Novell GROUPWISE 8 - INTERNET AGENT Manual de usuario

Internet Agent

715

novdocx (en) 22 June 2009

Internet Agent

Chapter 45, “Configuring Internet Addressing,” on page 717

Chapter 46, “Configuring Internet Services,” on page 731

Chapter 47, “Managing Internet Access,” on page 763

Chapter 48, “Configuring the Internet Agent,” on page 785

Chapter 49, “Monitoring the Internet Agent,” on page 793

Chapter 50, “Optimizing the Internet Agent,” on page 817

Chapter 51, “Connecting GroupWise Systems and Domains Using the Internet Agent,” on

page 823

Chapter 52, “Using Internet Agent Startup Switches,” on page 831

716 GroupWise 8 Administration Guide

novdocx (en) 22 June 2009

Configuring Internet Addressing

717

novdocx (en) 22 June 2009

Configuring Internet Addressing

By default, GroupWise®uses a proprietary address format consisting of a user’s ID, post office, and

domain (userID.post_office.domain). However, when you install the GroupWise Internet Agent,

GroupWise also supports native Internet-style addressing consisting of a username and Internet

domain name (for example, userID@Internet_domain_name).

Internet-style addressing is the preferred addressing format if you are connected to the Internet,

because with Internet-style addressing, users have the same address within the GroupWise system as

they do outside the GroupWise system. For example, if John Smith’s address at Novell®is

jsmith@novell.com, this address can be used by users within the GroupWise system and users

external to the system.

To set up Internet addressing, you do the following:

Define Internet domain names for your GroupWise system. You can have one or more domain

names (for example, novell.com, gw.novell.com, and support.novell.com).

Set up the default Internet address format for use when displaying user addresses in the

GroupWise Address Book and sent messages. There are six formats that can be assigned at the

system, domain, post office, or user level. In addition, there is a free-form format that can be

used at the user level.

Designate the address formats that can be used to address messages to your GroupWise users.

There are five possible formats to choose from. You can allow all five formats, or only one.

Specify the default Internet Agent to be used when sending messages from your GroupWise

system to the Internet. This becomes your system’s default Internet Agent for outbound

messages sent from all domains; however, if you have multiple Internet Agents, you can

override this setting by assigning Internet Agents at the domain level.

The following sections help you plan and set up Internet addressing:

Section 45.1, “Planning Internet Addressing,” on page 717

Section 45.2, “Setting Up Internet Addressing,” on page 722

Section 45.3, “Transitioning from SMTP Gateway Aliases to Internet Addressing,” on

page 727

45.1 Planning Internet Addressing

The following sections help you prepare to set up Internet-style addressing for your GroupWise

system:

Section 45.1.1, “Internet Agent Requirement,” on page 718

Section 45.1.2, “Internet Agents Used for Outbound Messages,” on page 718

Section 45.1.3, “Internet Domain Names,” on page 718

Section 45.1.4, “Preferred Address Format,” on page 718

Section 45.1.5, “Allowed Address Formats,” on page 721

Section 45.1.6, “Override Options,” on page 722

718 GroupWise 8 Administration Guide

novdocx (en) 22 June 2009

45.1.1 Internet Agent Requirement

Internet addressing requires you to have the GroupWise Internet Agent installed in your GroupWise

system. The Internet Agent connects your GroupWise system to the Internet. To install the Internet

Agent, see “Installing the GroupWise Internet Agent” in the GroupWise 8 Installation Guide.

45.1.2 Internet Agents Used for Outbound Messages

Each domain in your GroupWise system must be assigned an Internet Agent for outbound messages.

A domain’s assigned Internet Agent handles all outbound messages sent by the domain’s users.

If your GroupWise system includes only one Internet Agent, that Internet Agent must be assigned to

all domains and is used for all outbound messages.

If your GroupWise system includes multiple Internet Agents, you must decide which Internet Agent

you want to be responsible for outbound messages for each domain. You must select one Internet

Agent as your system’s default Internet Agent, but you can override the default at each domain.

45.1.3 Internet Domain Names

You must associate at least one Internet domain (novell.com, gw.novell.com, support.novell.com, or

so forth) with your GroupWise system. These Internet domains need to exist in the domain name

service (DNS).

After you have associated Internet domains with your GroupWise system, all users in your system

can be addressed using any of the domains (for example, jsmith@novell.com,

jsmith@gw.novell.com, and [email protected]om). The addresses can be used both internally

and externally.

Preferred Internet Domain Name

You must assign each GroupWise user a preferred Internet domain. GroupWise uses the preferred

Internet domain name when constructing the e-mail address that are displayed in the GroupWise

Address Book and in the To field of sent messages.

To make this process easier, GroupWise lets you assign a preferred Internet domain to be used as the

default for your GroupWise system (for example, novell.com). The system’s preferred Internet

domain is applied to all users in your GroupWise system. However, you can override the system’s

preferred Internet domain at the domain, post office, or user level, meaning that different users

within your GroupWise system can be assigned different preferred Internet domains. For example,

users in one domain can be assigned gw.novell.com as their preferred Internet domain while users in

another domain are assigned support.novell.com.

45.1.4 Preferred Address Format

You must choose a preferred address format for your GroupWise users. GroupWise uses the

preferred address format, along with the preferred Internet domain, to construct the e-mail addresses

that are published in the GroupWise Address Book and in the To field of sent messages.

GroupWise supports the following address formats:

userID.post_office.domain@internet_domain_name

Configuring Internet Addressing 719

novdocx (en) 22 June 2009

userID.post_office@internet_domain_name

userID@internet_domain_name

firstname.lastname@internet_domain_name

lastname.firstname@internet_domain_name

firstinital lastname@internet_domain_name

As with the preferred Internet domain, you must assign a preferred address format to be used as the

default for your GroupWise system. The system’s preferred address format is applied to all users in

your GroupWise system. However, you can override the system’s preferred address format at the

domain, post office, and user/resource level.

The following sections explain some of the advantages and disadvantages of each address format:

“userID.post_office.domain@internet_domain_name” on page 719

“userID.post_office@internet_domain_name” on page 719

“userID@internet_domain_name” on page 719

“firstname.lastname@internet_domain_name” on page 720

“lastname.firstname@internet_domain_name” on page 720

“firstinitial lastname@internet_domain_name” on page 721

userID.post_office.domain@internet_domain_name

Advantages

Reliable format. GroupWise guarantees that each address is unique.

Identical usernames can be used in different post offices.

Disadvantages

Addresses tend to be long and hard to remember.

Addresses might change over time as users are moved from one post office to another.

userID.post_office@internet_domain_name

Advantages

Guarantees uniqueness if all your post offices have unique names.

Identical usernames can be placed in different post offices.

Disadvantages

Addresses tend to be long and hard to remember.

Addresses might change over time as users are moved from one post office to another.

userID@internet_domain_name

Advantages

Addresses are short and easy to remember.

720 GroupWise 8 Administration Guide

novdocx (en) 22 June 2009

Backwards-compatible with previous versions of GroupWise. (Users won’t need to update

their business cards.)

Addresses do not change as users are moved.

Disadvantages

When you first enable this address format, you might have duplicate user IDs in your

GroupWise system. However, in the future, ConsoleOne®prevents you from creating duplicate

user IDs within the same Internet domain name. The same user ID can be used in different

Internet domains without problem.

firstname.lastname@internet_domain_name

Advantages

Addresses are intuitive and easy to remember.

Addresses do not change as users are moved.

Disadvantages

When you first enable this address format, you might have duplicate first and last names in

your GroupWise system. However, in the future, ConsoleOne prevents you from creating users

with the same first and last names within the same Internet domain name. The same first name

and last name combination can be used in different Internet domains without problem.

The probability of conflicts increases if any user’s first and last names match any GroupWise

domain or post office name, if any two users have the same first and last names, or if any two

users have the opposite first and last names (such as James Dean and Dean James).

lastname.firstname@internet_domain_name

Advantages

Addresses are intuitive and easy to remember.

Addresses do not change as users are moved.

Disadvantages

When you first enable this address format, you might have duplicate first and last names in

your GroupWise system. However, in the future, ConsoleOne prevents you from creating users

with the same first and last names within the same Internet domain name. The same last name

and first name combination can be used in different Internet domains without a problem.

The probability of conflicts increases if any user’s first and last names match any GroupWise

domain or post office name, if any two users have the same first and last names, or if any two

users have the opposite first and last names (such as James Dean and Dean James).

Configuring Internet Addressing 721

novdocx (en) 22 June 2009

firstinitial lastname@internet_domain_name

Advantages

Addresses are intuitive and easy to remember.

Addresses do not change as users are moved.

Disadvantages

When you first enable this address format, you might have duplicate first initial and last names

in your GroupWise system. However, in the future, ConsoleOne prevents you from creating

users with the same first initials and last names within the same Internet domain name. The

same first initial and last name combination can be used in different Internet domains without

problem

The probability of conflicts increases when using first initials instead of complete first names.

45.1.5 Allowed Address Formats

The preferred Internet domain and preferred address format apply to user addresses as displayed in

the GroupWise Address Book or in the address displayed on sent messages.

The allowed address formats, on the other hand, determine which address formats are accepted by

the Internet Agent. There are five possible allowed formats:

userID.post_office@internet_domain_name

userID@internet_domain_name

firstname.lastname@internet_domain_name

lastname.firstname@internet_domain_name

firstinital lastname@internet_domain_name

If you select all five formats, the Internet Agent accepts messages addressed to users in any of the

formats. For example, John Peterson would receive messages sent using any of the following

addresses:

[email protected]

jpeterson@novell.com

john.peterson@novell.com

peterson.jo[email protected]m

jpeterson@novell.com

You must designate the allowed address formats to be used as the default formats for your

GroupWise system. The system’s allowed address formats are applied to all users in your

GroupWise system. However, you can override the system’s allowed address formats at the domain,

post office, and user/resource level.

For example, assume you have two John Petersons with userIDs of jpeterson and japeterson. The

userID.post_office and userID address formats do not cause message delivery problems, but the

firstname.lastname, lastname.firstname, and firstinitial lastname address formats do. To overcome

this problem, you could disallow the three problem formats for these users at the user level.

722 GroupWise 8 Administration Guide

novdocx (en) 22 June 2009

45.1.6 Override Options

In spite of the best planning, some e-mail addresses do not fit the rules and are not processed

correctly. You can handle such addresses by overriding the regular address processing, as described

in Section 45.2.3, “Overriding Internet Addressing Defaults,” on page 725.

45.2 Setting Up Internet Addressing

The following sections help you to set up Internet addressing:

Section 45.2.1, “Installing the Internet Agent,” on page 722

Section 45.2.2, “Enabling Internet Addressing,” on page 722

Section 45.2.3, “Overriding Internet Addressing Defaults,” on page 725

45.2.1 Installing the Internet Agent

Before you can set up Internet addressing, you must install the GroupWise Internet Agent for at least

one domain. If you have not already installed the agent, see “Installing the GroupWise Internet

Agent” in the GroupWise 8 Installation Guide.

45.2.2 Enabling Internet Addressing

1In ConsoleOne, click Tools > GroupWise System Operations > Internet Addressing.

2On the Internet Domains tab, click Create.

Configuring Internet Addressing 723

novdocx (en) 22 June 2009

3Specify the Internet domain name (for example, Corporate.com), then click OK to set up the

first Internet domain for your GroupWise system.

4If you want your GroupWise system to receive e-mail addressed to additional Internet domain

names:

4a Repeat Step 2 and Step 3.

4b When you are finished adding Internet domain names to the list, select the preferred

Internet domain name for your GroupWise system, then click Set Preferred.

The preferred Internet domain name is used in addresses published in the GroupWise

Address Book and in the To field of sent messages. This can be overridden on the Internet

Addressing properties pages for domains, post offices, users, and resources. For more

information, see Section 45.2.3, “Overriding Internet Addressing Defaults,” on page 725.

5In the Internet Agent for Outbound SMTP/MIME Messages list, select the Internet Agent to use

as the default Internet Agent for your GroupWise system.

By default, all GroupWise domains use this Internet Agent for outbound messages sent by

users in the domain. If you have multiple Internet Agents in your GroupWise system, you can

override the default setting at the domain level, as described in “Domain Overrides” on

page 725.

6Click the Addressing Formats tab.

724 GroupWise 8 Administration Guide

novdocx (en) 22 June 2009

7In the Preferred Address Format field, select your GroupWise system’s default Internet address

format.

This is the format that is used when displaying addresses in the GroupWise Address Book and

in a message’s From field if it is not overridden at a lower level. For a list of the available

addressing formats and their respective advantages and disadvantages, see Section 45.1.4,

“Preferred Address Format,” on page 718.

You can override the preferred address format at the domain, post office, and user/resource

levels. For more information, see Section 45.2.3, “Overriding Internet Addressing Defaults,”

on page 725.

8If desired, turn on the Enable “First Initial Last Name” Matching for Incoming Mail option.

This option allows the Internet Agent to resolve addresses for incoming messages by

performing first initial last name lookups on the username portion of the address. When doing

so, the Internet Agent uses the first letter of the username as the first initial and the remainder

of the username as the last name. It then resolves the address to any GroupWise users whose

Last Name field (in their eDirectory User object properties) contains the last name and whose

Given Name field starts with the first initial.

For example, if the recipient’s address is jpeterson@novell.com, the first initial would be J and

the last name would be Peterson. The address would resolve to the user whose Last Name field

is Peterson and Given Name field starts with J. If more than one user’s given name starts with J

(for example, John and Janice), the message is undeliverable.

This option is useful if you want to be able to use the UserID@Internet_domain_name format

but your userIDs do not really reflect your users’ actual names (for example, John Peterson’s

user ID is 46789 so his address is 46789@novell.com). In this case, you could publish users’

addresses as the first initial last name (for example, jpeterson@novell.com) and enable this

option so that the Internet Agent resolves the addresses to the appropriate users.

9In the Allowed Address Formats list, select the address formats that you want to be supported

for incoming messages. GroupWise delivers a message to the recipient if any of the allowed

formats have been used in the address. By default, all formats are supported.

You can override the allowed address formats at the domain, post office, and user/resource

levels. For more information, see Section 45.2.3, “Overriding Internet Addressing Defaults,”

on page 725.

10 Click OK to save your changes.

If you changed the preferred address format, you are prompted to update the Internet e-mail

address (User object > General > Identification > E-Mail Address) for all affected users. The

Internet e-mail address is the address returned in response to LDAP queries to eDirectoryTM. It

is recommended that you allow this update; however, performing it for the entire GroupWise

system might take a while.

At this point, Internet addressing is enabled and configured.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Software de Novell

Novell

Novell ZENWORKS 7.2 LINUX MANAGEMENT - SCENARIOS 1... Manual de usuario

Novell

Novell PLATESPIN ORCHESTRATE 2.0.2 - UPGARDE GUIDE... Manual del operador

Novell

Novell APPARMOR 2.0.1 Manual de instrucciones

Novell

Novell ZENWORKS ENDPOINT SECURITY MANAGEMENT 3.5 Manual de usuario

Novell

Novell IDENTITY MANAGER 3.6.1 - JOBS GUIDE Manual de usuario

Novell

Novell EDIRECTORY 8.8 SP5 - GUIDE 12-2009 Manual de usuario

Novell

Novell LINUX ENTERPRISE SERVER 10 SP2 - ARCHITECTURE-SPECIFIC INFORMATION... Manual de usuario

Novell

Novell IDENTITY MANAGER 3.6.1 - STAGING BEST PRACTICES GUIDE... Manual de usuario

Novell

Novell CLIENT LOGIN EXTENSION 3.7 - ADMINISTRATION Manual de instrucciones

Novell

Novell Account Management 2.1 Manual de usuario

Novell

Novell OPEN ENTERPRISE SERVER 2 SP2 - STORAGE SERVICES AUDITING CLIENT LOGGER UTILITY REFERENCE... Manual de servicio

Novell

Novell ZENWORKS 10 CONFIGURATION MANAGEMENT SP3 - COMMAND LINE UTILITIES REFERENCE 10.3... Manual de funcionamiento

Novell

Novell LINUX ENTERPRISE SERVER 10 SP2 - VIRTUALIZATION WITH... Manual de usuario

Novell

Novell Open Enterprise Server 2 Manual de instrucciones

Novell

Novell ACCESS MANAGER 3.1 SP1 - IDENTITY SERVER Manual de usuario

Novell

Novell IFOLDER 3.X - SECURITY ADMINISTRATOR GUIDE... Manual de servicio

Novell

Novell IDENTITY MANAGER 3.6.1 Manual de usuario

Novell

Novell ZENWORKS 10 CONFIGURATION MANAGEMENT SP3 - NETWORK DISCOVERY DATABASE... Guía rápida

Novell

Novell LINUX ENTERPRISE SERVER 11 - DEPLOYMENT Guía de referencia rápida

Novell

Novell ACCESS MANAGER 3.1 SP2 - SSL VPN USER GUIDE... Manual de usuario

Novell

Novell PLATESPIN ORCHESTRATE 2.0.2 - ADMINISTRATOR REFERENCE... Manual de servicio

Novell

Novell LINUX ENTERPRISE SERVER 11 - VIRTUALIZATION Manual de usuario

Novell

Novell LINUX ENTERPRISE SERVER 10 SP3 -... Manual

Novell

Novell ZENWORKS 7.2 LINUX MANAGEMENT - SCENARIOS 2... Manual de usuario

Manuales populares de Software de otras marcas

COMPRO

COMPRO COMPROFM Manual de usuario

Muratec

Muratec OFFICEBRIDGE ONLINE Manual de usuario

Oracle

Oracle Contact Center Anywhere 8.1 Manual de usuario

Adobe

Adobe 65007312 - Photoshop Lightroom Manual

Avaya

Avaya NULL One-X for RIM Blackberry Manual de usuario

HP ProLiant BL420c Manual de usuario

PS Audio

PS Audio PowerPlay Manual del propietario

Brady

Brady LOCKOUT PRO 3.0 Manual de servicio

Avaya

Avaya Interaction Center Manual de usuario

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manual

Oracle

Oracle Application 9i Manual de usuario

Acer

Acer RDM Manual de usuario

Canon

Canon Vixia HF21 Manual de usuario

Canon

Canon ZR950 Manual de usuario

Samsung

Samsung Auto Backup Manual de usuario

Polycom

Polycom Vortex EF2201 Instrucciones de instalación y funcionamiento

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manual de usuario

Lexmark

Lexmark Apps Manual de servicio
