Features:

• 2-Channel Audio Amplier

• Rugged & Durable Marine Grade Construction

• Water Resistant & Weatherproof Design

• Bluetooth Receiver for Wireless Music Streaming Ability

• USB Flash & SD Memory Card Readers

• MP3 Digital Audio File Compatibility

• LCD Digital Display Screen

• RCA (L/R) Audio Connectors

• Spring-Loaded Speaker Terminals

• Connect & Stream Audio from External Devices

• Heavy Duty Aluminum Alloy Heatsink

• Side Panel Button Control Center

• Volume, Bass, Treble Rotary Controls

• Built-in Thermal, Overload & Speaker Short Protection

• Includes Wall Power Adapter

• Power ON/OFF Switch

BT Wireless Connectivity:

• Works with All of Today's Latest Devices

• (Laptops, Computers, Smartphones, Tablets, etc.)

• Smart Auto Connect Pairing Ability

• Bluetooth Version: 2.1

• Bluetooth Network Name: Pyle

• Wireless Range: About 50' ft.

Technical Specs:

• MAX Power: 200 Watt ( I 00W x 2)

• Amplier Type: Class-D Circuit

• Marine Grade Rating: IP-41

• Impedance: 4 Ohm

• Frequency Response : 10 - 40kHz

• Channel Separation : > 65dB

• T.H.D.: <1.0%

• S/N Ratio : > 95dB

• Maximum USB Flash Support: 32 GB

• Digital Audio File Support: MP3, WMA, WAV

• Power: 1 I 0/220V (DC 12.5V Power Adapter)

• Dimensions (LxWx H): 10.2" x 8.6" x 2.1"

• Sold as: I

PFMRA340BB

PFMRA350BW

Weather Resistant Audio Amp System

with MP3/USB/SD Readers, 200 Watt

USER MANUAL

Marine Amplier

1. SD Card input for MP3 player

2. USB input for MP3 player

3. Treble Volume Control

4. Bass Volume Control

5. Master Volume Control

6. Display screen

7. Input select

8. Previous song

9. PIay/Pause function

10. Next song

11. Amplier output jack

12. Power plug

13. Power ON/OFF Switch

14. Power Adapter jack(1 2.5V/2.5A)

15. Audio Input(L/R)

BLUETOOTH OPERATION INSTRUCTION:

External devices which have a built-in Bluetooth feature can be

connected to this amplier wirelessly to play through the

amplier's speakers. If your amp is connected to speakers, you will

hear audible tones which will help for connecting.

1. At rst be sure that the amplier is powered on, and turn the

volume to low.

2. Press "MODE" button on the front panel, the unit is automatically

ready to pair with your devices when you here two "Tone".

3. Turn on the Bluetooth of your external device.

4. Search for available Bluetooth devices and make sure to be

within range of your amp, and wait for your device to select

"PYLE " on the pairing devices lists of Bluetooth networks.

5. You can now play music on your external device through the

amplier.

Notes: This Marine Amplier has a bluetooth prioritized

function, unit will auto enter BT mode when your external

devices are in the wireless range.

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

•Consult the dealer or an experienced radio/TV technician for help.

Caution: Any changes or modiﬁcations to this device not explicitly approved by manufacturer could

void your authority to operate this equipment.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

RF Exposure Information

The device has been evaluated to meet general RF exposure requirement. The device can be used in

portable exposure condition without restriction.
