Nortel ALTEON OS BMD00009 Manual de usuario
2350 Mission College Blvd.
Suite 600
Santa Clara, CA 95054
www.bladenetwork.net
Alteon OS
BBI Quick Guide
Nortel 10Gb Uplink Ethernet Switch Module for IBM BladeCenter®
Version 1.2
TM
Part Number: BMD00009, November 2007
Alteon OS BBI Quick Guide
2BMD00009, November2007
Copyright © 2007 Blade Network Technologies, Inc., 2350 Mission College Blvd., Suite 600, Santa Clara,
California, 95054, USA. All rights reserved. Part Number: BMD00009.
This document is protected by copyright and distributed under licenses restricting its use, copying,
distribution, and decompilation. No part of this document may be reproduced in any form by any means
without prior written authorization of Blade Network Technologies, Inc. Documentation is provided “as
is” without warranty of any kind, either express or implied, including any kind of implied or express
warranty of non-infringement or the implied warranties of merchantability or fitness for a particular
purpose.
U.S. Government End Users: This document is provided with a “commercial item” as defined by FAR
2.101 (Oct. 1995) and contains “commercial technical data”and “commercial software documentation” as
those terms are used in FAR 12.211-12.212 (Oct. 1995). Government End Users are authorized to use this
documentation only in accordance with those rights and restrictions set forth herein, consistent with FAR
12.211- 12.212 (Oct. 1995), DFARS 227.7202 (JUN 1995) and DFARS 252.227-7015 (Nov. 1995).
Blade Network Technologies, Inc. reserves the right to change any products described herein at any time,
and without notice. Blade Network Technologies, Inc. assumes no responsibility or liability arising from
the use of products described herein, except as expressly agreed to in writing by Blade Network
Technologies, Inc. The use and purchase of this product does not convey a license under any patent rights,
trademark rights, or any other intellectual property rights of Blade Network Technologies, Inc.
Originated in the USA.
Alteon OS, and Alteon are trademarks of Nortel Networks, Inc. in the United States and certain other
countries. Cisco®and EtherChannel®are registered trademarks of Cisco Systems, Inc. in the United States
and certain other countries. Any other trademarks appearing in this manual are owned by their respective
companies.
BMD00009, November 2007 3
Contents
Preface 5
Who Should Use This Book 6
Related Documentation 6
Typographic Conventions 7
How to Get Help 8
Chapter 1: Getting Started 9
Features 9
Requirements 10
Switch Set Up 10
IP Interfaces 10
Enabling/Disabling BBI Access 11
Web Browser Set Up 11
Starting the BBI 11
Chapter 2: Browser-Based Interface Basics 15
Toolbar 17
Context Tabs 17
Commands 18
Navigation Window 19
Forms Window 20
Message Window 20
Chapter 3: Configuring the Switch 21
Configuration Steps 22
Using the BBI to Load Switch Software 24
Chapter 4: Viewing Statistics 27
Steps for Displaying Statistics 28
Alteon OS BBI Quick Guide
4 Contents BMD00009, November 2007
Chapter 5: The Dashboard 29
Steps for Displaying Dashboards 30
BMD00009, November 2007 5
Preface
Alteon OS Browser-Based Interface (BBI) software is included with the Nortel 10Gb Uplink
Ethernet Switch Module (GbE Switch Module). The BBI software lets you use your Web
browser to access switch information and statistics, and to perform switch configuration via
the Internet.
This BBI Quick Guide provides an overview of how to access and use the Alteon OS Browser-
Based Interface.
Alteon OS BBI Quick Guide
6 Preface BMD00009, November 2007
Who Should Use This Book
This BBI Quick Guide is intended for network installers and system administrators engaged in
configuring and maintaining a network. It assumes that you are familiar with your GbE Switch
Module, your Web browser, Ethernet concepts, IP addressing, the IEEE 802.1d Spanning-Tree
Protocol, and SNMP configuration parameters.
Related Documentation
For documentation on installing the switch physically, see the Installation Guide for your
GbE Switch Module.
For details about the switch information, statistics, and configuration parameters available
using the Alteon OS BBI, see the Alteon OS Command Reference and Application Guide.
Alteon OS BBI Quick Guide
Preface 7BMD00009, November 2007
Typographic Conventions
The following table describes the typographic styles used in this book.
Table 1 Typographic Conventions
Typeface or
Symbol Meaning Example
AaBbCc123 This type is used for names of commands,
files, and directories used within the text. View the readme.txt file.
It also depicts on-screen computer output and
prompts. Main#
AaBbCc123 This bold type appears in command exam-
ples. It shows text that must be typed in
exactly as shown.
Main# sys
<AaBbCc123> This italicized type appears in command
examples as a parameter placeholder. Replace
the indicated text with the appropriate real
name or value when using the command. Do
not type the brackets.
To establish a Telnet session, enter:
host# telnet <IP address>
This also shows book titles, special terms, or
words to be emphasized. Read your User’s Guide thoroughly.
[ ] Command items shown inside brackets are
optional and can be used or excluded as the
situation demands. Do not type the brackets.
host# ls [-a]
Alteon OS BBI Quick Guide
8 Preface BMD00009, November 2007
How to Get Help
If you need help, service, or technical assistance, see the "Getting help and technical
assistance" chapter in the Nortel 10Gb Uplink Ethernet Switch Module for IBM BladeCenter
Installation Guide.
BMD00009, November 2007 9
CHAPTER 1
Getting Started
This chapter briefly describes the software features and requirements for the Alteon OS
Browser-Based Interface (BBI), and explains how to access the BBI start page.
Features
The network administrator can access switch configuration and monitoring functions through
the BBI, a Web-based switch management interface. The BBI has the following features:
Many of the same configuration and monitoring functions as the command-line interface
Intuitive and easy-to-use interface structure
Password protection
Nothing to install; the BBI is part of the Alteon OS switch software
Automatically upgraded with each new software release
NOTE – You can perform most configuration and monitoring tasks through the BBI.
For a comprehensive set of commands, use the command-line interface. Refer to Alteon OS
Command Reference for the Nortel 10Gb Uplink Ethernet Switch Module for
IBM BladeCenter.
Alteon OS BBI Quick Guide
10 Getting Started BMD00009, November 2007
Requirements
GbE Switch Module
Installed Alteon OS switch software
PC or workstation with network access to the switch’s management interface, as config-
ured using the management module
Frame-capable Web-browser software, such as the following:
Netscape Navigator 4.7x or higher
Internet Explorer 6.0x or higher
Mozilla FireFox 1.0.4 or higher
JavaScript enabled in your Web browser
Switch Set Up
Before you can access the BBI, minimal configuration is required on the GbE Switch Module.
IP Interfaces
At least one IP interface must be configured on the switch. This is configured from the man-
agement module and not the command-line interface. The management module assigns the
management IP address by default, starting at 192.168.70.127 for I/O module slot 1 through
192.168.70.130 for I/O module slot 4.
Each IP interface address provides a point of access for Alteon OS switch management. The
default management interface is 128, which allows access to Alteon OS switch management
via the management module network only.
For complete information about configuring IP interfaces, see your GbE Switch Module
Installation Guide.
