto source detection and switching

• Amplied stereo speaker outputs support LPCM 2.0 sources from

HDMI or optical

• Supports simultaneous audio output over HDMI and analog stereo

• Per-input HDCP support control

• Supports system control with 5 IR outputs, 4 Trigger inputs, 4 Relay

outputs, 2 COM ports, and 1 Ethernet port

• Supports 4 trigger inputs with a voltage range of 0~3.3V

• Supports COM port baud rates from 4800~115200bps

• Supports RS-232, IR, Telnet, and WebGUI controls

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

POWER

MUTE

OPT.

SYNC

MUTE

IR 4

TRIG IN

OPTICAL

HDMI

1 2 4 5 6 7

1POWER & LED: Press this button to power the unit on (green LED) or

place it into stand-by mode (red LED).

Note: To force the IP mode to switch from Static to DHCP press and

hold the power button for 3 seconds while the unit is ON and the

LED will blink once to indicate the change has occurred.

2IR Window & LED: Accepts IR signals from the included IR remote

for control of this unit only. The LED will blink when IR signals are

received.

3HDMI IN: Press this button to sequentially switch through the 4

available HDMI inputs.

4OPTICAL IN: Press this button to select the optical input as the live

audio for the analog stereo outputs. Press the “HDMI IN” button

once to return to outputting the HDMI source’s audio.

Note: The HDMI output will always follow the selected HDMI input’s

audio. Only the analog speaker connections will output the audio

from a selected optical source(LPCM 2.0 only).

5-/+ (MINUS/PLUS): Press these buttons to adjust the audio volume

up/down.

6MUTE: Press this button to mute the analog speaker output's audio.

Note: To return back to the unit’s factory defaults, press and hold

this button while plugging the AC power into the unit.

7HDMI IN LED 1~4: These LEDs will illuminate to indicate which source

is currently selected.

OPT IN LED: This LED will illuminate when optical is selected as an

audio source.

SYNC LED: This LED will illuminate when a valid HDMI source is

detected from the currently selected input.

MUTE LED: This LED will illuminate when audio is muted. When the

currently selected audio input is in an unsupported format, or

absent, this LED will blink and analog output will be automatically

muted.

TRIGGER IN LEDs 1~4: These LEDs will illuminate when their

associated trigger input has been activated. The legal voltage

threshold is from 0V to 3.3V and activation is determined by the

system settings (rising, falling, or change).

6.2 Rear Panel

12HDMI IN 34HDMI OUT

USB

RS-232

CONTROL

INFRARED OPT. IN RELAY OUTCOM 1 COM

R1TX RX TX RX R2 R3

1234

OUT 1 OUT 2 OUT 3 OUT 4 OUT 5

SPEAKER

DC 24V

7 94 5 6 810 11

1 2 3 12

1HDMI IN: Connect to HDMI source equipment such as media

players, game consoles or set-top boxes.

Note: This unit has an automatic source detection function and will

automatically switch to the most recently connected/activated

HDMI input. If the currently selected input is disconnected, or turns

off, the unit will automatically switch to the next available live

input.

2HDMI OUT: Connect to an HDMI TV, monitor or amplier for digital

video and audio output.

3SPEAKER OUT: Connect to unpowered analog speakers using

banana plug or bare-tipped speaker wire.

Note: These terminals only support LPCM 2.0 audio sources, other

formats will be automatically muted.

4USB: This slot is reserved for rmware update use only.

5CONTROL: Connect to an active Ethernet network with an RJ-

45 terminated cable to allow control of the unit via WebGUI and

Telnet or to allow the unit to control other devices on the network.

6RS-232: Connect directly to your PC/laptop using the provided

cable to send RS-232 commands to control the unit.

7IR OUT 1~5: Connect to the provided IR Blasters to transmit IR

signals to devices within direct line-of-sight of the IR Blaster.

8OPT. IN: Connect any LPCM 2.0 optical audio source to this port for

output over the analog stereo output.

9COM 1~2: Connect to RS-232 controllable devices to send

commands to those devices via macros. Please use terminal block

to DB-9 adapter cables.

10 RELAY OUT 1~4: Connect to devices that support DC relay trigger

functionality to power or activate them via macro commands.

11 TRIGGER IN 1~4: Connect to any device with trigger or switch

functionality such as window security alarms, motion detectors,

door switches, etc. Each of the 4 trigger inputs will activate the

associated macro when triggered.

12 DC 24V: Plug the 24V DC power adapter into the unit and connect

it to an AC wall outlet for power.

Otros manuales para CDPS-UH4H1HFS

Tabla de contenidos

Otros manuales de Cambiar de CYP

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario
