Interlogix TruVision TVB-5702 Hoja de instrucciones

TruVision IP Thermal

Camera Configuration

Manual

P/N 1073336-EN • REV C • ISS 21NOV17

2017 United Technologies Corporation.

Interlogix is part of UTC

Climate, Controls & Security

, a unit of United

Technologies Corporation.

Trademarks and

patents

rade names used in this document may be trademarks or

registered trademarks of the manufacturers or vendors of the

respective products.

Manufacturer

Interlogix

2955 Red Hill Avenue, Costa Mesa, CA 92626

-5923, USA

Authorized EU manufacturing representative:

UTC

Building & Industrial Systems B.V.

Kelvinstraat 7, 6003 DH Weert, The Netherlands

Certification

Contact information

For contact information

, see www.interlogix.com or

www.firesecurityproducts.com

TruVision IP Thermal Camera Configuration Manual 1

Content

Introduction 3

Network access 4

Checking your web browser security level 4

Activating the camera 5

Overview of the camera web browser 7

Camera configuration overview 9

Local configuration menu 9

Configuration menu 11

VCA configuration menu 12

Device information 12

System time configuration 13

Network configuration 14

Video and audio configuration 22

Image display configuration 25

OSD parameters 26

Overlay text parameters 28

Privacy mask parameters 29

Picture overlay parameters 30

Detective pixel correction parameters 30

Alarm configuration 32

Motion detection alarms 32

Video tampering alarms 38

Alarm inputs and outputs 39

Exception alarms 40

Audio exception detection 41

Scene change detection 42

Fire source detection 43

Temperature measurement 46

VCA configuration 54

VCA resource type 54

VCA information 54

Behavior analysis 56

Storage configuration 62

Snapshot parameters 62

NAS settings 65

Storage management 66

Recording schedule 67

2 TruVision IP Thermal Camera Configuration Manual

Camera management 69

User management 69

RTSP authentication 72

IP address filter 73

Defining the security service 73

Restore default settings 74

Import/export a configuration file 75

Upgrade firmware 75

Reboot the camera 76

Camera operation 78

Logging on and off 78

Live view mode 78

Playing back recorded video 78

Searching event logs 81

Operating PTZ control 83

TruVision IP Thermal Camera Configuration Manual 3

Introduction

This is the user manual for the following TruVision IP thermal camera models:

TVB-5701 (IP Thermal Bullet Camera, 384x288, 15mm)

TVB-5702 (IP Thermal Bullet Camera, 384x288, 35mm)

TVB-5706 (IP Thermal Bullet Camera, 640x512, 15mm)

TVB-5707 (IP Thermal Bullet Camera, 640x512, 25mm)

4 TruVision IP Thermal Camera Configuration Manual

Network access

This manual explains how to configure the camera over the network with a web

browser.

TruVision IP cameras can be configured and controlled using Microsoft Internet

Explorer (IE) and other browsers. The procedures described use Microsoft Internet

Explorer (IE) web browser.

Checking your web browser security level

When using the web browser interface, you can install ActiveX controls to connect and

view video using Internet Explorer. However, you cannot download data, such as video

and images, due to the increased security measure. Consequently you should check

the security level of your PC so that you are able to interact with the cameras over the

web and, if necessary, modify the Active X settings.

Configuring IE ActiveX controls

You should confirm the ActiveX settings of your web browser.

To change the web browser’s security level:

1. In Internet Explorer, click Internet Options on the Tools menu.

2. On the Security tab, click the zone to which you want to assign a web site under

“Select a web content zone to specify its security settings”.

3. Click Custom Level.

4. Change the ActiveX controls and plug-ins options that are signed or marked as

safe to Enable. Change the ActiveX controls and plug-ins options that are

unsigned to Prompt or Disable. Click OK.

- Or -

Under Reset Custom Settings, click the security level for the whole zone in the

Reset To box, and select Medium. Click Reset.

Then click OK to the Internet Options Security tab window.

5. Click Apply in the Internet Options Security tab window.

Windows Internet Explorer

Internet Explorer operating systems have increased security measures to protect your

PC from any malicious software being installed.

To have complete functionality of the web browser interface with Windows 7, 8, and 10,

do the following:

• Run the browser interface as an administrator in your workstation

• Add the camera’s IP address to your browser’s list of trusted sites

TruVision IP Thermal Camera Configuration Manual 5

To add the camera’s IP address to Internet Explorer’s list of trusted sites:

1. Open Internet Explorer.

2. Click Tools, and then Internet Options.

3. Click the Security tab, and then select the Trusted sites icon.

4. Click the Sites button.

5. Clear the “Require server verification (https:) for all sites in this zone box.

6. Enter the IP address in the “Add this website to the zone” field.

7. Click Add, and then click Close.

8. Click OK in the Internet Options dialog window.

9. Connect to the camera for full browser functionality.

Activating the camera

When you first start up the camera, the Activation window appears. You must define a

high-security admin password before you can access the camera. There is no default

password provided.

You can activate a password by using a web browser and by TruVision Device

Manager (included on the CD to find the IP address of the camera).

Activation via the web browser:

1. Power on the camera and connect the camera to the network.

2. Input the IP address into the address bar of the web browser, and click Enter to

enter the activation interface.

Note:

The default IP address of the camera is 192.168.1.70.

For the camera to enable DHCP by default, you must activate the camera via

TruVision Device Manager. Please refer to the following section, “Activation via

TruVision Device Manager”.

3. Enter the password in the password field.

6 TruVision IP Thermal Camera Configuration Manual

Note: A valid password range must be between 8 and 16 characters. You can use a

combination of numbers, lower and upper case letters, and special characters : _ - ,

. * & @ / $ ? Space. The password must contain characters from at least two of

these groups. We also recommend that you reset your password regularly. For high

security systems, it is particularly recommended to reset the password monthly or

weekly for better protection.

4. Confirm the password.

5. Click OK to save the password and enter the live view interface.

Activation via TruVision Device Manager:

1. Run the TruVision Device Manager to search for online devices.

2. Select the device status from the device list, and select the inactive device.

3. Enter the password in the password field, and confirm it.

Note: A valid password range must be between 8 and 16 characters. You can use a

combination of numbers, lower and upper case letters, and special characters : _ - ,

. * & @ / $ ? Space. The password must contain characters from at least two of

these groups. We also recommend that you reset your password regularly. For high

security systems, it is particularly recommended to reset the password monthly or

weekly for better protection.

4. Click OK to save the password.

A pop-up window appears to confirm activation. If activation fails, confirm that the

password meets the requirements and try again.

5. Change the device IP address to the same subnet with your computer by either

modifying the IP address manually or selecting the check box of Enable DHCP.

TruVision IP Thermal Camera Configuration Manual 7

6. Enter the password and click the Save button to activate your IP address

modification.

Overview of the camera web browser

The camera web browser lets you view, record, and play back recorded videos as well

as manage the camera from any PC with Internet access. The browser’s easy-to-use

controls give you quick access to all camera functions. See Figure 1.

If there is more than one camera connected over the network, open a separate web

browser window for each individual camera.

Figure 1: Web browser interface (Live view shown)

Menu bar

Toolbar

Name

Description

1. Live view Click to view live video.

2. Playback Click to play back video.

3. Log Click to search for event logs. There are three main types: Alarm, Exception and

8 TruVision IP Thermal Camera Configuration Manual

Name

Description

Operation.

4. Configuration Click to display the configuration window for setting up the camera.

5. Viewer View live video. Time, date and camera name are displayed here.

6. PTZ controls Direction actions, zoom, focus, iris, light and wiper control. See page 83 for

further information.

Note: Direction actions, light, and wiper control can be used if the camera

supports RS-485 and the external pan/tilt unit, light or wiper is installed.

7. Current user Displays current user logged on.

8. Logout Click to log out from the system. This can be done at any time.

9. Help Online Help.

10. Display control Click each tab to adjust the layout and the stream type of the live view. You can

also click the drop-down menu to select the plug-in.

For IE (internet explorer) users, web components and quick time are selectable.

For non-IE users, web components, quick time, VLC or MJPEG are selectable if

they are supported by the web browser.

The window size is 4:3.

The window size is 16:9.

The original window size.

Self-adaptive window size.

Live view with main stream.

Live view with substream.

Live view with third stream.

Click to select the third-party plug-in. Select Webcomponents or

QuickTime.

11. Start/stop live

view Click to start/stop live view.

12. Audio

Click to turn audio on/off. Also use the scroll bar to adjust the volume.

13. Bi-directional

audio Turn on/off the microphone for bidirectional audio.

14. Capture Click to capture a snapshot of the video. The snapshot will be saved to

the default folder in JPEG or BMP format.

15. Start/stop

recording Click to manually start/stop recording of live video.

16. Digital zoom

Click to enable digital zoom.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara de seguridad de Interlogix

Interlogix

Interlogix TruVision TVB-2402 Instrucciones de funcionamiento y mantenimiento

Interlogix

Interlogix TruVision TVC-6110-1 Instrucciones de funcionamiento y mantenimiento

Interlogix

Interlogix TruVision TVB-2401 Manual de usuario

Interlogix

Interlogix TruVision Line Manual

Interlogix

Interlogix TruVision TVW-2401 Hoja de instrucciones

Interlogix

Interlogix TVD-5110-3 Manual de usuario

Interlogix

Interlogix TruVision Open Standards Manual de usuario

Interlogix

Interlogix UltraView PTZ Manual de usuario

Interlogix

Interlogix TVB-5301 Manual de usuario

Interlogix

Interlogix 36X Manual de usuario

Interlogix

Interlogix TruVision TVP-5201 Hoja de instrucciones

Interlogix

Interlogix TVF-1101 Manual de usuario

Interlogix

Interlogix TruVision TVC-7120-1-N Manual de usuario

Interlogix

Interlogix TruVision TVB-2101 Manual de usuario

Interlogix

Interlogix TruVision TVW-2401 Manual de usuario

Interlogix

Interlogix TruVision Line Manual de usuario

Interlogix

Interlogix TruVision HD-TVI 3MPX Hoja de instrucciones

Interlogix

Interlogix UltraView UVD-6130VE-2-P Manual de usuario

Interlogix

Interlogix TVB-5501 Manual de usuario

Interlogix

Interlogix TruVision TVT-2103 Manual de usuario

Interlogix

Interlogix TruVision TVB-2402 Manual de usuario

Interlogix

Interlogix MobileView MVC-7100-29-BL Manual de usuario

Interlogix

Interlogix TruVision TVB-2402 Manual de usuario

Interlogix

Interlogix TruVision TVD-2402 Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario
