Winmate G-Win Series Manual de usuario

Please read these instructions carefully before using this product, and save this manual for future use.

Full IP67 Panel PC

G-WIN Series

R19IK3S-67FTP(HB)

Quick Start Guide

Document Version 1.0

Document Part No. 915211101077

2 R19IK3S-67FTP(HB) Quick Start Guide

Contents

Preface 3

Chapter 1: Introduction 7

1.1 Overview 7

1.2 Features 7

1.3 Package Contents 7

1.4 Product Overview 8

1.5 Front Buttons & LED Indicators 9

Chapter 2: Installation 10

2.1 Cleaning the Monitor 10

2.2 Wiring Requirements 10

2.3 Connecting Peripherals 11

2.4 Connectors Pin Assignment 11

2.5 Connecting to the Source of Power 14

Chapter 3: Getting Started 15

3.1 Turning On Your Device 15

3.2 Adjusting the LCD DisplayBrightness 15

3.3 Turning Off the Device 15

Chapter 4: Mounting Solution 16

4.1 Panel Mount 16

4.2 VESA Mount 17

Chapter 5: Operating the Device 19

5.1 Capacitive Touch Keys 19

5.2 Plus/ Minus Keys 20

5.3 Function Key 21

5.4 Touch Lock 21

Appendix 22

Appendix A: Hardware Specifications 22

Preface

No part of this document may be reproduced, copied, translated, or transmitted in any form or

by any means, electronic or mechanical, for any purpose, without the prior written permission

of the original manufacturer.

Trademark Acknowledgement

Brand and product names are trademarks or registered trademarks of their respective owners.

Disclaimer

We reserve the right to make changes, without notice, to any product, including circuits and/or

software described or contained in this manual to improve design and/or performance. We

assume no responsibility or liability for the use of the specified product(s) conveys no license

or title under any patent, copyright, or masks work rights to these products, and make no

representations or warranties that these products are free from patent, copyright, or mask work

right infringement unless otherwise specified. Applications that are described in this manual

are for illustration purposes only. We make no representation or guarantee that such a request

will be suitable for the specified use without further testing or modification.

Warranty

Our warranty guarantees that each of its products will be free from material and workmanship

defects for a period of one year from the invoice date. If the customer discovers a defect, we

will, at his/her option, repair or replace the defective product at no charge to the customer,

provide it is returned during the warranty period of one year, with transportation charges

prepaid. The returned product must be appropriately packaged in its original packaging to

obtain warranty service. If the serial number and the product shipping data differ by over 30

days, the in-warranty service will be made according to the shipping date. In the serial

numbers, the third and fourth two digits give the year of manufacture, and the fifth digit means

the month (e. g., with A for October, B for November, and C for December).

For example, the serial number 1W18Axxxxxxxx means October of year 2018.

Customer Service

We provide a service guide for any problem by the following steps: First, visit the website of

our distributor to find the updated information about the product. Second, contact with your

distributor, sales representative, or our customer service center for technical support if you

need additional assistance.

You may need the following information ready before you call:

•Product serial number

•Software (OS, version, application software, etc.)

•Description of the complete problem

•The exact wording of any error messages

In addition, free technical support is available from our engineers every business day. We are

always ready to give advice on application requirements or specific information on the

installation and operation of any of our products.

4 R19IK3S-67FTP(HB) Quick Start Guide

Advisory Conventions

Four types of advisories are used throughout the user manual to provide helpful information or to

alert you to the potential for hardware damage or personal injury. These are Notes, Important,

Cautions, and Warnings. The following is an example of each type of advisory.

Note:

A note is used to emphasize helpful information

Important:

An important note indicates information that is important for you to know.

Caution A Caution alert indicates potential damage to hardware and explains how

to avoid the potential problem.

Attention Une alerte d’attention indique un dommage possible à l’équipement et

explique comment éviter le problème potentiel.

Warning!

An Electrical Shock Warning indicates the potential harm from electrical

hazards and how to avoid the potential problem.

Avertissement!

Un Avertissement de Choc Électrique indique le potentiel de

chocs sur des emplacements électriques et comment éviter ces problèmes.

Safety Information

Warning! Always completely disconnect the power cord from your chassis

whenever you work with the hardware. Do not make connections while the power

is on. Sensitive electronic components can be damaged by sudden power surges.

Only experienced electronics personnel should open the PC chassis.

Avertissement!

Toujours débrancher le cordon d’alimentation du chassis

lorsque vous travaillez sur celui-

ci. Ne pas brancher de connections lorsque

l’alimentation est présente. Des composantes électroniques sensibles peuvent être

endommagées par des sauts d’alimentation. Seulement du personnel expérimenté

devrait ouvrir ces chassis.

Caution

Always ground yourself to remove any static charge before touching the

CPU card. Modern electronic devices are very sensitive to static electric charges.

As a safety precaution, use a grounding wrist strap at all times. Place all electronic

components in a static-dissipative surface or static-shielded bag when they are not

in the chassis.

Attention

Toujours verifier votre mise à la terre afin d’éliminer toute charge

statique avant de toucher la carte CPU. Les équipements électroniques moderns

sont très sensibles aux décharges d’

électricité statique. Toujours utiliser un

bracelet de mise à la terre comme précaution. Placer toutes les composantes

électroniques sur une surface conçue pour dissiper les charge, ou dans un sac

anti-statique lorsqu’elles ne sont pas dans le chassis.

For your safety carefully read all the safety instructions before using the device. Keep this user

manual for future reference.

•Always disconnect this equipment from any AC outlet before cleaning. Do not use liquid or

Earth Ground The Protective Conductor Terminal (Earth Ground) symbol

indicates the potential risk of serious electrical shock due to improper grounding.

Mise à le terre ! Le symbole de Mise à Terre indique le risqué potential de choc

électrique grave à la terre incorrecte.

Preface

spray detergents for cleaning. Use a damp cloth.

•For pluggable equipment, the power outlet must be installed near the equipment and must

be easily accessible.

•Keep this equipment away from humidity.

•Put this equipment on a reliable surface during installation. Dropping it or letting it fall

could cause damage.

•The openings on the enclosure are for air convection and to protect the equipment from

overheating.

•Do not cover the openings.

•Before connecting the equipment to the power outlet, make sure the voltage of the power

source is correct.

•Position the power cord so that people cannot step on it. Do not place anything over the

power cord.

•If the equipment is not used for a long time, disconnect it from the power source to avoid

damage by transient over-voltage.

•Never pour any liquid into an opening. This could cause fire or electrical shock.

•Never open the equipment. For safety reasons, only qualified service personnel should

open the equipment.

•All cautions and warnings on the equipment should be noted.

•Do not leave this equipment in an uncontrolled environment where the storage

temperature is below -20°C (-4°F) or above 60°C (140°F). It may damage the

equipment.

Caution

Use the recommended mounting apparatus to avoid risk of

injury.

Attention Utiliser l’appareil de fixation recommandé pour éliminer le

risque de blessure.

Warning! Only use the connection cords that come with the product. When in

doubt, please contact the manufacturer.

Avertissement! Utiliser seulement les cordons d’alimentation fournis

avec le produit. Si vous doutez de leur provenance, contactez le

manufacturier.

Warning! Always ground yourself against electrostatic damage to the device.

Avertissement! Toujours vérifier votre mise à la terre afin que

l’équipement ne se décharge pas sur vous.

•Cover workstations with approved anti-static material. Use a wrist strap connected to a

work surface and properly grounded tools and equipment.

•Use anti-static mats, heel straps, or air ionizer for added protection.

•Avoid contact with pins, leads, or circuitry.

•Turn off power and input signals before connecting test equipment.

•Keep the work area free of non-conductive materials, such as ordinary plastic assembly

aids and Styrofoam.

•Use filed service tools, such as cutters, screwdrivers that are conductive.

•Always put drivers and PCB's component side on anti-static foam.

General Guideline

It is recommended to reboot the device when some functions are defect or inactive. If it

still can't solve the problems, please contact your dealer or agent.

6 R19IK3S-67FTP(HB) Quick Start Guide

Important Information

Federal Communications Commission Radio Frequency Interface Statement

This device complies with part 15 FCC rules.

Operation is subject to the following two conditions:

This device may not cause harmful interference.

This device must accept any interference received including

interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a class "B" digital

device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is likely

to cause harmful interference in which case the user will be required to correct the interference

at him own expense.

EC Declaration of Conformity

This equipment is in conformity with the requirement of the following EU

legislations and harmonized standards. Product also complies with the

Council directions.

Electromagnetic Compatibility Directive (2014/30/EU)

•EN55024: 2010 EN 55022: 2010 Class B

oIEC61000-4-2: 2009

oIEC61000-4-3: 2006+A1: 2007+A2: 2010

oIEC61000-4-4: 2012

oIEC61000-4-5: 2014

oIEC61000-4-6: 2013

oIEC61000-4-8: 2010

oIEC61000-4-11: 2004

•EN55022: 2010/AC:2011

•EN61000-3-2:2014

•EN61000-3-3:2013

Low Voltage Directive (2014/35/EU)

•EN 60950-1:2006/A11:2009/A1:2010/A12:2011/ A2:2013

7Chapter 1: Introduction

Chapter 1: Introduction

1.1 Overview

Winmate 19" G-WIN Rugged Panel PC R19IK3S-67FTP(HB) features high-performance and low

power consumption Intel® Core i5-7200U 3.1 GHz processor with the fanless thermal system.

The 19" 1280 x 1024-pixel screen with up to 1000 nits brightness and optical bonding technology

offers sunlight readability. In terms of wireless connectivity, the R19IK3S-67FTP(HB) features

optional WLAN integration. The rugged panel PC is compliant with MIL-STD-810G military

standard for shock and vibration. The robust design fits the demands for every harsh

environment applications such as logistics, transportation/ fleet management, heavy vehicles,

utility, and outdoor usage.

1.2 Features

•Sealed Full IP67 Design

•Intel® Core i5-7200U 2.5GHz (turbo to 3.1 GHz)

•19-inch sunlight viewable 400 nits LCD panel (Optional for 1000 nits high brightness)

•-10 to 60°C operating temperature

•Fanless, streamlined enclosure for highly efficient heat dissipation

•Touch screen control button to enable/disable touch screen interface

•Rugged front anti-impact design

•Front control membrane keys Lockable by software

•Optical bonding with panel & touch screen to increase the clarity and transparency

1.3 Package Contents

Before using the R19IK3S-67FTP(HB) panel PC, please make sure that all the items listed below

are present in your package.

Standard Packing List:

Panel PC

Manual & Driver CD

9-36V DC Power

Cable

RS-232/422/485

Cable

USB 2.0 Cable LAN Cable USB 2.0 A Type

Cable

8 R19IK3S-67FTP(HB) Quick Start Guide

1.4 Product Overview

Unit: mm

Dimensions: 457.7 x 381.7 x 111

No.

Description

1 1 x IP67 USB 2.0 A Type with cover

2 1 x IP67 LAN with RJ45 Connector

3 1 x IP67 USB 2.0 Connector

4 1 x IP67 RS232/422/485

5 1 x IP67 9~36V DC

9Chapter 1: Introduction

1.5 Front Buttons & LED Indicators

Front Buttons & LED Indicators are located at the front side of the R19IK3S-67FTP(HB) panel

PC.

Front Buttons

Button

Function

Power on/off.

Increase the brightness.

Decrease brightness.

Suspend the touch function temporarily.

Programmable function key configured by FunctionKeys Utility.

LED Indicators

LED Indicator

Function

PWR

Lights up when connected to the source of power.

HDD

Lights up when the HDD is working.

Heater

Lights up when the heater (if equipped) is turned on.

LAN1

Lights up when the LAN1 is working.

LAN2

Lights up when the LAN2 is working.

CLEAN

When the Clean button is pressed, the Touch power will be

turned off, and the Clean LED will be on at the same time

Press the Clean button again to turn on the touch power will be

turned on and the Clean LED will dim.

WLAN

Lights up when the WLAN (if equipped) is working.

10 R19IK3S-67FTP(HB) Quick Start Guide

Chapter 2: Installation

2.1 Cleaning the Monitor

Before cleaning:

• Make sure the device is turned off.

• Disconnect the power cable from any AC outlet.

When cleaning:

• Never spray or pour any liquid directly on the screen or case.

• Wipe the screen with a clean, soft, lint-free cloth. This removes dust and other particles.

• The display area is highly prone to scratching. Do not use ketene type material (ex.

Acetone), Ethyl alcohol, toluene, ethyl acid, or Methyl chloride to clear the panel. It may

permanently damage the panel and void the warranty.

• If it is still not clean enough, apply a small amount of non-ammonia, non-alcohol based

glass cleaner onto a clean, soft, lint-free cloth, and wipe the screen.

• Do not use water or oil directly on the display screen. If droplets are allowed to drop on

the screen, permanent staining or discoloration may occur.

2.2 Wiring Requirements

The following common safety precautions should be observed before installing any electronic

device:

•Strive to use separate, non-intersecting paths to route power and networking

wires. If power wiring and device wiring paths must cross, make sure the wires

are perpendicular at the intersection point.

•Keep the wires separated according to the interface. The rule of thumb is

that wiring that shares similar electrical characteristics may be bundled

together.

•Do not bundle input wiring with output wiring. Keep them separate.

•When necessary, it is strongly advised that you label wiring to all devices in the system.

ATTENTION

•Do not run signal or communication wiring and power wiring in the same

conduit. To avoid interference, wires with different signal characteristics (i.e.,

different interfaces) should be routed separately.

•Be sure to disconnect the power cord before installing and/or wiring your device.

•Verify the maximum possible current for each wire gauge, especially for

the power cords. Observe all electrical codes dictating the maximum

current allowable for each wire gauge.

•If the current goes above the maximum ratings (80 W), the wiring could

overheat, causing serious damage to yourequipment.

•Be careful when handling the unit. When the unit is plugged in, the internal

components generate a lot of heat which may leave the outer casing too hot to

touch.

Otros manuales para G-Win Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Panel táctil de Winmate

Winmate

Winmate R10FA3S-GST2 Manual de usuario

Winmate

Winmate ATEX R19IHAT-66EX-T Manual de usuario

Winmate

Winmate R19IK3S-SPM169 Manual de usuario

Winmate

Winmate R15IT3S-SPC369 Manual de usuario

Winmate

Winmate W10IB3S-PCH2AC-PoE S-Series Manual de usuario

Winmate

Winmate R15IH3S-SPC3 Manual de usuario

Winmate

Winmate R15ID3S-65A1FTE Manual de usuario

Winmate

Winmate W07IB3S-POT1 Manual de usuario

Winmate

Winmate W10IB3S-PCH2AC-PoE S-Series Manual de usuario

Winmate

Winmate R05FA3S-OFD1HMHB Manual de usuario

Winmate

Winmate R10IB3S-67T2 Manual de usuario

Winmate

Winmate R17IK3S-RKA1ML Manual de usuario

Winmate

Winmate W10IB3S-EHH2 Manual de usuario

Winmate

Winmate Military Series Manual de usuario

Winmate

Winmate R05FA3S-IPD1HMHB Manual de usuario

Winmate

Winmate R19IHAT-66EX Manual de usuario

Winmate

Winmate W22IK3S-SPA3 Manual de usuario

Winmate

Winmate W10IB3S-PCH2AC-PoE S-Series Manual de usuario

Winmate

Winmate W19IB3S-CHA1 Manual de usuario

Winmate

Winmate T5-series Manual de usuario

Winmate

Winmate R10IB3S-67T2 Instrucciones de funcionamiento y mantenimiento

Winmate

Winmate W10IB3S-GSH2 Manual de usuario

Winmate

Winmate W07L100-GCM1 Manual de usuario

Winmate

Winmate P-CAP SERIES Manual de usuario

Manuales populares de Panel táctil de otras marcas

FlowLine

FlowLine Data loop Manual de usuario

ALPEX

ALPEX AEx-8 P Series Manual de usuario

Ltech

Ltech E5S Manual de usuario

Harman

Harman AMX MODERO S MSD-701-L2 Manual de usuario

Acnodes

Acnodes PC 1150 Manual de usuario

AIS

AIS IP10IA99 series Manual de usuario

IBASE Technology

IBASE Technology ASTUT-152-RE1S Manual de usuario

YASKAWA

YASKAWA TP 610C Manual de usuario

B&R

B&R Power Panel C Series Manual de usuario

Beijer Electronics

Beijer Electronics X2 control Manual de usuario

AXIOMTEK

AXIOMTEK GOT321W-521 Manual de usuario

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Manual de usuario

Qomo

Qomo QIT1386 Manual de usuario

DFI

DFI KS104-CD Manual de usuario

AMX

AMX AXP-PPC Guía

Sartorius

Sartorius X3 PR 5410 Manual de usuario

AMX

AMX Modero X Series Manual de usuario

Advantech

Advantech TPC-30 Series Manual de usuario
