Overview

The Unison Foundry 0–10 V Controller provides fully-rated 20 A relays for

switched power control with 0–10 V dimming for compatible fluorescent

ballasts and LED drivers. The 0–10 V Controller provides two outputs of

control that can be wired to individual fixtures or used for zone control.

Each output can be configured to a separate DMX address, or both outputs

can be controlled in unison by setting the 0–10 V Controller to single-

channel mode (see

Channel Mode

page 8

Control connected loads from any DMX control device. Configure the

0–10 V Controller either remotely via RDM (using a tool like Concert) or

locally on the controller. See

Configure the 0–10 V Controller

page 8

Specifications

Ambient Environment

For indoor use only. Rated for plenum use.

• 0°C to 50°C (32°F to 122°F) operating temperatures in 5%–95%

non-condensing humidity.

ETC Installation Guide

0–10 V Controller

0–10 V Controller Page 2 of 16 ETC

Electrical Specification

The 0–10 V Controller Supports:

• Power input 120–277 VAC, 60 Hz

• Load rating:

- 20 A general purpose, tungsten, or resistive

- 16 A electronic ballast

• Independent control for 0–10 V fluorescent ballasts and/or LED

drivers, each is capable of sinking 100 mA

Compliance

• cULus listed

• Conforms to UL 508 (Industrial Control Equipment), UL 916 (Energy

Management Equipment) and UL 2043 (Plenum rated)

• Certified to CSA C22.2 No. 14 (Industrial Control Equipment) and

No. 205 (Signal Equipment)

Note:

The maximum load on the 0–10 V Controller can be

split between the two relay outputs in any

combination required for the installation, but cannot

exceed the maximum load as specified above.

FCC Compliance

Unison Foundry 0–10 V Controller

(For any FCC matters):

Electronic Theatre Controls, Inc.

3031 Pleasant View Road

Middleton, WI 53562

+1 (608) 831-4116

etcconnect.com

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept

any interference received; including interference that may cause undesired operation. Visit

etcconnect.com/products

for current and complete compliance information including FCC

compliance.

Note:

This equipment has been tested and found to comply with the

limits for a Class A digital device, pursuant to Part 15 of the FCC

rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in

a commercial environment. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and used

in accordance with the instructions, may cause harmful

interference to radio communications. Any modifications or

changes to this product not expressly approved by Electronic

Theatre Controls, Inc. could void the user’s authority to operate

the product. Operation of this equipment in a residential area is

likely to cause harmful interference, in which case the user will be

required to correct the interference at their own expense.

ETC Installation Guide

0–10 V Controller

0–10 V Controller Page 3 of 16 ETC

Prepare for Installation

The 0–10 V Controller is designed for mounting directly to an electrical

junction box or panel (provided by others) at the electrical lighting load,

upstream of the load in the circuit.

DMX Control Wiring

The 0–10 V Controller connects to a DMX512-A source (provided by ETC or

others) for control.

DMX wiring runs can be daisy chains of up to 32 devices with no Y’s or

loops. Each DMX daisy chain must be terminated for proper control

performance (see

Terminate DMX

page 5

ETC recommends using Belden 9729 (or approved equivalent) Class 2 wire.

Belden 1583A or equivalent Cat5, Cat5e, or Cat 6 UTP wire is also acceptable

when properly shielded or installed in grounded metal conduit.

A voltage barrier installation box (part number 7187A1000) is available for

installations where DMX control wiring is installed in grounded metal

conduit. Contact ETC to purchase voltage barrier installation boxes if

required.

The total combined length of a DMX wire run (using Belden 9729 or

equivalent) may not exceed 300 m (1,000 ft).

Note:

If your installation requires Class 2 wiring to be

installed in separate conduit, a voltage barrier

installation box is available from ETC. Order ETC part

number 7187A1000.

Note:

All control wiring should be installed and terminated

by a qualified installer and should follow standard

wiring installation practices.

Leave approximately 20 cm (8 in) of wiring available for

connection and to allow slack for future service needs

Note:

For more information on DMX control wiring

requirements, see these and other Support Articles at

etcconnect.com:

• support.etcconnect.com/ETC/FAQ/DMX-512-Info

• support.etcconnect.com/ETC/FAQ/DMX_Over_Cat5

ETC Installation Guide

0–10 V Controller

0–10 V Controller Page 4 of 16 ETC

Installation

Installation should follow all local codes and standard electrical practices.

Ensure that the junction box is clean and free of obstructions and that all

wiring is installed correctly.

1. Locate the circuit breaker panel and turn off the power to the lighting

circuit.

2. To gain access to the line voltage wiring, remove the cover plate and

other hardware from the junction box at the load.

3. Mount the 0–10 V Controller to the exterior of the junction box or

panel using the 1/2 in threaded nipple. Use the provided 1/2 in conduit

locknut to secure the 0–10 V Controller to the junction box or panel.

WARNING:

Risk of electric shock! This device utilizes high

voltage and should only be installed by a qualified

installer or electrician. Follow all local codes for

installation. Before terminating the AC power

wiring verify that the main breaker is in the off

position and follow the proper lockout/tag out

procedures per NFPA Standard 70E.

AVERTISSEMENT :

Risque de décharge électrique! Cette appareil

utilise une haute tension et ne doit être installé

que par un installateur qualifié ou un électricien.

Suivez tous les codes locaux pour l'installation.

Avant de raccorder le câblage du courant

alternatif, vérifiez que le disjoncteur principal est

en position d'arrêt et suivez les procédures de

Consignation/Déconsignation prescrites par la

norme NFPA 70E.

WARNING:

For indoor use only! Must install to an electrical

junction box or wireway.

AVERTISSEMENT :

Uniquement pour usage d'intérieur! Doit être

installé sur une boîte de raccordement électrique

ou un chemin de câbles.

ETC Installation Guide

0–10 V Controller

0–10 V Controller Page 5 of 16 ETC

Connect DMX

1. Pull wiring to the junction box.

2. Terminate the DMX cable by following the steps in the termination kit

supplied with the unit.

Terminate DMX

Terminate the last device in the DMX data run for proper control

performance. To terminate the DMX data run at the 0–10 V Controller,

connect the last two pins on the termination connector with a wire jumper

(not included).

Note:

Follow all local code requirements for terminating

wire.

• Notice that the harness wires on the controller are

pre-stripped for your installation convenience.

• Use appropriately sized wire nuts (not provided) to

secure each termination.

Note:

Because resistance is built into the 0–10 V Controller,

no additional resistor is required to terminate the last

device in the DMX data run.

ETC Installation Guide

0–10 V Controller

0–10 V Controller Page 6 of 16 ETC

Connect Power Input and Relay Output

The power input and relay output wiring exits the 0–10 V Controller

through the knockout mount on the enclosure.

1. Connect the power input wiring.

a. Connect the white wire (14 AWG) to the incoming neutral wire

from the breaker panel and the neutral wire of the lighting load.

b. Connect the black power input wire (12 AWG) to the line input

feed wire (hot) from the breaker panel.

2. Connect the relay output wiring. The 0–10 V Controller has two relay

output wires (12 AWG): Zone 1 is red and Zone 2 is red/white.

a. Connect the Zone 1 relay output wire (red) to the hot input of the

first load.

b. Connect the Zone 2 relay output wire (red/white) to the hot input

of the second load.

Note:

When configured to single-channel mode, a single

DMX address controls both relays. If you are using only

one output, cap off the unused wires with wire nuts

(not included).

DMX-512A

Black

Line In

White

Neutral

Load 1

Red

Load 2

Red/White

Dimming

Ballast 1

Dimming

Ballast 2

Gray

0–10 V

Violet Gray/White

0–10 V

Violet/White

ETC Installation Guide

0–10 V Controller

0–10 V Controller Page 7 of 16 ETC

Connect 0–10 V Dimming Output

The 0–10 V dimming output wiring exits the 0–10 V Controller through the

top nipple of the enclosure with the power wiring.

1. Connect the 0–10 V dimming output wiring. The 0–10 V Controller

has two pairs of 0–10 V output wires (18 AWG): Zone 1 is gray and

violet, and Zone 2 is gray/white and violet/white.

a. Connect the Zone 1 output wires, gray (-) and violet (+), to the

control input of the connected load.

b. Connect the Zone 2 output wires, gray/white (-) and

violet/white (+), to the control input of the second connected

load.

2. Reinstall the junction box cover plate.

WARNING:

RISK OF DEATH OR INJURY BY ELECTRIC SHOCK!

0–10 V wiring may not be fully isolated from high

voltage AC power. Do not assume that 0–10 V

wiring is safe to touch, even when run as an NEC

Class 2 signal. Test for AC voltage to ground before

terminating any 0–10 V control wiring to the

device.

AVERTISSEMENT :

RISQUE DE MORT OU DE BLESSURE PAR

ÉLECTROCUTION! Le câblage 0–10 V peut ne pas

être complètement isolé du courant alternatif

haute tension. Ne supposez jamais que le câblage

0–10 V peut être touché en toute sécurité, même

s'il est utilisé avec un signal NEC de Classe 2. Testez

la tension alternative par rapport à la terre avant

de raccorder tout câblage de commande 0–10 V à

l'appareil.

CAUTION:

The 0–10 V control outputs must be treated as

NEC Class 1 control signals, in the same manner as other

high voltage connections.

ETC Installation Guide

0–10 V Controller

0–10 V Controller Page 8 of 16 ETC

Configure the 0–10 V Controller

You can use RDM to set the DMX address and data loss behavior for the

0–10 V Controller. You can set other parameters using RDM, too. See

RDM

Parameters

page 15

Channel Mode

You can configure the 0–10 V Controller to single-channel or dual-channel

mode using Concert or another RDM controller.

• Single-channel mode: Both relays are assigned to a single DMX

address and function in unison.

• Dual-channel mode: Each relay is assigned a separate DMX address

for control. The second DMX address is always the next sequential

address after the first DMX address, and this cannot be changed. The

0–10 V Controller ships from the factory in dual-channel mode. See

RDM Parameters

page 15

You can also switch between single-channel mode and dual-channel mode

using the SET button on the 0–10 V Controller. Press and hold the SET

button to switch modes. The POWER LED will blink once for single-channel

mode or twice for dual-channel mode.

DMX Address

You can assign DMX addresses to an entire daisy chain of Unison Foundry

devices using Concert or another RDM controller. If you cannot assign the

DMX addresses using RDM, you can manually set the DMX start address on

the device. The default factory-set DMX address is 1, and the range of

available addresses is 1–512.

ETC Installation Guide

0–10 V Controller

0–10 V Controller Page 9 of 16 ETC

Manually Set the DMX Address

If you cannot assign the DMX addresses using RDM, use the MODE and SET

buttons to set the value of each digit in the three-digit DMX address in

sequence.

Task What to do What you will see

1: Put the controller

into DMX addressing

mode.

Press and hold the MODE

button.

•ThePOWER LED indicator blinks

3 times to indicate that you can set the

100s digit of the DMX address.

•TheSIGNAL LED indicator blinks the

100s digit in the current DMX address.

For example, if the current DMX

address is 201, the SIGNAL LED

indicator blinks 2 times. (If the 100s

digit is a 0, the indicator remains lit and

does not blink.)

2: Set the 100s digit

of the DMX address.

Press the SET button to

set the 100s digit. For

example, press the button

once for 1, twice for 2,

and so forth up to five

times for 5. Press and hold

the SET button for 0.

If the 100s digit in the

new DMX address is the

same as in the current

DMX address, you can

keep the digit by skipping

to step 3.

•ThePOWER LED indicator continues to

blink 3 times to indicate that you are

setting the 100s digit of the DMX

address.

•TheSIGNAL LED indicator blinks the

value that you set for the 100s digit in

the DMX address.

SIGNAL LED

POWER LED

MODE button

SET button

201

10s 1s100s

ETC Installation Guide

0–10 V Controller

0–10 V Controller Page 10 of 16 ETC

3: Set the 10s digit of

the DMX address.

Press the MODE button to

advance to the 10s digit.

•ThePOWER LED indicator blinks

2 times to indicate that you are setting

the 10s digit of the DMX address.

•TheSIGNAL LED indicator blinks the

10s digit in the current DMX address.

For example, if the current DMX

address is 201, the SIGNAL LED

indicator remains lit and does not blink.

•IftheSIGNAL LED indicator rapidly

blinks red, this means that you set the

100s digit to an invalid value (for

example, 6). When this occurs, the

0–10 V Controller exits DMX

addressing mode without saving.

Press the SET button to

set the 10s digit. For

example, press the button

once for 1, twice for 2,

and so forth up to nine

times for 9. Press and hold

the SET button for 0.

If the 10s digit in the new

DMX address is the same

as in the current DMX

address, you can keep the

digit by skipping to step 4.

•ThePOWER LED indicator continues to

blink 2 times to indicate that you are

setting the 10s digit of the DMX

address.

•TheSIGNAL LED indicator blinks the

value that you set for the 10s digit in

the DMX address.

Task What to do What you will see

201

10s 1s100s

Tabla de contenidos

Otros manuales de Controladores de ETC

ETC

ETC QuickTouch Preset Manual de usuario

ETC

ETC Foundation Rigging Controller Manual de instalación y operación

ETC

ETC ArcSystem Pro D4 Series Manual de usuario

ETC

ETC Echoflex ELED3 Manual de usuario

ETC

ETC Echoflex ELED1-BUN Manual de usuario

ETC

ETC ION Manual de usuario

ETC

ETC echoflex ElahoTouch Manual de usuario

ETC

ETC echoflex ELEDR Manual de usuario

ETC

ETC Echoflex Elaho Inspire Station Instrucciones de funcionamiento

ETC

ETC Unison Aero Relay Controller Manual de usuario

ETC

ETC ArcSystem Navis 100 Manual de usuario

ETC

ETC Unison Mosaic Manual de usuario

ETC

ETC QuickTouch Preset Handheld Manual de usuario

ETC

ETC echoflex ELED1 Manual de usuario

ETC

ETC Echoflex ELED3 Manual de usuario

ETC

ETC QuickTouch Preset Manual de usuario

ETC

ETC PENKO Flex Manual de usuario

ETC

ETC F-Drive W1 Series Manual de usuario

ETC

ETC F-Drive W1 Series Manual de usuario

ETC

ETC Expression Guía de configuración

ETC

ETC Echoflex ELED2-BU Manual de usuario

ETC

ETC QuickTouch+ Mk2 Manual de usuario

ETC

ETC DMX DEBC-1 Manual de usuario

ETC

ETC Unison Foundry Relay Controller Manual de usuario

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

Emerson

Emerson SW93 Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario
