Jbc AL250-B Manual de usuario

AL250

Auto-Feed Iron

INSTRUCTION MANUAL

Auto-Feed Iron .......................................................................................................................................... 1 unit

Includes: Cartridge Ref. C250403

and GAL0910 Guide Tube Ø 0,9 - 1 mm (0.035 - 0.04 in), Ref. 0002401

Manual ......................................................... 1 unit

Ref. 0012317

GAL0910

C250403

Packing List

The following items are included:

This manual corresponds to the following reference:

AL250-B

for AL Auto-Feed Soldering Station

Allen Key 2,5mm ................................ 1 unit

Ref. 0023792

Features and Connections

AL250 Auto-Feed Iron is compatible only with AL Auto-Feed Soldering Station.

Stand*

R e f . A L- S F

Power

Socket

Equipotential

connection

Pedal connection

(optional)

Auto-Feed Iron

Ref. AL250-B

Fuse

Main switch

Auto Feed Soldering

Station*

*not included

40 mm

50 mm

60 mm

80 mm

100 mm

130 mm 130 mm

para manuales - color gris

200 mm

300 mm

AP250

AL250

SF280

SF250

ALE250

AL250

SOLDER WIRE

Connect the tool to the station and switch the station on. With the tool out of the stand, press the

WIRE LOAD (1) key at the station till the solder wire comes out at the guide tube end (2).

Fast Wire Dragging

Adjust the dragging strength (1) to enable the solder wire to be passed on properly and to

avoid any jamming or clogging.

Fix the dragging mechanism by tighten more or less (2) the sprung element.

Clutch Regulation

Solder Wire Loading

ø 0,6

3,2x1,5

2,2 x 1

ø 3,8

AP250

AL250

SF280

SF250

ALE250

AL250-B

0.9-1 Ø0.9-1 Ø0.9-1 Ø

AL250-B

0.9-1 Ø0.9-1 Ø0.9-1 Ø

0.9-10.9-1 Ø0.9-1 Ø

AP250

AL250

SF280

SF250

ALE250

AP250

AL250

SF280

SF250

ALE250

Align the cartridge tip with the guide nozzle (6)

and tighten the cartridge screw (7).

Place a new cartridge into the auto-feed iron (4).

Important: For a good connection it is essential

to insert the cartridge till the end, until the mark

(5).

B. RemovingA. Unlocking

Loosen the cartridge screw (1) to release the

cartridge (2).

Place the cartridge in the extractor and pull

the tool to remove the cartridge (3).

C. Inserting

Changing Cartridges

For a safe cartridge change, unplug the tool or turn the station off before following these guidelines.

Mark

D. Adjusting

AL250 Auto-Feed Iron works with C250 cartridges. Find the model that best suits your soldering needs in

www.jbctools.com

Compatible Cartridges

Conical Bent Chisel Chisel Bent Bevel

40 mm

50 mm

60 mm

80 mm

100 mm

130 mm 130 mm

para manuales - color gris

200 mm

300 mm

AP250

AL250

SF280

SF250

ALE250

AL250

Accessories

Fume Extractor

Ref. F4468 - 2 m (78.74 ft) lenght.

The fume extractor for the Auto-Feed Iron is an easy & safe solution to suck the fume generated at the

solder joint.

Handsfree Stand

Ref. AL-IA

Indispensable for using the Auto-Feed Iron while

having both hands free. Suitabel for Auto-Feed

Iron Ref. AL250-B and Ref. 0027332.

Maintenance

Clean periodically

- Before carrying out maintenance, always unplug the stand and the tool.

- Check periodically that the metal parts of the tool and the stand are clean to ensure detection of the

tool when it is in the stand. Use a damp cloth or alcohol.

- Periodically check all cables and tubes connections.

- Replace any defective or damaged pieces. Use original JBC spare parts only. Repairs should only

be performed by a JBC authorized technical service.

Fume

Extractor

Safety

- Do not use the tool for any purpose other than soldering or rework.

- The power cord must be plugged into approved bases. Be sure that it is properly grounded before

use. When unplugging it, hold the plug, not the wire.

- The tool should be placed in the stand when not in use in order to activate the sleep mode. The

soldering tip, the metal part of the tool and the stand may still be hot even when the station is turned

off. Handle with care, including when adjusting the stand position.

- Avoid the contact of flux with skin or eyes to prevent irritation.

- Be careful with the fumes produced when soldering.

- Keep your workplace clean and tidy. Wear appropriate protection glasses and gloves when working

to avoid personal harm.

- Utmost care must be taken with liquid tin waste which can cause burns.

- This appliance can be used by children over the age of eight and also persons with reduced physical,

sensory or mental capabilities or lack of experience provided that they have been given adequate

supervision or instruction concerning use of the appliance and understand the hazards involved.

Children must not play with the appliance.

- Maintenance must not be carried out by children unless supervised.

It is imperative to follow safety guidelines to prevent electric shock, injury, fire or explosion.

40 mm

50 mm

60 mm

80 mm

100 mm

130 mm 130 mm

para manuales - color gris

200 mm

300 mm

0028674-0122

Specifications

AL250

Auto-Feed Iron

Ref. AL250-B

- Guide Tube GAL0910: Ø 0.9 - 1 mm / 0.035 - 0.04 in

- Total Net Weight: 148 g / 0.33 lb

- Package Dimensions/Weight: 300 x 125 x 65 mm / 257 g

(L x W x H) 11.81 x 4.92 x 2.56 in / 0.57 lb

Complies with CE standards.

ESD safe

This product should not be thrown in the garbage.

In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must

be collected and returned to an authorized recycling facility.

Warranty

JBC’s 2 year warranty covers this equipment against

all manufacturing defects, including the replacement

of defective parts and labour.

Warranty does not cover product wear or misuse.

In order for the warranty to be valid, equipment must

be returned, postage paid, to the dealer where it was

purchased.

Get 1 extra year JBC warranty by registering here:

https://www.jbctools.com/productregistration/

within 30 days of purchase.

40 mm

50 mm

60 mm

80 mm

100 mm

130 mm 130 mm

para manuales - color gris

200 mm

300 mm
