Festo CDVI Series Manual de lista de piezas
Brief description
Clean design
valve terminal
CDVI... (type 15)
with multipin
connector
– English
8080200
2017-12d
[8080193]
Valve terminal type 15
Festo CDVI... 2017-12d2
Translation of the original instructions
Documentation on the product
For all available product documentation
èwww.festo.com/pk
Copyright:
Festo SE & Co. KG
Ruiter Straße 82
73734 Esslingen
Germany
Internet: http://www.festo.com
E-Mail: service_international@festo.com
Reproduction, distribution or sale of this document or communication of
its contents to others without express authorization is prohibited.
Offenders will be liable for damages. All rights reserved in the event that
a patent, utility model or design patent is registered.
English 3............................................
Festo CDVI... 2017-12d English 3
1 User instructionsEnglish
The CDVI has been designed exclusively for controlling
pneumatic actuators. The maximum values specified in
the section “Technical specifications” must be observed
here. Detailed information can be found in the Pneumatics
manual P.BE-CDVI-... .
Warning
SSwitch off the power supply before connecting or
disconnecting plugs. You can thereby avoid func
tional damage.
SUse only power units which guarantee reliable
electrical isolation of the operating voltage as per
IEC/DIN EN 60204-1. Observe also the general
requirements for PELV power circuits as per
IEC/DIN EN 60204-1.
SMake sure that there is a conductive connection with
sufficient cross-sectional area between the CDVI and
the earthed mounting surface or earthed machine
rack.
Please note
Commission only a valve terminal which has been fitted
and wired completely.
Please observe the instructions for connecting the
“pressure compensation” in the manual P.BE-CDVI-... .
Festo CDVI... 2017-12d English4
2 Multi-pin connection
2.1 Multi-pin plug
Each valve solenoid coil must be assigned to a specific pin
of the multi-pin plug in order that the valves can be actu
ated. A valve position always occupies two addresses on
the base block, irrespective of whether it is fitted with a
blanking plate, separator plate or valve sub-base. The
number of addresses which a valve position occupies in
the expansion blocks depends on the expansion blocks
used.
Bi = expansion block which occupies 2 addresses
Mo = expansion block which occupies 1 address
Extension blocks
Occupies 1 address per valve
position:
CDVI5.0-EB...MP-Mo
Occupies 2 addresses per valve
position:
CDVI5.0-EB...MP-Bi
Caution
The components of the valve terminal contain electro-
statically sensitive elements. The components will be
damaged if you touch the contact surfaces of the plug
connectors or if you do not observe the regulations for
handling electrostatically sensitive components.
Long signal lines reduce the immunity to interference.
Do not exceed the maximum permitted signal line
length of 10 m.
Festo CDVI... 2017-12d English 5
The multi-pin plug is fitted in the left-hand end plate at
the factory.
The following diagram shows the pin numbering of the
multi-pin plug in the left-hand end plate of the valve ter
minal (view of plug):
A01 A10
B10
C10C01
B01
2.2 Pin allocation of the multi-pin plug
Notes on the following table:
– Designation of the core colours as per DIN/IEC 757
– The multi-pin cable has 27 cores. Only 26 cores
are used. The remaining core can be cut back (core
colour see following table).
Festo CDVI... 2017-12d English6
Please note the following addressing rules:
The following table shows the address assignment of
the manifold blocks.
Further address assignment depends on the type of
the expansion block.
2 Bi-expansion block = 4 addresses
2 Mo-expansion block = 2 addresses
1 Bi-expansion block = 2 addresses
1 Mo-expansion block = 1 address
Complete the assignment list (following table) according
to the expansion blocks used on your valve terminal.
Please note
Maximum 8 addresses can be addressed in the exten
sion.
Festo CDVI... 2017-12d English 7
Pin Address Core
colour
Valve location/sole
noid coil
Pins Sub-D
37-pin
4-group
manifold
block
8-group
manifold
block
Test adapter
A01
A02
B01
B02
C01
C02
A03
A04
B03
B04
C03
C04
A05
A06
B05
B06
C05
C06
A07
A08
B07
B08
C07
C08
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
WH
GN
YE
GY
PK
BU
RD
VT
GY PK
RD BU
WH GN
BN GN
WH YE
YE BN
WH GY
GY BN
WH PK
PK BN
WH BU
BN BU
WH RD
BN RD
WH BK
BN BK
0/14
0/12
1/14
1/12
2/14
2/12
3/14
3/12
_ _ _
_ _ _
_ _ _
_ _ _
_ _ _
_ _ _
_ _ _
_ _ _
_ _ _
_ _ _
_ _ _
_ _ _
_ _ _
_ _ _
_ _ _
_ _ _
0/14
0/12
1/14
1/12
2/14
2/12
3/14
3/12
4/14
4/12
5/14
5/12
6/14
6/12
7/14
7/12
_ _ _
_ _ _
_ _ _
_ _ _
_ _ _
_ _ _
_ _ _
_ _ _
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
B10
C10
-----
-----
-----
-----
BN
BK
GY GN 2)
0 V 1)
0 V 1)
-------
0 V 1)
0 V 1)
-------
25
26
27-37 3)
1) Apply 0 V with positive-switching control signals; apply 24 V with
negative-switching control signals. Mixed operation is not
permitted. The contacts B10 and C10 are connected internally.
2) This core is not used and can be cut back.
3) Unused
Festo CDVI... 2017-12d English8
3 Controlling the valve terminal
Use a uniform method of control. Preferably all control
signals should be positive-switching (1-switching), other
wise all control signals negative-switching (0-switching).
Mixed mode control is not permitted.
3.1 Address assignment of the valves
– Assign the addresses in ascending order without gaps.
– Counting begins from left to right, but on the individ
ual valve positions from right to left.
– A valve position occupies 2 addresses on the manifold
block and Bi-expansion block, even if it is fitted with a
blanking plate. On the Mo-expansion block 1 address
will be assigned.
– In the case of valves with two pilot solenoids, pilot
solenoid 14 occupies the lower-value address and
pilot solenoid 12 occupies the higher-value address.
– In the case of valves with only one pilot solenoid on
Bi-blocks, the higher-value address remains unused.
Festo CDVI... 2017-12d English 9
01 2
34
56
78
91011 12 13 1415
1214
12 14 12 14 1214 1214 14 1214
4
3215
67
14-group manifold block
22 Bi-expansion block
32 Mo-expansion block
41 Bi-expansion block
5Addresses of the solenoid
coils
6Reserve location on the
Mo-expansion block
(occupies 1 address)
7Reserve location on the
4-group manifold block
(occupies 2 addresses)
Festo CDVI... 2017-12d English10
4 Technical specifications
Type CDVI5.0-...
Dimensions See Pneumatics Manual
Number of valve positions 4, 6, 8, 10, 124) / 4, 5,...165)
Control voltage:
– Rated value (protected against
incorrect polarity)
– Tolerance
– Total permitted current
24 V DC
± 10 % (21.6 V ... 26.4 V DC)
2880 mA
Protection class with completely fitted
CDVI (with fitted plugs or covers)
IP65, IP66, IP67 as per EN 60529,
Type 4 1) as per NEMA250
Temperature ranges/storage duration
– Ambient/medium temperature
– Storage temperature
– Recommended storage duration
- 5 ... + 50 °C
- 20 ... + 40 °C
max. 18 months
Materials See Pneumatics manual
Electromagnetic compatibility
– Interference emission
– Immunity to interference 3)
Tested as per EN 61000-6-4
(industry) 2)
Tested as per EN 61000-6-2
(industry)
1) Type 4 (hosedown test, test no. 5.7)
2) The CDVI valve terminal is intended for industrial usage.
3) The maximum permitted signal line length is 10 m.
4) For exclusive use of Bi-blocks in the extension
5) For exclusive use of Mo-blocks in the extension
