Outback ONYX 4 Burner Manual de usuario

WARNING

• For outdoor use only.

• Read instructions before using the appliance. Failure to follow instructions could

result in death, serious bodily injury, and/or property loss.

• Warning: accessible parts may be very hot. Keep young children away.

• Do not move the appliance during use.

• Turn off the gas supply at the gas cylinder after use.

• Any modification of the appliance, misuse, or failure to follow the instructions

may be dangerous and will invalidate your warranty. This does not affect your

statutory rights.

• Retain these instructions for future reference.

• Leak test your barbecue annually. Check the hose connections are tight and leak

test them each time you reconnect the gas bottle.

FOR YOUR SAFETY

If you smell gas:

1. Shut off gas to the appliance.

2. Extinguish any open flame.

3. Open barbecue lid or hood.

4. If odour continues, discontinue use and

contact your local dealer.

FOR YOUR SAFETY

1. Do not store or use petrol or other flammable

vapours or liquids in the vicinity of this or any

other appliance.

2. A gas cylinder not connected for use shall not

be stored in the vicinity of this or any other

appliance.

Photographs are not to scale.

Specifications subject to change

without prior notice.

Assembly and Operating Instructions for

ONYX 4 Burner with Side Burner Gas Barbecue

0359

　Pre-Assembled Component

HQuantity varies according to model purchased

sAppearance, size, and construction may differ according to model purchased

CODE PART QTY ONYX 4 Burner with Side Burner

HOOD

A1 Hood (pre-assembled to body) 1 3　

A2 Hood Handle 1 3　

A3 Heat Indicator Assembly 1 3　

A4 WarmingRack 1 3

BODY

B1 Barbecue Body 1 3

B2 Burner 4 3

B3 Control Panel 1 3　

B4 Knob (four pre-assembled) 5 3

B5 Side Burner Valve/Hose/Regulator Assembly 1 3　

B6 Flame Tamer 2 3

B7 Cooking Grill 1 3

B8 Cooking Griddle 1 3

B9 Ignition Button (one pre-assembled) 2 3

B10 Drip Tray Left Bracket 1 3

B11 Drip Tray Right Bracket 1 3

B12 Drip Tray Handle 1 3　

B13 Drip Tray 1 3

TROLLEY

C1 Side Burner 1 3

C2 Side Burner Grid 1 3

C3 Side Burner Shelf 1 3

C4 Knob Bezel (four pre-assembled) 5 3

C5 Side Burner Drip Tray 1 3

C6 Side Shelf 1 3

C7 Cabinet Top Panel 1 3

C8 Cabinet Left Panel 1 3

C9 Cabinet Right Panel 1 3

C10 Cabinet Back Panel 1 3

C11 Cabinet Bottom Panel 1 3

C16 Door 2 3

C17 Door Retaining Spring Axle 2 3

C18 Door Retaining Axle 2 3

C19 Door Catch 2 3

C20 Wheel 2 3

C21 Short Axle 2 3

C22 Hubcap 2 3

C23 Lockable Caster 2 3

HARDWARE

D1 ST4.0X10 Screw 16 3

D2 M4x10 Bolt 4 3

D3 M5x15 Bolt 4 3

D4 M5x35 Bolt 8 3

D5 Ø5 Washer 4 3

D6 M5 Nut 12 3

D7 M6x15 Bolt 12 3

D8 M6x80 Bolt 8 3

D9 M6 Nut 8 3

D10 Body Spacer 8 3

D11

Wi N t

C12 Left Front Leg 1 3

C13 Left Rear Leg 1 3

C14 Right Front Leg 1 3

C15 Right Rear Leg 1 3

Parts List

Quantities vary according to model purchased. Specifications subject to change without prior notice.

Parts Diagrams

Quantities vary according to model purchased. Specifications subject to change without prior notice.

B10

C20 C23

B11

B12

B13

C8 C9

C10

C11

C12 C13

C14

C15

C16C17

C18

C19

C21

C22

Assembly

IMPORTANT!

• Tools Required: Medium size flat blade or Phillips/Crosspoint screwdriver, adjustable spanner or metric

spanner set

• The assembly of this barbecue requires 3 people.

• Carefully unpack the parts from the box and remove all internal packaging before commencing

assembly. All loose items including the grills, flame tamers and warming rack must be removed from the

body.

• Whilst every care is taken in the manufacture of this product, care must be taken during assembly in

case sharp edges are present.

Attach the Left and Right Legs (C12, C13, C14, C15) to the Cabinet Bottom Panel (C11) using

the M5x35 Bolts (D4) and M5 Nuts (D6) as shown. (The bottom panel with door catch

assembling hole should be located at front after assembly)

Insert Short Axles (C21) through Wheels (C20), Axle Washers (D12) and guide holes in left legs and

secure with M8 Nuts (D13). Screw the Lockable Caster (C23) into the end of the right legs and hand

tighten until it stops. Snap the Hubcaps (C22) into wheels.

L/H R/H

Attach the Cabinet Back Panel (C10) onto rear legs using ST4.0x10 Screws (D1) as shown.

Attach the Cabinet Left Panel (C8) and Cabinet Right Panel (C9) onto the bottom panel

and legs using ST4.0x10 Screws (D1) as shown.

L/H R/H

ST4.0x10 Screw

L/H R/H

Attach the Cabinet Top Panel (C7) onto left panel and right panel using M6x15 Bolts

(D7) and M6 Nuts (D9).

Attach the Door Catches (C19) to the top and bottom panels using M6x15 Bolts (D7) and

M6 Nuts (D9).

Attach the Side Shelf (C6) and Side Burner Shelf (C3) using M6x15 Bolts (D7) as shown.

NOTE: Side table supports have slots for easy assembly.

Align guide holes in side table supports, holes in legs, then insert eight M6x80 Bolts

(D8) through the aligned holes, Body Spacers (D10). Do not let the bolts over the

spacers, it is easy to attach body to cabinet assembly.

Place hood and body assembly onto position, screw the bolts through both sidewall of

body and secure with Wing Nuts (D11) as shown. (Three people required)

R/H L/H

Body Spacer

Attach the valve of Side Burner Valve/Hose/Regulator Assembly (B5) and Knob Bezel (C4)

onto side burner shelf using M4x10 Bolts (D2) as shown.

Attach Drip Tray Right Bracket (B11) onto body using M5x15 Bolts (D3) , Ø5 Washers (D5)

and M5 Nuts (D6) as shown. Repeat for Drip Tray Left Bracket (B10). Make sure that the

tabs which stop drip tray should be located at front.

M5 Nut

Unscrew the retaining nut from Ignition Button (B9), insert the button through the hole beside

side burner knob and secure with the retaining nut.

Connect the ignition wire onto end of ignition button.

Feed the venturi tube of the Side Burner (C1) through the hole in the side burner shelf, and

slide the end of the venturi tube over the tip of the valve. Fix side burner onto bottom of side

burner shelf using a M4x10 Bolt (D2) as shown.

Place the Side Burner Grid (C2) onto the burner.

Press the Burner Knob (B4) on the vale stem.

Attach Side Burner Drip Tray (C5) onto bottom of side burner shelf using a M4x10 Bolt (D2).
