TruVision IP PTZ Camera FW5.1 Installation

Guide

Introduction

This installation guide provides basic information on setting up

and using the camera. Detailed information on the cameras

can be found in the configuration manual.

Product overview

This is the installation guide for following TruVision IP PTZ

camera models:

TVP-1101 (1.3 MPX pendant, 20X, PAL)

TVP-3101 (1.3 MPX pendant, 20X, NTSC)

TVP-1102 (1.3 MPX surface, 20X, PAL)

TVP-3102 (1.3 MPX surface, 20X, NTSC)

TVP-1103 (1.3 MPX flush, 20X, PAL)

TVP-3103 (1.3 MPX flush, 20X, NTSC)

TVP-1104 (2 MPX pendant, 20X, PAL)

TVP-3104 (2 MPX pendant, 20X, NTSC)

TVP-1105 (2 MPX surface, 20X, PAL)

TVP-3105 (2 MPX surface, 20X, NTSC)

TVP-1106 (2 MPX flush, 20X, PAL)

TVP-3106 (2 MPX flush, 20X, NTSC)

TVP-1107 (2 MPX pendant, 30X, PAL)

TVP-3107 (2 MPX pendant, 30X, NTSC)

TVP-1122 (2 MPX pendant, 30X, IR, PAL)

TVP-3122 (2 MPX pendant, 30X, IR, NTSC)

Before you begin

Unpack everything. Check the items for damage, and verify

that all items are included. The camera is shipped with the

following items:

Dome camera

Installation Guide

CD with the Configuration Manual and Device Manager

Installation environment

When installing your camera, consider these factors:

•Place the camera in a secure location.

•Ensure that the camera is in a well-ventilated area.

•Do not expose the camera to rain or moisture.

Caution: Risk of explosion if the battery is replaced by an

incorrect type. Dispose of used batteries according to the

instructions.

Camera description

Figure 1: Overview of the dome camera (pendant-mount shown)

TVP-1122/3122 cameras only:

1. Power supply cord

Connect 24 VAC power supply

2. Video output

Connect the BNC connector to a

CCTV monitor

3. Ethernet RJ45 connector. Connect

to the network devices

Connect to the PoE+ switch

4. Alarm input/outputs and

audio in/out port

5. Housing

6. Bubble

7. Metal housing

8. IR LEDs

9. Camera

2 / 6 P/N 1073029-EN • REV A • ISS 03JUN15

Connections

There are seven built-in alarm inputs to use as internal alarm

triggers and two alarm built-in outputs in the camera housing.

These connections do not apply to the TVP-1122/3122

cameras.

Note: The DIP switches are not used.

Figure 2: Connections to the circuit board (excludes TVP-

1122/3122)

1. Power supply: Connect +24 VAC power supply and GND.

2. RJ45 connector: Connect to the network.

Caution: The RJ45 connector on the camera module is not for connecting the

network. It is an RS-232 port for troubleshooting.

3. Alarm inputs 3 to 7: Connect to up to five alarm input devices.

4. GND

5. Alarm inputs 1 and 2: Connect to up to two alarm input devices.

6. Alarm outputs 1 and 2: Connect up to two output devices

7. AIN, AOUT: Connect audio input, audio output, and GND to the audio

terminals.

8. VIDEO: Connect a CCTV monitor to the video terminals.

Alarm input and output connections

The alarm output can be used to turn on and off an external

alarm device. Connect a 30 VDC/1 A external power supply to

the alarm output. If using an AC power supply, an external

relay must be used to prevent electric shock and damage to

the device. See Figure 3 below.

Figure 3: External alarm output

Direct current:

Dome camera

relay output

Alternating current:

Dome camera

relay output

Installing a camera

Pendant-mount camera

1. Prepare the mounting surface and install the camera

bracket.

2. Unscrew the bubble from the camera and remove the

protective tape from the PTZ module (excluding TVP-

1122).

3. Press the two tabs on either side of the PTZ module and

remove the module from the camera housing (excluding

TVP-1122).

4. Route the cables from the pendant bracket as shown

below.

5. Attach the safety cable to the bracket and connect the

cables to the PCB of the module through the cable entry

hole on top of the housing.

Safety cable

Note: If alarm and audio input/output relays are to be

used, also connect them to the PCB of the module.

Caution:The safety cable is made of metal. Please ensure

that it does not touch the PCB of the module.

6. Attach the camera housing to the bracket using the screws

enclosed with the bracket.

7. Insert the PTZ module into the housing:

Position the tabs on the PTZ module by aligning the arrow

label on the module with those on the housing (see

below). The module should firmly snap into position. If

using a SD card, insert it into the module before inserting

the module into the housing.

RED AC24V

YELLOW/GREEN

BLACK AC24V

P/N 1073029-EN • REV A • ISS 03JUN15 3 / 6

Caution: The RS-232 serial port on the camera is not a

network connection.

8. Re-attach the bubble by screwing it to the housing.

9. See “Accessing the camera over the internet” on page 4 to

configure the camera over the internet. Refer to the

Configuration Manual for detailed information.

TVP-1122/3122 pendant-mount camera

1. Prepare the mounting surface and install the camera

bracket.

2. Attach the safety cable to the bracket and then route the

cables from the pendant bracket as shown below.

Safety cable

3. Connect the cables to the PCB of the module through the

cable entry hole on top of the housing.

4. See “Accessing the camera over the internet” on page 4 to

configure the camera over the internet. Refer to the

Configuration Manual for detailed information.

Flush-mount camera

1. Drill a hole on the ceiling using the drill template.

2. Tie three safety cables (not supplied) to the safety hooks

on the camera and hang the camera from a secure point.

3. Unscrew the bubble from the camera and remove the

protective tape from the PTZ module.

4. Press the two tabs on either side of the PTZ module and

remove it from the camera housing.

5. Route the cables from the bracket and connect them to

the PCB of the module through the cable entry hole on the

top of the housing.

Note: If alarm and audio input/output relays are to be used, also

connect them to the PCB of the module.

6. Adjust the height of the two housing tabs by turning the

screw on which they are attached. The distance (h) of the

tabs from the housing ring must be greater than the

thickness of the ceiling.

Housing tab

Screw

7. Make sure the housing tab is closed and then PUSH the

housing into the pass-through hole. Hold the housing and

fix it by screwing the housing tabs down to the mounting

surface

8. Insert the PTZ module into the housing:

9. Re-attach the bubble by screwing it to the housing.

10. Install the trim ring. Align the trim ring to the housing, and

insert the fix-pins to the holes. Then rotate the ring

clockwise to secure.

11. See “Accessing the camera over the internet” on page 4 to

configure the camera over the internet. Refer to the

Configuration Manual for detailed information.

RED AC24V

YELLOW/GREEN

BLACK AC24V

4 / 6 P/N 1073029-EN • REV A • ISS 03JUN15

Surface-mount camera

The cables of PTZ camera can be routed either from the top or

the side of the housing. For the cables routed from the top of

the housing, you must drill a cable hole in the ceiling.

1. Use the mounting base as a template to mark four screw

holes onto the ceiling. If you route cables from the top of

the housing, mark the cable hole on the ceiling and drill a

hole.

Cable hole

Screw holes

2. Secure the mounting base to the ceiling with the set

screws.

3. Unscrew the bubble from the camera and remove the

protective tape from the PTZ module.

4. Press the two tabs on either side of the PTZ module and

remove it from the camera housing.

5. Route the cables from the bracket and connect them to

the PCB of the module through the cable entry hole on the

top or side of the housing.

Note:If alarm and audio input/output relays are to be

used, also connect them to the PCB of the module.

6. Install the housing onto the mounting base. Line up the

direction of the arrow on the housing with the spring end of

the mounting base. Push the housing upwards (A) and

then forwards (B) in the direction of the arrow.

When the housing is placed in position, the spring will

automatically snap into the lock clip firmly. Refer to the

figures below.

Line up

B. Push forward

A. Push

upward

Lock clip

7. Insert the PTZ module into the housing:

8. Re-attach the bubble by screwing it to the housing.

Warning: After installation, the PTZ module will perform a

PTZ self-test and initializes with the power on. DO NOT

touch and move the camera while it is self-testing and

initializing.

9. See “Accessing the camera over the internet” below to

configure the camera over the internet. Refer to the

Configuration Manual for detailed information.

Using the camera with an Interlogix NVR or

Hybrid DVR or another system

Please refer to the NVR/DVR user manuals for instructions on

connecting and operating the camera with these systems.

Using the camera with TruVision Navigator

A camera must be connected to an Interlogix NVR or hybrid

DVR to be operated by TruVision Navigator. Please refer to the

TruVision Navigator user manual for instructions on operating

the camera with the TruVision Navigator.

Accessing the camera over the

internet

Use the web browser to access and control the camera over

the internet.

Note: Any changes made to the camera’s configuration only

apply to this camera.

P/N 1073029-EN • REV A • ISS 03JUN15 5 / 6

Change the administrator password once the set-up is

complete. Only authorized users should be able to modify

camera settings.

To access the camera online:

1. In the web browser enter the camera’s IP address (default

is 192.168.1.70). The Login dialog box appears.

2. Enter your user name and password.

Default user name: admin

Default password: 1234

Click Login. The web browser screen appears in live

mode.

3. Click the Configuration tab on the top of the screen and

select the parameter to change.

Figure 4: Example of a configuration window

Table 1: Overview of the Configuration panel

Configuration folders

Description

System

Defines device basic information

including SN and the current

firmware version, time settings, and

maintenance parameters.

Network

Defines the network parameters

required to access the camera over

the internet.

Video/Audio

Defines recording parameters.

PTZ

Defines the PTZ parameters.


Defines the image parameters,

OSD

settings, overlay text, and privacy

mask.

Security

Defines who can use the camera,

their passwords and access

privileges, RTSP authentication, IP

address filter, and telnet access.

Events

Defines motion detection, tamper-

proof, alarm input/output, exception,

and snapshot configuration.

Storage

Defines recording schedule, storage

management and NAS

configuration.

Specifications

Electrical

Voltage input

24 VAC, PoE+ (IEEE 802.3at)

Power

consumption

Pendant housing:

PoE:Max. 25 W

24 VAC: Max. 65 W

Flush housing: Max. 25 W

Surface housing: Max. 25 W

Miscellaneous

Operating

temperature

Pendant housing: PoE+ for -30 to 65 °C

24 VAC: -40 to +65 °C

Flush housing: -10 to +50 °C

(14 °F to 122 °F)

Surface housing: -10 to +50 °C

(14 to 122 °F)

Dimensions

Pendant housing: Ø 220 × 266 mm

Flush housing: Ø 206 × 251 mm

Surface housing: Ø 180 × 240 mm

Weight

Pendant housing: 3,5 kg

Flush housing: 3 kg

Surface housing: 2,5 kg

Environmental

rating

Pendant housing: IP66

Flush housing: IP54

Surface housing: IP54

Pin definitions

There are eight wires on a standard UTP/STP cable and each

wire is color-coded. The following shows the pin allocation and

color of straight and crossover cable connection:

Figure 5: Straight-through cable

1 White/Orange

White/Orange 1

2 Orange Orange 2

3 White-Green White-Green 3

4 Blue Blue 4

5 White/Blue White/Blue 5

6 Green Green 6

7 White/Brown White/Brown 7

8 Brown Brown 8

Figure 6: Cross-over cable

1 White/Orange

White/Orange 1

2 Orange Orange 2

3 White-Green White-Green 3

4 Blue Blue 4

5 White/Blue White/Blue 5

6 Green Green 6

7 White/Brown White/Brown 7

8 Brown Brown 8

Please make sure your connected cables have the same pin

assignment and color as above before deploying the cables in

your network.

6 / 6 P/N 1073029-EN • REV A • ISS 03JUN15

Regulatory information

Manufacturer

Interlogix.

2955 Red Hill Avenue, Costa Mesa, CA 92626

5923, USA

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, The Netherlands

FCC compliance

Class A: This equipment has been tested and

found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide

reasonable protection against harmful

interference when the equipment is operated in

commercial environment. This equipment

generates, uses, and can radiate radio frequency

energy and, if not installed and used in

accordance with the instruction manual, may

cause harmful interference to radio

communications. Operation of this equipment

in a

residential area is likely to cause harmful

interference in which case the user will be

required to correct the interference at his own

expense.

This device complies with Part 15 of the FCC

Rules. Operation is subject to the following two

conditions:

(1) This device may not cause harmful

interference

(2) This Device must accept any interference

received, including interference that may cause

undesired operation.

Any changes or modifications not expressly

approved by the party responsible for complianc

could void the user’s authority to operate the

equipment.

ACMA compliance

Notice! This is a Class A product. In a domestic

environment this product may cause radio

interference in which case the user may be

required to take adequate measures.

Canada

This Class A digital apparatus complies with

Canadian ICES-003.

Cet appareil numérique de la classe A est

conforme à la norme NMB-0330 du Canada.

Certification

N4131

European Union

directives

12004/108/EC (EMC directive): Hereby, UTC Fire

& Security declares that this device is in

compliance with the essential requirements and

other relevant provisions of Directive

2004/108/EC.

2012/19/EU (WEEE directive): Products marked

with this symbol cannot be disposed of as

unsorted municipal waste in the European Union.

For proper recycling, return this product to your

local supplier upon the purchase of equivalent

new equipment, or dispose of it at designated

collection points. For more information see:

www.recyclethis.info.

2006/66/EC (battery directive): This product

contains a battery that cannot be disposed of as

unsorted municipal waste in the European Union.

See the product documentation for specific

battery information. The battery is marked with

this symbol, which may include lettering to

indicate cadmium (Cd), lead (Pb), or mercury

(Hg). For proper recycling, return the battery to

your supplier or to a designated collection point.

For more information see: www.recyclethis.info.

Interlogix is part of UTC Building & Industrial

Systems, a unit of United Technologies

Trademarks and

patents

The trade names used in this document may be

trademarks or registered trademarks of the

manufacturers or vendors of the respective

products.

Contact information

For contact information, see www.interlogix.com or

www.utcfssecurityproducts.eu.

Otros manuales para FW5.1

Tabla de contenidos

Otros manuales de Cámara de seguridad de Interlogix

Interlogix

Interlogix TruVision TVB-4402 Manual de usuario

Interlogix

Interlogix True Vision TVP-5104 Manual de usuario

Interlogix

Interlogix TruVision TVC-7120-1-N Manual de usuario

Interlogix

Interlogix UVC-XP4DN-HR Manual de usuario

Interlogix

Interlogix 36X Manual de usuario

Interlogix

Interlogix 4 SERIES Hoja de instrucciones

Interlogix

Interlogix TruVision TVD-5801 Manual de usuario

Interlogix

Interlogix UVD-XP4DNR(-P) Manual de usuario

Interlogix

Interlogix TruVision 5 Series Hoja de instrucciones

Interlogix

Interlogix TruVision TVD-2401 Manual de usuario

Interlogix

Interlogix UVP-M1120P-18X-N Manual de usuario

Interlogix

Interlogix UltraView IP PTZ 36X Manual de usuario

Interlogix

Interlogix UltraView PTZ Manual de usuario

Interlogix

Interlogix TruVision Bullet IR Manual de usuario

Interlogix

Interlogix TruVision Open Standards Manual de usuario

Interlogix

Interlogix TruVision TVB-2402 Manual de usuario

Interlogix

Interlogix TruVision TVC-6110-1 Instrucciones de funcionamiento y mantenimiento

Interlogix

Interlogix PIR Manual de usuario

Interlogix

Interlogix TruVision Line Manual de usuario

Interlogix

Interlogix TruVision TVP-5101 Hoja de instrucciones

Interlogix

Interlogix TruVision TVD-7120VE-2 Manual de usuario

Interlogix

Interlogix TruVision TVP-5104 Hoja de instrucciones

Interlogix

Interlogix TruVision TVD-2402 Manual de usuario

Interlogix

Interlogix TruVision Line Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario
