Socket CHS 7Qi Manual de usuario
Model shown: CHS 7Qi
Bluetooth Barcode Scanner
CHS 7Qi, 7Xi, 7XiRx
www.socketmobile.com
SerieS 7
2D IMAGER QUICKSTART GUIDE
PACKAGE CONTENTS PRODUCT INFORMATION
© 2010-2015 Socket Mobile, Inc. All rights reserved. Socket, the Socket logo, and
SocketScan are registered trademarks or trademarks of Socket Mobile, Inc. The Bluetooth
word mark and logo are registered trademarks of the Bluetooth SIG, Inc. USA, and any
use by Socket Mobile, Inc. is under license. All other trademarks and trade names con-
tained herein may be those of their respective owners.
mobile
®
mobile
®
mobile
®
mobile
®
mobile
®
mobile
®
mobile
®
mobile
®
mobile
®
Rechargeable
Li-ion battery pack
(installed)
AC adapter* & USB to
DC plug cable
*Use the plug that is
regionally appropriate
Lanyard
CHS 7Qi
Thank you for choosing Socket Mobile!
Let’s get started!
3
*Also used for keyboard Pop-up (HID Mode only)
Scanner head
Product label
Lanyard
Blue/Green/Red
LED
Trigger button
Power button*
DC-in connector
Battery door
Twist-lock
(horizontal/unlocked)
Twist-lock
(vertical/locked)
Pins for
charging
cradle
SCANNER SETUP
Lock Unlock
Battery door removal
Unlock the Battery door by using a
thin coin to turn the lock under the
CHS to a horizontal position (turn
90 degrees).
Attach the Lanyard (optional)
Detach the string loop of the tether
from the lanyard. Then feed the
string loop through the slot in the Twistlock
and then through the end of the loop.
Pull tight so the string loop is secure to the
Twist-lock, Reattach the string loop to the
tether from the Lanyard.
If desired, attach the tether to a lanyard
or belt.
CHARGE THE BATTERY
Charge the CHS
The CHS must be fully charged be-
fore rst use. Please allow 4 hours
uninterrupted charging for the
initial battery charge.
For the 7Xi or 7XiRx, lift the rubber ap to
access the power connector.
• Red LED = Charging
• Green LED = Fully charged
Charging from a computer USB port
is not reliable and not recommend-
ed.
Socket Mobile offers a Charging Cradle
(optional Accessory/sold separately) which
is a convenient holder
that charges the scanner when not in use.
Cradle Sku#
CHS 7Qi: AC4054-1381
CHS 7Xi: AC4055-1382
CHS 7XiRx: AC4056-1383
4 5
BASIC FUNCTIONALITY
•Powering On:
Press and hold down the small
power button until the LED
turns Blue and the CHS beeps
twice (low-high).
•Powering Off/Disconnecting:
Press and hold down the small
power button until the CHS beeps
twice (high-low).
BASIC FUNCTIONALITY (CONTINUED)
1D
Aim the scan beam straight
across the entire barcode.
2D
Aim at the center.
Scanning Barcodes:
After connecting the CHS to your device, open an application and put
the cursor where you want to enter data.
Hold the CHS about 4 inches (10 cm) from the barcode and press and
hold the trigger button. Position the CHS so the Red beam covers the
entire width of the barcode. Keep your hand steady while scanning.
By default, the CHS will beep and vibrate, and the LED will ash
Green to conrm that data was decoded and sent to the device.
67
Power button
CONNECTION MODES (CONTINUED)
CONNECTION MODES
HID Keyboard Emulation mode (default)
In HID mode the CHS emulates a keyboard. This is a universal connection
method and will work with any application that has a text eld.
The application receives the data input from the CHS. The CHS includes
a keyboard pop-up feature so you can disable the CHS and accept data
input from the onscreen keyboard on the device. Pages 10-14 provides
the connection steps using HID mode.
SerialPortProle(SPP)
Highly recommended, allows two-way communications with Android,
BlackBerry and Windows. SocketScan 10 software installation is re-
quired.
MAC OS devices are connected using HID mode.
iOS devices are connected using either iOS mode or HID mode, but
not both together.
The CHS is connected to your iOS device using one of the following
modes:
1. iOS mode
2. HID Keyboard Emulation mode (default)
3. Serial Port Prole (SPP)
iOS mode
iOS mode is used with a Scanner-enabled Application. Scanner controls
are embedded in the Application to provide better performance, secu-
rity, features, and domain-specic capabilities.
If you purchased a Scanner-enabled Application on the Apple App Store
(or through the Apple Volume Purchase Program for Business) that
features integrated support for the CHS, we recommend you install that
Application on your device and follow the Application instructions to
connect with the CHS. If the connection steps are not documented in
the Application, please see pages 15-16 for the connection steps using
iOS mode.
Please visit the Socket Mobile App Store to conrm your Scanner-en-
abled
Application supports the CHS.
http://www.socketmobile.com/appstore
98
HID (KEYBOARD EMULATION) MODE
10
To pair the CHS with the Apple device: (required only the rst time
you connect)
1. Power on the CHS.
2. Make sure the CHS is set to HID keyboard mode (default). If needed,
scan this barcode to set it to the correct scanner mode. The CHS will
beep 3 times.
3. Enable Bluetooth on the Apple device. A Bluetooth device search will
begin.
4. In the list of found devices, select Socket 7Xi[xxxxxx]. If prompted,
tap Pair.
The characters in brackets are the last 6 characters of the
Bluetooth Address, which is labeled in the CHS battery
compartment.
5. After the CHS connects and is ready to scan barcodes, it will beep
once.
HID (KEYBOARD EMULATION) MODE
11
IMPORTANT! Follow the instructions below ONLY if you are
using a compatible application developed with SocketScan 10
SDK!
To view a selected listing of compatible apps developed with
SocketScan 10 SDK, please visit: http://www.socketmobile.com/
appstore.
The setup instructions may vary depending on your application.
Follow the instructions provided by your software application
developer.
To install the software:
1. Install a compatible application onto your device that was developed
with SocketScan 10 SDK. Follow the installation instructions from the
application developer.
2. To Pair the CHS with the Apple device: (required only the rst time
you connect).
3. Power on the CHS Scan this barcode to change the CHS to iOS mode.
The CHS will beep 3 times.
4. Open the application.
5. Enable Bluetooth on the Apple device. A Bluetooth device search will
begin.
HID (KEYBOARD EMULATION) MODE HID (KEYBOARD EMULATION) MODE (CONTINUED)
12
To pair the CHS with the Apple device in HID mode: (required only the
rst time you connect).
1. Power on the CHS. The Blue LED should blink every second indicating
Bluetooth is on but not Connected.
2. Turn Bluetooth on for the Apple device. Go to Settings > Bluetooth.
A Bluetooth Devices search will begin.
An iOS device is always Discoverable when in the Bluetooth
menu is active. A MAC OS device provides an option to turn
Discoverable On or Off. Conrm the MAC OS device is Discover-
able.
3. Tap Socket 7Xi [xxxxxx] in the list of Devices found. After a few sec-
onds the “Not Paired” status will change to “Connected” and the CHS
Blue LED will blink every 3 seconds indicating it is Connected.
The characters in brackets are the last 6 characters of the
Bluetooth Address. The full Bluetooth address is printed in the
Product label (remove the battery door).
You are now ready to scan barcodes, see instructions on page 7.
13
Keyboard Pop-up Enable
The CHS emulates the keyboard in HID mode. So scanned barcode data
will be input into the text eld. The following steps show how to access
the onscreen keyboard while connected to the CHS in HID mode.
1. Make sure the CHS is connected to your Apple device in HID mode.
2. Open your application and place the cursor where you want to enter
data.
3. Quickly double-press the power button of the CHS (like
doubleclicking a mouse) to open or close the onscreen keyboard. The
CHS will beep once as conrmation.
To connect to a new Apple device, you must rst unpair the CHS
and remove the CHS from the Bluetooth list in your device. See
page 23.
IOS MODE - SCANNER-ENABLED APP IOS MODE - SCANNER-ENABLED APP (CONTINUED)
If you are using a Scanner-enabled Application, follow their instructions
to connect with the CHS. Many applications include these steps and
barcodes in the set-up procedure.
If you are using an Application that connects to the CHS using HID
Keyboard Emulation mode, follow the instructions on pages 10-14. iOS
mode should not be used.
If you are using the CHS with an iOS device and a Scanner-enabled
Application that does not provide instructions to connect with the CHS,
please use the following steps.
1. Power on the CHS and scan this barcode. The CHS will beep 3 times.
14
2. Turn Bluetooth on for the Apple device. Go to Settings > Bluetooth. A
Bluetooth Devices search will begin.
3. Tap Socket Socket 7Xi [xxxxxx] in the list of Devices found. After
a few seconds the “Not Paired” status will change to “Connected”
and the CHS Blue LED will blink every 3 seconds conrming the
connection.
The characters in brackets are the last 6 characters of the
Bluetooth Address. The full Bluetooth address is printed in the
Product label (remove the Battery door).
4. Open the Scanner-enabled Application. The CHS will beep once
indicating that the application is in control and you are ready to scan.
It should now be connected to the CHS.
You are now ready to scan barcodes with the Scanner-enabled
Application, see instructions on page 7.
15
ANDROID OS SPP MODE ANDROID OS SPP MODE
The instructions below are based on the Asus Nexus 7 running
Android OS 4.2. Instructions for other devices may slightly differe.
For Bluetooth HID instructions, please see the User’s Guide.
To install the software: (required only the rst time you connect)
1. If you installed barcode scanning software for
your device camera, scan this barcode to
launch the SocketScan 10 page in Google Play.
Alternatively, open Google Play and search for
SocketScan 10 Keyboard Wedge Software using
the keyword “Socket”.
2. Follow the on-screen instructions to download and install SocketScan
10 software. If prompted, allow the app to access Bluetooth settings/
USB storage/ SD card contents.
3. If SocketScan 10 prompts you to turn on Bluetooth, touch Allow.
4. You will be prompted to set SocketScan 10 as the keyboard language.
Touch Back .
5. Touch Home | Apps | Settings | Language & input.
6. Under Keyboard & Input Methods, select SocketScan 10. In the same
settings you can congure the keyboard language or congure the
volume up button to trigger a scan. Touch Back .After the CHS pairs
and is ready to scan barcodes, it will beep once. The icon at the top
of the screen will also change (see below). Touch Back .
7. In SocketScan 10, touch Menu | Input Method. Select SocketScan 10.
Touch Back .
To pair and connect the CHS and Android device: (required only the rst
time you connect)
1. In SocketScan 10, touch Menu | Socket EZ Pair.
2. Touch On screen. Touch 2D Scanner.
3. Power on the CHS. Scan the barcode that appears on the screen.
4. Your device will automatically try to pair with the CHS. When prompt-
ed with a Bluetooth Pairing Request, touch Pair.
5. After the CHS connects and is ready to scan barcodes, it will beep
once. Touch Back.
6. The SocketScan 10 icon at the top of the screen will change to indi-
cate the connection.
7. if you have not registered your CHS, a registration icon will appear on
top of the screen. If desired, swipe it down to open the software and
register your CHS.
Now you are ready to scan barcodes, see instructions on page 7.
16 17
WINDOWS PC SPP MODE
To install the software and congure a COM port:
Windows 7/8: Make sure you have administrative privileges to
install software.
1. Download the latest SocketScan 10 software from:
http://www.socketmobile.com/support/downloads/data-collection/
series7/ss10/
2. Follow the on-screen instructions to install the software. In the last
screen, click Finish.
3. In SocketScan Settings, select an incoming Bluetooth serial COM port.
Click OK.
Click Ports to create a new incoming COM port or identify an
incoming COM port.
To pair the CHS with the PC: (required only the rst time you connect)
1. Make sure Bluetooth is enabled on your PC.
2. Make sure SocketScan 10 is running. Click on the SocketScan 10 desk-
top icon.
3. Click on the SocketScan 10 icon in the task tray. In the pop-up menu,
click Socket EZ Pair.
4. Click On screen. Click 2D Scanner
5. Power On screen. Click 2D Scanner.
6. The PC will automatically try to pair with the CHS. If prompted to al-
low the pairing, click Yes. If prompted for a passkey, enter 0000 (four
zeroes).
18
WINDOWS PC SPP MODE
7. After the CHS connects, it will beep once. Close Socket EZ Pair.
8. If you have not registered the CHS, a registration screen will ap-
pear. If desired, register your CHS.
9. The task tray icon will change to indicate the connection.
Now you are ready to scan barcodes, see instructions on page 4.
To connect to a new device, you must rst unpair the CHS. See
page 23.
19
Otros manuales para CHS 7Qi
1
Este manual sirve para los siguientes modelos
2
Tabla de contenidos
Otros manuales de Lector de código de barras de Socket
Socket
Socket SOCKETSCAN S800 Manual de usuario
Socket
Socket CHS Series 7 Manual de usuario
Socket
Socket DURASCAN D750 Manual
Socket
Socket CompactFlash Scan Card Series 5 Manual de usuario
Socket
Socket DuraScan D745 Manual de usuario
Socket
Socket Socketscan S370 Hoja de especificaciones
Socket
Socket CHS 7Ci Manual de usuario
Socket
Socket 9M Manual de usuario
Socket
Socket SD Scan Card 3E Manual de usuario
Socket
Socket CHS Series 7 Manual de usuario
Socket
Socket D820 Manual de usuario
Socket
Socket CHS Series 7 Manual de usuario
Socket
Socket Cordless Ring Scanner Series 9 Manual de usuario
Socket
Socket CHS 7Qi Manual de usuario
Socket
Socket Gun Scanner (GS) 2X (Xtreme Performance) Manual de usuario
Socket
Socket DURASCAN D740 Manual de usuario
Socket
Socket CHS 7Mi Manual de usuario
Socket
Socket SocketScan S550 Manual de usuario
Socket
Socket CHS 7Ci Manual de usuario
Socket
Socket 7Qi Manual de usuario
