CDB-6HP
HD Audio Amplier
Operation Manual
Operation Manual
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2015 by Cypress Technology.
All Rights Reserved.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE
RDV1 16/03/16 Preliminary release
CONTENTS
1. Introduction............................................ 1
2. Applications........................................... 1
3. Package Contents ................................ 1
4. System Requirements............................ 1
5. Features.................................................. 2
6. Operation Controls and Functions....... 3
6.1 Panel Description .............................3
7. Connection Diagram ............................ 4
8. Specications ........................................ 5
1
1. INTRODUCTION
This USB to Headphone Audio Converter is a simple but smart
device and no external power is required. It allows you to connect
your PC/laptop to a set of analog headphones or other analog
audio destination devices for delivery of superior audio quality. This
compact HD audio product supports LPCM 2.0 audio with a maximum
sampling rate of 384kHz/24-bit and utilizes a direct-coupled amplier,
for better frequency response and to avoid signal loss, providing
higher audio quality than is typically delivered by a standard PC/
laptop’s headphone output. This unit connects to your PC/laptop
using any available USB 2.0 (or higher) port (Windows and Mac OSX
compatible).
2. APPLICATIONS
• High-resolution audio playback
• Improved audio quality from laptops for presentations or
entertainment
3. PACKAGE CONTENTS
• HD Audio Amplier
• Driver Disk
• Operation Manual
4. SYSTEM REQUIREMENTS
• Audio source equipment such as PC/Mac/laptop with an available
USB port. (Windows XP, Vista, 7, 8, 8.1, 10 (32 & 64-bit) or Apple OSX
version 10.6.4 and later)
• Analog audio receiving equipment such as headphones, audio
ampliers or powered speakers.
2
5. FEATURES
• Output HD audio from your PC/laptop to headphones
• Superior USB audio processor (XMOS U8A) supporting sample rates
up to 384kHz/24-bit
• Superior DAC engine (TI PCM5101A) which supports up to 384kHz for
digital to analog signal conversion
• Direct-coupled amplier for better frequency response and to avoid
signal loss
• Simple operation and compact design
• No external power required
3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Panel Description
HD AUDIO AMPLIFIER
IN OUT
384KHz
321
1USB IN: Connect to computer source equipment with an available
USB port such as a PC/Laptop (Windows and Mac Operating
Systems are compatible).
2POWER LED: This LED will illuminate RED to indicate the unit is on and
receiving power from the USB connection.
3Headphone OUT: Connect to headphones, powered speakers or
an amplier via 3.5mm headphone plug for analog audio output.
4
7. CONNECTION DIAGRAM
HD AUDIO AMPLIFIER
IN OUT
384KHz
PC/Laptop
Head/Earphones or
Speakers
5
8. SPECIFICATIONS
Input Ports 1 x USB 2.0 (Type B)
Output Ports 3.5mm headphone jack
ESD Protection Human body model:
±8 kV (air-gap discharge)
±4 kV (contact discharge)
Chassis Material Aluminum
Silkscreen color Black
Dimensions 81mm × 22.5mm × 25mm (W×H×D) [Case Only]
Operating Temperature 0˚C~40˚C/32˚F~104˚F
Weight 54g
Storage Temperature −20˚C~60˚C/−4˚F~140˚F
Relative Humidity 20~90% RH (non-condensing)
Power Consumption 0.5W
USB Audio Specication
USB Audio Class USB Audio 2.0
Format Support LPCM 2.0: 44.1kHz, 48kHz, 88.2kHz, 96kHz,
176.4kHz, 192kHz,
352.8kHz, 384kHz
Windows XP, Vista, 7, 8, 8.1, 10 (32 & 64bit) / OSX
10.6.4 above
OS Support Windows XP, Vista, 7, 8, 8.1, 10 (32 & 64-bit) / OSX
10.6.4 and above
Audio Specication
Output
Sample
Rate
Output
Level
THD+N
(A-Weight)
Frequency
Response
SNR Crosstalk
USB
0dBFS/1kHz
384kHz 160mW
at
16ohm
<0.01% ±1dB >80dB <-80dB
