QU-18S

v1.3 HDMI 1 to 8 Rack

Mountable Distribution Amplier

OPERATION MANUAL

1. Introduction 1

2. Features 1

3. Operation Controls and Functions 2

3.1 Front Panel Diagram 2

3.2 Rear Panel Diagram 3

4. Connection Diagram 4

5. Specications 5

Table of Contents

1. Introduction

The QU-18S HDMI Distribution Amplier has a single HDMI input with 8 HDMI

outputs. The Silicon Image chipset based splitter is compatible with both Deep

Colour (10 & 12bit) and HD Audio. It boasts an extended HDMI output range of

up to 20 metres. EDID management is handled by a simple switch. A common

application of this product is in commercial and residential installations where one

HDMI source is required at multiple HDTV’s.

2. Features

• Compliant with v1.3 HDMI, HDCP 1.1 and DVI 1.1 standards.

• HDMI 1 to 8 Splitter.

• Resolutions Supported:

• PC: VGA to UXGA

• HDTV: 480i to 1080p, plus 1080p24fps.

• High Denition Audio supported: Dolby TrueHD, Dolby Digital Plus and DTS-HD

Master Audio, plus LPCM (32-192KHz sample rate).

• Auto signal amplication & equalisation improves signal transmission

distances.

• Support CEC bypass.

• Supports ‘Deep Colour’ (10 & 12 bit).

• Selectable EDID settings - TV (downstream) and STD (xed).

• Power, HDMI/DVI, HDCP & SYNC, plus independant output LED indicators.

Page 1

Page 2

3. Operation Controls and Functions

3.1 Front Panel

1. HDMI/DVI Indicator: The LED will illuminate when the selected HDMI input

source is originally from a HDMI output. The LED will not illuminate when the

signal originates from a DVI source.

2. HDCP Indicator: The LED will illuminate when the selected HDMI input source

is HDCP protected.

3. SYNC Indicator: The LED will illuminate when the selected HDMI input

connects to a HDMI or DVI output correctly.

4. HDMI Output Indicator: The LED will illuminate when the output sources are

connected.

5. POWER Indicator: The Power LED will illuminate when the power is On.

OUTPUT

POWERSYNC

HDCPHDMI / DVI 12345

678

QU-18S 1X8 HDMI 1.3 SPLITTER

1 3 4 5

2

Page 3

3.2 Rear Panel

1. EDID Control Switch: Default setting is TV (downstream). In this mode the

QU-18S will search all output ports (starting at output 1) for the highest

video/audio settings connected to each of the outputs.

The detection priority

of the matrix is v1.3 HDMI, v1.2 HDMI, DVI.

Switch to STD (xed EDID) if

you have any issues with the default setting (TV). When switching to STD,

please ensure that the unit is powered OFF, then ON again, for the setting to

be made. By changing to STD, this will force the source to be congured as

standard stereo (PCM) Audio and initiate a search for a common compatible

video resolution.

2. HDMI Input: Connect input port to the HDMI or DVI output of your source

equipment such as a Blu-Ray player or set-top box.

3. HDMI Outputs 1 to 8: Connect each of the output ports to the HDMI display.

When more than one output is connected, the HDMI outputs play an identical

video signal simultaniously.

4. POWER: Plug the 5V DC power supply into the splitter and connect the

adaptor to the AC wall socket.

1

HDMI IN DC 5V

11 2 3 4 5 6 7 8

EDID

STD TV

HDMI OUT

1 3 42

4. Connection Diagram

Page 4

Input 1 x HDMI

Output 8 x HDMI

Power Supply 5V/6A DC (US/EU standards, CE/FCC/UL certied)

Dimensions (mm) 435(W) x 160(D) x 45(H)

Gross Weight (g) 800

Net. Weight (g) 580

Chassis Material Aluminium

Colour Black

Operating Temperature Operating from 0°C ~ 48°C

5. Specications
