HP SysMan Manual de usuario

SysMan on iPAQ

Accessing SysMan Menu from an iPAQ Pocket

Part Number: AA-xxxxx-TF

November 2002

Operating System and Version: Tru64 UNIX, Version 5.1 and higher

This document describes the installation procedure and the instructions

for accessing the SysMan Menu from a HP iPAQ Pocket PC.

Hewlett-Packard Company

Palo Alto, California

COMPAQ, the Compaq logo, Tru64, and TruCluster are trademarks of Compaq Information Technologies

Group, L.P. in the U.S. and/or other countries.

Microsoft, Windows, Windows 200, Windows NT, Windows XP, Windows CE, Pocket PC Software 2002, and

ActiveSync are trademarks of Microsoft Corporation in the U.S. and/or other countries. UNIX and The

Open Group are trademarks of the Open Group in the U.S. and/or other countries. All other product names

mentioned herein may be trademarks of their respective companies.

Confidential computer software. Valid license from Compaq Computer Corporation, a wholly owned

subsidiary of Hewlett-Packard Company, required for possession, use, or copying. Consistent with FAR

12.211 and 12.212, Commercial Computer Software, Computer Software Documentation, and Technical

Data for Commercial Items are licensed to the U.S. Government under vendor’s standard commercial

license.

None of Compaq, HP, or any of their subsidiaries shall be liable for technical or editorial errors or omissions

contained herein. The information is provided “as is” without warranty of any kind and is subject to

change without notice. The warranties for HP or Compaq products are set forth in the express limited

warranty statements accompanying such products. Nothing herein should be construed as constituting

an additional warranty.

Contents

1 Installing the Software

1.1 Minimal Requirements .............................................. 1–1

1.1.1 Tru64 UNIX Minimum Requirements ........................ 1–1

1.1.2 Personal Computer Minimum Requirements ................ 1–2

1.1.3 iPAQ Pocket PC Minimum Requirements .................... 1–2

1.2 Transferring SysMan iPAQ software .............................. 1–3

1.2.1 Downloading by way of the Tru64 UNIX System ........... 1–4

1.2.2 Downloading by way of the PC ................................. 1–5

1.3 Installing the sysmanipaq.cab File .............................. 1–5

1.4 Upgrading the Authentication Server ............................. 1–5

1.4.1 Upgrade Determination ......................................... 1–6

1.4.2 Upgrade Procedure .............................................. 1–6

2 Accessing the SysMan Menu

2.1 HostList ............................................................... 2–1

2.1.1 Connecting to the Remote Host ................................ 2–1

2.1.2 AddingHosts ...................................................... 2–1

2.1.3 Modifying Hosts .................................................. 2–2

2.1.4 Deleting Hosts .................................................... 2–2

2.2 Invoking SysMan Menu Applications .............................. 2–2

2.3 Exiting the SysMan Menu ........................................... 2–2

Contents iii

Installing the Software

You can perform system administration tasks remotely on a system running

Tru64 UNIX by using your iPAQ Pocket PC hand-held computer, after you

download and install the SysMan iPAQ software.

1.1 Minimal Requirements

The following section states the minimal requirements for both the

installation and use of the software to access the SysMan Menu from the

iPAQ Pocket PC hand-held computer. These requirements are divided into

these categories:

•Tru64 UNIX requirements

•Personal computer requirements

•iPAQ Pocket PC requirements

The majority of these requirements are easily fulfilled.

1.1.1 Tru64 UNIX Minimum Requirements

•Tru64 UNIX Version 5.1 or higher

For TruCluster systems, all cluster nodes must be running the same

version of the operating system, Version 5.1 or higher.

To verify the version of the Tru64 UNIX operating system on a single

system, enter the following command:

# /usr/sbin/sizer -v

HP Tru64 UNIX V5.1A (Rev. 1885)

To verify the version of the Tru64 UNIX operating system on each node

of a TruCluster system, enter the following command:

# clu_get_info -full | grep "Member cluster version"

The following is output for each node of the TruCluster system:

Member cluster version = HP TruCluster server V5.1A (Rev. 1312)

•Wireless Network support

Installing the Software 1–1

1.1.2 Personal Computer Minimum Requirements

The primary use of the PC is to download files to the iPAQ Pocket PC using

Microsoft®ActiveSync software; the following are required to do so:

•Microsoft Windows®2000, 98, Windows NT®Workstation 4.0 or XP with

a 486/33DX or higher processor (Pentium®90 MHz recommended)1

•Hard disk drive with 10 to 50MB of available hard disk space (actual

requirements will vary based on selection of features and user’s system

configuration)

•Communications port (9 pin or 25 pin, adapter required for 25 pin

communication port) or USB interface.

•CD-ROM drive

•VGA or higher resolution graphics card

•Mouse or compatible pointing device

•Internet Connection (if downloading software to the PC)

•Microsoft ActiveSync Software, version 3.5 or higher.

This software is available from the iPAQ CD-ROM and from the

Microsoft Corporate Web Site, http://www.microsoft.com.

1.1.3 iPAQ Pocket PC Minimum Requirements

The following requirements are necessary for the installation and use of

the SysMan iPAQ software.

•32MB of RAM, with 256KB free for Storage and 256KB free for Programs.

You can verify the available capacity by tapping Start, then Settings,

then System, then Memory.

•206MHz processor

•Microsoft®Pocket PC Software (Microsoft Windows CE 3.0 or greater)

Verify the iPAQ Pocket PC’s operating system version by tapping

Settings in the Start Menu, then System, then About.

•Either the Serial connections and cable2or the Docking Cradle with

cable.

•Wireless card

•Java 2 Run Time Environment

1required for Microsoft ActiveSync.

2USB interface can be used instead of serial connection.

1–2Installing the Software

This software may not be installed on your iPAQ Pocket PC; it is

available from the Pocket PC companion CD, which accompanies the

iPAQ 3800 series and 3900 series.

1.2 Transferring SysMan iPAQ software

The software that enables the iPAQ Pocket PC to access the Tru64

UNIX SysMan Menu is available over the Internet at the following URL:

http://www.tru64unix.compaq.com/ipaq

There are other useful files, including this document in PDF format, at this

site also.

The software consists of the following components:

sysmanipaq.cab This cab file contains the client software that you

install on the iPAQ Pocket PC. The remainder of this

section describes the various ways you can download

this software to the iPAQ Pocket PC. Section 1.3

describes how to install the software on the iPAQ

Pocket PC.

smauth.jar This is a Java archive file containing the

Authentication Server. This file is installed on a

Tru64 UNIX V5.1A system or on only one node of a

TruCluster system (it is a shared file). Transferring

and installing this file is discussed in Section 1.4.

smauth.jar_v51 This is a Java archive file containing the

Authentication Server for Tru64 UNIX. This file is

installed on a Tru64 UNIX V5.1 system or on only

one node of a TruCluster system (it is a shared file).

Transferring and installing this file is discussed in

Section 1.4.

These files can be downloaded individually or in an archive. Two types of

archive files, tar and zip, are available. You must extract the files from

the archive after downloading them.

While the smauth.jar is downloaded directly to the Tru64 UNIX system,

there are two methods for downloading the sysmanipaq.cab file onto the

iPAQ Pocket PC, as shown here:

From theweb site to the Tru64 UNIX system to the PC to the iPAQPocket PC

From theweb site to the PC to the iPAQPocket PC

Installing the Software 1–3

These methods are described in the following sections.

1.2.1 Downloading by way of the Tru64 UNIX System

Transfer the sysmanipaq.cab file from the web site to the Tru64 UNIX

system, then to the PC, then to the iPAQ Pocket PC as follows:

1. Use a browser to download the sysmanipaq.cab file from the web

site (http://www.tru64unix.compaq.com/ipaq) to a temporary

directory on the Tru64 UNIX system. If you download an archive file,

you need to extract the sysmanipaq.cab file.

2. Ensure that the Tru64 UNIX system and PC are able to communicate.

3. Use the Tru64 UNIX ftp or the PC’s WS_FTP32 (FTP-32 Client for

Windows) to transfer the sysmanipaq.cab file to My Documents

folder on the PC.

4. Ensure that the PC and the iPAQ Pocket PC are properly connected

using the serial or USB cable.

5. Invoke the Microsoft ActiveSync Software from the PC.

6. Select the Explore button.

A window displaying the contents of the iPAQ Pocket PC appears.

7. Drag the sysmanipaq.cab icon from the My Documents folder

and drop it in the My Documents folder in the ActiveSync window.

Alternatively, you can use the Cut and Paste commands.

This step transfers the SysMan iPAQ software to the iPAQ Pocket PC.

8. Verify the success of the transfer by using the iPAQ Pocket PC’s File

Explorer to locate the sysmanipaq.cab file in the My Documents

folder. You can access the File Explorer by tapping Start, then

Programs, then File Explorer.

____________________ Note _____________________

Repeat the transfer if you do not see the sysmanipaq.cab in

the My Documents folder.

Proceed to Section 1.3 to install this software on the iPAQ Pocket PC.

1–4Installing the Software

1.2.2 Downloading by way of the PC

Transfer the sysmanipaq.cab from the web site to the PC, then to the

iPAQ Pocket PC:

1. Use a browser to download the sysmanipaq.cab file from the web site

(http://www.tru64unix.compaq.com/ipaq) to the My Documents

folder of the PC. If you download an archive file, you need to extract

the sysmanipaq.cab file.

2. Ensure that the PC and the iPAQ Pocket PC are properly connected

using the serial or USB cable.

3. Invoke the Microsoft ActiveSync Software from the PC.

4. Select the Explore button.

A window displaying the contents of the iPAQ Pocket PC appears.

5. Drag the sysmanipaq.cab icon from the PC’sMy Documents folder

and drop it in the My Documents folder in the ActiveSync window.

Alternatively, you can use the Cut and Paste commands.

This step transfers the SysMan iPAQ software to the iPAQ Pocket PC.

6. Verify the success of the transfer by using the iPAQ Pocket PC’s File

Explorer to locate the sysmanipaq.cab file in the My Documents

folder. You can access the File Explorer by tapping Start, then

Programs, then File Explorer.

____________________ Note _____________________

Repeat the transfer if you do not see the sysmanipaq.cab in

the My Documents folder.

Proceed to Section 1.3 to install this software on the iPAQ Pocket PC.

1.3 Installing the sysmanipaq.cab File

Locate the SysMan iPAQ software in the iPAQ Pocket PC’sMy Documents

folder.

Simply tap the SysMan file and the software installs itself.

Verify the installation by tapping Start. The command SysMan will be in

the Start menu.

1.4 Upgrading the Authentication Server

You may need to upgrade the Authentication Server on a Tru64 UNIX

system before you can access the SysMan Menu from the iPAQ Pocket PC.

Installing the Software 1–5

1.4.1 Upgrade Determination

There is an instance when you should not upgrade the authentication server.

If you have not installed patches to your Tru64 UNIX V5.1A system, you can

use the procedure in Section 1.4.2 to upgrade the Authentication Server. If

patches have been installed, or you are not sure, use the following procedure

to determine whether this applies to your system.

1. Invoke the dupatch utility, which is delivered with each patch kit.

The Main Menu is displayed.

2. Select item 4, “Patch Tracking”from the Main Menu.

The Patch Tracking Menu is displayed.

3. Select item 2, “List installed patches”from the Patch Tracking Menu.

The Patch Tracking Selection Menu is displayed.

4. Select item 3, “List All Files”from the Patch Tracking Selection Menu.

5. Look for /usr/share/sysman/web/classLib/smauth.jar in the

list of displayed files.

If this file is listed, do not upgrade the Authentication Server.

If this file is not listed, proceed to Section 1.4.2 to upgrade the

Authentication Server.

1.4.2 Upgrade Procedure

Use the following procedure to upgrade the authentication server:

1. Log in as root on the Tru64 UNIX system.

2. Change directory and back up the current Authentication Server.

# cd /usr/share/sysman/web/classLib

# cp smauth.jar smauth.jar.orig

3. The next step differs depending on the version of Tru64 UNIX you are

running.

If you are running Tru64 UNIX V5.1A :

Use a browser to download the Authentication Server from the

following web site: http://www.tru64unix.compaq.com/ipaq.

If you have transferred this file as part of an archive, extract

the smauth.jar file from the archive and move it to the Tru64

UNIX system.

1–6Installing the Software

Tabla de contenidos

Otros manuales de Software de HP

HP AA-RTDRB-TE Manual de usuario

HP Integrity rx2800 - i2 Manual de usuario

HP AE370A - Brocade 4Gb SAN Switch 4/12 Manual de servicio

HP Xw460c - ProLiant - Blade Workstation Manual de usuario

HP 345646-001 - StorageWorks NAS 2000s External Storage... Instrucciones de instalación y funcionamiento

HP HPE XP P9500 Manual de usuario

HP T6553 D45 Manual de usuario

HP AJ765A - StorageWorks RDX Removable Disk Backup... Manual de instrucciones

HP C7791C - DesignJet 130 Color Inkjet Printer Guía de configuración

HP 6200C Manual de usuario

HP SN3000B Manual de servicio

HP C7791C - DesignJet 130 Color Inkjet Printer Guía de configuración

HP Quality Center Synchronizer 1.2 Manual de usuario

HP ProLiant StorageWorks NAS 2000s Manual de usuario

HP Integrity BL860c Manual de servicio

HP HPE XP P9500 Manual de usuario

HP D5970A - NetServer - LCII Manual de usuario

HP LASERJET PRO 400 Manual de servicio

HP Xw4300 - Workstation - 2 GB RAM Guía de referencia rápida

HP 413742-001 Manual de usuario

HP NC373m - PCI Express Dual Port Multifunction Gigabit Server... Manual de usuario

HP T5725 - Compaq Thin Client Manual de instrucciones

HP 8/20q Manual de usuario

HP JetCAPS Manual de usuario

Manuales populares de Software de otras marcas

COMPRO

COMPRO COMPROFM Manual de usuario

Muratec

Muratec OFFICEBRIDGE ONLINE Manual de usuario

Oracle

Oracle Contact Center Anywhere 8.1 Manual de usuario

Adobe

Adobe 65007312 - Photoshop Lightroom Manual

Avaya

Avaya NULL One-X for RIM Blackberry Manual de usuario

PS Audio

PS Audio PowerPlay Manual del propietario

Brady

Brady LOCKOUT PRO 3.0 Manual de servicio

Avaya

Avaya Interaction Center Manual de usuario

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manual

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manual de usuario

Oracle

Oracle Application 9i Manual de usuario

Acer

Acer RDM Manual de usuario

Canon

Canon Vixia HF21 Manual de usuario

Canon

Canon ZR950 Manual de usuario

Samsung

Samsung Auto Backup Manual de usuario

Polycom

Polycom Vortex EF2201 Instrucciones de instalación y funcionamiento

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manual de usuario

Novell

Novell SP2 - S Manual de instrucciones
