Packing List
Ref. DR560
Desoldering Iron
Tips .............................................. 3 units
Ref. C560005*
Ref. C560013*
Ref. C560004*
Desoldering Iron ........................ 1 unit
Ref. DR560-A
C560003 already inserted
The following items should be included:
Union
flanges ......... 1 u.
R ef. 0 0113 5 6
Tip cleaning
set ................. 1 u.
Ref. 0965970*
Internal
gasket .......... 1 u.
Ref. 0019208*
It contains 2 gaskets
Filter
box ................ 1 u.
Ref. 0780840
It contains 10 filters
Spanner ...... 1 u.
Ref. 0780550*
Spiral
Filter ............. 1 u.
Ref. 0812330*
Long tip
cleaning set
..........................1 u.
Ref. 0965760*
Cleaning
stick .............. 1 u.
Ref. 0786640
Metal Solder
Collector .... 1 u.
Ref. 0812630*
Glass Solder
Collector ..... 1 u.
Ref. 0812620*
Manual ......... 1 u.
Ref. 0008867
*DR560-A Desoldering Iron accessories included in the Ref. 0010261
2
www.jbctools.com
Desoldering process
When desoldering, use a tip with a diameter larger than the pad being desoldered. This will achieve
maximum suction and thermal efficiency.
The vacuum pump will continue to run for a few seconds. This makes sure that the vacuum
circuit is completely empty. If there are any solder remains left on a terminal, just resolder it
with fresh solder and repeat the desoldering operation.
Connection
Desoldering Iron
Ref. DR560-A
Tip
Ref. C560003
to desoldering module
to stand
Suction Filter
Ref. 0821830
Supplied with desoldering module
1. Apply the tip so that it fits
over the component terminal.
2. When the solder liquefies,
gently rotate the tip so that the
terminal can be lifted off.
3. Then press the vacuum
pump button long enough to
suck up the solder.
www.jbctools.com
3
A ø
B ø
C560-001 C560-002
C560-003
C560-004 C560-009
C560-014
Changing Tips
This operation should be done while the tip is
hot and at a minimum temperature of 250°C,
so that any tin left inside is still molten.
- Use the special spanner to unscrew the tip
- Fit the new tip, and tighten with the
spanner so that it is airtight.
250º C min.
C560-001 A=1,4 B=0,6 max. pin=0,4 mm
(A=0.05 B= 0.02 max. pin= 0.01 in)
C560-002 A=1,8 B=0,8 max. pin=0,6 mm
(A=0.07 B= 0.03 max. pin= 0.02 in)
C560-003 A=2,7 B=1 max. pin=0,8 mm
(A=0.1 B= 0.04 max. pin= 0.03 in)
C560-004 A=3,2 B=1,3 max. pin=1,1 mm
(A=0.12 B= 0.05 max. pin= 0.04 in)
C560-009 A=5 B=1,3 max. pin=1,1 mm
(A=0.19 B= 0.05 max. pin= 0.04 in)
C560-014 A=2,5 B=0,8 max. pin=0,6 mm
(A=0.09 B= 0.03 max. pin= 0.02 in)
Compatible Tips
The DR560 uses C560 tips. Find the model that best suits your needs in www.jbctools.com
See here some of them in real size:
4
washer
Changing the heating element (Ref. DSV-DR)
ba
Important
For a proper connection it is
essential to insert the car-
tridge as far as the mark.
Important
Before placing, make sure to
insert the internal gasket into
the Solder Collector.
Compatibility
The DSV-DR also works with
the previous version DR5600
Desoldering Iron (Ref.
5600010). In this case, you
must take out the washer with
a pliers.
1. Removing
Loosen the deposit lid (a), remove the screw (b) and withdraw the heating element (c).
2. Placing
Insert the new one (a), tighten the lid (b) and then the screw (c).
For this operation, turn off the station or disconnect the tool and wait until the tool temperature
drops to room temperature.
Recommended: Remove the
lid in a vertical position and
follow the cleaning guideli-
nes in the tool and station
manuals.
c
cb
a!
!
mark
www.jbctools.com
5
Maintenance
Before carrying out maintenance or storage, always unplug the tool.
- Check periodically that the metal parts are clean to ensure it is detected when on the stand.
Always use a damp cloth or alcohol.
- Periodically check all cables and tubes connections.
- Replace any defective or damaged pieces. Use original JBC spare parts only.
- Repairs should only be performed by a JBC authorized technical service.
Glass Solder Collector Maintenance
2. Next remove the spiral and clean the inside
part of the collector with the cleaning stick.
- Check the filter and replace it if it is dirty or
damaged.
1. For cleaning, the top must be unscrewed with
the DR560 in a vertical position.
3. Insert the filter and the spiral filter which must
be inserted in place between the 2 lines on the
solder collector.
Before placing, make sure to insert the internal
gasket into the solder collector.
Finally screw on the top to close the unit.
Check filter
Check
internal joint 2
3
1
6
Tip Care
- Use the largest rod possible to clean the tip.
- Important: DO NOT press the pushbutton
vacuum pump while tinning the desoldering
tip, as the fumes given off by the flux would
quickly soil the ducts and filter of the air
circuit.
www.jbctools.com
7
It is imperative to follow safety guidelines to protect health and prevent electric
shock, injury, fire or explosions.
Safety
- Do not use the tool for any purpose other than soldering or rework. Incorrect use may cause fire.
- The temperature of accessible surfaces may remain high after the unit is turned off.
Handle with care.
- Do not leave the appliance unattended when it is on.
- It is necessary to turn the station off before changing tips.
- Heat can cause inflamable products to ignite even when out of sight.
- Be careful with the remains of liquid tin. In contact with skin, it can cause burns.
- Avoid flux coming into contact with skin or eyes to prevent irritation
- Be careful with the fumes produced when soldering.
- Keep your workplace clean and tidy. Wear appropriate protection glasses and gloves when
working to avoid personal harm.
- This appliance can be used by children over the age of eight and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge once they have been
given adequate supervision or instruction concerning use of the appliance and understand the
hazards
involved.
- Children must not play with the appliance. Maintenance shall not be carried out by them unless
supervised.
8
- Weight: 0.4 kg (0.91 lb)
Complies with CE standards
ESD protected housing “skin effect”
Specifications
www.jbctools.com
9
Ref. DR560
Desoldering Iron
Composición
Puntas ................................. 3 unidades
Ref. C560005*
Ref. C560013*
Ref. C560004*
Desoldering Iron
Desoldador .............................. 1 unidad
Ref. DR560-A
Punta C560003
incluida
Los siguientes artículos deben estar incluidos:
Union
flanges
Bridas de
unión ........... 1 ud.
R ef. 0 0113 5 6
Tip cleaning set
Juego de limpieza
de puntas ... 1 ud.
Ref. 0965970*
Internal gasket
Junta
interna ........ 1 ud.
Ref. 0019208*
Contiene 2 juntas
Filter box
Caja de
filtros ........... 1 ud.
Ref. 0780840
Contiene 10 filtros
Spanner
Llave para
puntas ........ 1 ud.
Ref. 0780550*
Spiral Filter
Filtro en
espiral.......... 1 ud.
Ref. 0812330*
Long tip
cleaning set
Juego largo de
limpieza de
puntas ........ 1 ud.
Ref. 0965760*
Cleaning stick
Bastoncillo de
limpieza del
depósito ..... 1 ud.
Ref. 0786640
Metal Solder
Collector
Depósito metálico
de estaño ... 1 ud.
Ref. 0812630*
Glass Solder
Collector
Depósito de
estaño ........ 1 ud.
Ref. 0812620*
Manual ...... 1 ud.
Ref. 0008867
*Accesorios del desoldador DR560-A incluidos en la Ref. 0010261
