QU-16E-4K

1 to 16 HDMI Distribution Amplier (4K Resolution Support)

OPERATION MANUAL

DISCLAIMERS

The information in this manual has been carefully checked and is

believed to be accurate. CYP (UK) Ltd assumes no responsibility for any

infringements of patents or other rights of third parties which may result

from its use.

CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be

contained in this document. CYP (UK) Ltd also makes no commitment to

update or to keep current the information contained in this document.

CYP (UK) Ltd reserves the right to make improvements to this document

and/or product at any time and without notice.

No part of this document may be reproduced, transmitted, transcribed,

stored in a retrieval system, or any of its part translated into any language

or computer le, in any form or by any means—electronic, mechanical,

magnetic, optical, chemical, manual, or otherwise—without express

written permission and consent from CYP (UK) Ltd.

Version 1.1 August 2011

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or operate

this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts inside

the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU if

it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sucient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE SUMMARY OF CHANGE

v1.00 23/06/14 First release

CONTENTS

1. Introduction...........................................6

2. Applications ...........................................6

3. Package Contents ..................................6

4. System Requirements ...........................6

5. Features..................................................7

6. Operation Controls and Functions .......8

6.1 Front Panel................................................... 8

6.2 Rear Panel..................................................... 8

7. Connection Diagram .............................9

8. Specications...................................... 10

9. Acronyms............................................. 10

1. INTRODUCTION

The QU-16E-4K is a versatile 1 to 16 HDMI distribution amplier.

This product is designed to be used in a 19″rack and will distribute

uncompressed HDMI signals up to 4K resolutions. Each buered output

can run 1080p/8-bit up to 10 metres and can be cascaded up to two

layers.

2. APPLICATIONS

Simultaneously display one HDMI source on 16 displays

Showroom display

University lecture hall display

Retail sales display

3. PACKAGE CONTENTS

1× 1 by 16 HDMI Distribution Amplier

1× 5V/6 A DC Power Supply Adaptor

Operation Manual

4. SYSTEM REQUIREMENTS

HDMI equipped source device such as a DVD/Blu-ray player with HDMI

or DVI to HDMI cable

HDMI equipped displays (HDTVs or projectors) or AV Receivers with

HDMI cables

5. FEATURES

HDMI, HDCP 1.1 and DVI 1.0 compliant

Resolution Supported: PC - VGA to UXGA; HDTV - 480i to 1080p +

1080p24fps, and 4K

High Denition Audio supported: LPCM 7.1Ch, Dolby TrueHD, Dolby

Digital Plus and DTS-HD Master Audio transmission (32-192kHz Fs

sample rate)

HDMI cable distance tested with 1080p/8bits resolution the I/O source

can up run up to 15/15 meters. If 1080p/12bits the I/O source can run

up to 15/10 meters.

Supports xvYCC

Supports CEC bypass

Supports 3D signals

4K Resolution Support

Note: When displaying a 3D signal with a higher bandwidth than 225 MHz or

a 4K×2K resolution source, a High Speed HDMI cable is required.

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

POWERSYNC

1 2

POWER LED: The power LED will illuminate when the unit is powered.

SYNC LED: The LED will illuminate when the HDMI source signal is

connected to the input port.

6.2 Rear Panel

DC 5V

SERVICE

13 15

STD TV

INPUTOUTPUT

EDID

1 2 3 4 5

EDID STD/TV: The default factory setting is TV, when in this mode,

the unit will detect the rst HDMI output device's EDID settings and

record them in the unit's memory. If there are any audio or video

issues then switch the unit to STD (Standard) mode and power cycle it,

the unit will be congured as standard stereo (PCM) Audio and initiate

a search for a common compatible video resolution.

SERVICE: Manufacturer use only.

HDMI INPUT: Connect the input port to the HDMI or DVI output of

your source equipment such as DVD player or set-top box.

HDMI OUTPUTS (1~16): Connect each of the output ports to an

HDMI display for simultaneous HDMI distribution.

DC 5V: Connect the 5V DC power supply into the splitter and Plug the

adaptor to AC wall outlet.

7. CONNECTION DIAGRAM

DC 5V

SERVICE

13 15

STDTV

INPUT OUTPUT

EDID

TV/Projectors

Power

Supply

Blu-ray

Player

HDMI Input Simultaneous

HDMI Outputs

Simultaneous

HDMI Outputs

8. SPECIFICATIONS

Video Bandwidth 300 MHz/9 Gbps

Input Port 1×HDMI (Female connector), 1×USB

(Manufacturer use only)

Output Ports 16×HDMI (Female connector)

Output Resolutions 480i~1080p@50/60, 1080p@24/50/60,

VGA~UXGA, Ultra HD (4K×2K@30)

ESD Protection Human body model:

±8 kV (air-gap discharge)

±4 kV (contact discharge)

Dimensions 436 mm (W)×26 mm (D)×48 mm (H)

Weight 1664 g

Chassis Material Metal

Colour Black

Operating Temperature 0 ˚C~40 ˚C/32 ˚F~104 ˚F

Storage Temperature −20 ˚C~60 ˚C/−4 ˚F~140 ˚F

Relative Humidity 20~90 % RH (non-condensing)

Power Consumption 15.8 W

9. ACRONYMS

ACRONYM COMPLETE TERM

4K×2K Ultra HD Resolution (3840×2160)

HDMI High-Denition Multimedia Interface

HDTV High-Denition Television
