ETC Echoflex ElahoTouch Manual de usuario

Part Number: 8186M1283-3.1.0 Rev.A

Released: 2020-03

ElahoTouch Controller

User Manual

3.1.0

To view a list of trademarks and patents, go to etcconnect.com/ip.

All other trademarks, both marked and not marked, are the property of their respective owners.

ETC intends this document, whether printed or electronic, to be provided in its entirety.

Table of Contents

Table of Contents i

Introduction 1

Help from Technical Services 2

ElahoTouch Overview 3

Channels 3

Working with Dimmers / Intensity 3

Selected channels 3

Channel Map 3

Available Controls 4

Wheel 4

Clear Selection 4

Lockout 4

Pages 4

Add Page 5

Name Page 5

Remove Page 5

Layout Mode 5

Add Item 6

Edit Item 7

Remove Item 8

Getting Started With Patching 9

Patch 9

Add Elaho Zone 10

Patching an Elaho Zone 10

Add Dimmer 10

Duplicate Cell 10

Add Device 11

Patching a Device 11

RDM 12

Identify 12

Loading a Fixture Personality 12

Show Universes / Show Channel Map 13

Invert Pan 13

Invert Tilt 13

Swap Pan and Tilt 14

Remove 14

Controlling Parameters 15

Parameter 15

Parameter, All 15

Parameter, Position 16

Recording a Position Palette 17

Using Position Palettes 17

Nudge 17

Parameter, ColorMix 18

Whites 20

Record Color Palette 20

Parameter, Beam 21

Recording a Beam Palette 21

Using Beam Palettes 22

Parameter, Lamp Commands 22

Parameter, Home 22

Home All 22

Home Position 23

Home ColorMix 23

Home Beam 23

Recording Your Looks For Playback 24

Record 24

Presets 24

ii ElahoTouch User Manual

Re-recording Presets 24

Multi Space Presets 24

Off 25

Record Sequence 26

Store And New 26

Store And Exit 26

Include Options 26

Edit Sequence List 27

New Step 27

Copy Step 27

Delete Step 28

Edit Step 28

System Settings and Setup 29

Setup 29

Settings 29

Settings: General 29

Settings: Hardware 30

Settings: Network 30

Settings: Security 31

Settings: Display 31

Settings: Presets 32

Settings: TimeClock 32

Timed Events 33

Scheduled Timed Events 34

Open Hours 34

Holds 35

Showfile Management 36

Files 36

All filing operations: 36

Show files: 36

Advanced: 36

File, New 36

File, Open 36

File, Save 36

Table of Contents iii

File, Save As 37

File, Import 37

File, Export 38

File, Delete 38

Files, Show files 39

Format 39

Functions 39

Save As Default 39

Remove Default Show 39

Files, Advanced 40

Functions 40

Update Firmware 40

Install Extras 40

Export Logs 40

Installing Language Packs 40

EULA 41

iv ElahoTouch User Manual

Table of Contents v

1 ElahoTouch User Manual

Introduction

This manual is for use with ElahoTouch.

In order to be specific about where features and commands are found, the following naming and

text conventions will be used:

•

Buttons, Browser menus, and commands are indicated in bold text. For example: In the

File menu, click Open.

•

Alphanumeric keyboard buttons are indicated in all CAPS. For example, ALT or CTRL.

•

References to other parts of the manual are indicated in underlined blue (for example,

Patch). When viewing this manual electronically, click on the reference to jump to that

section of the manual.

Note:

Notes are helpful hints and information that is supplemental to the main text.

CAUTION:

A Caution statement indicates situations where there may be undefined or

unwanted consequences of an action, potential for data loss or an equipment problem.

WARNING: A Warning statement indicates situations where damage may occur, people

may be harmed, or there are serious or dangerous consequences of an action.

Please email comments about this manual to:TechComm@etcconnect.com

Introduction 2

Help from Technical Services

If you are having difficulties, your most convenient resources are the references given in this

document. To search more widely, try the Echoflex website at echoflexsolutions.com. If none of

these resources are sufficient, contact Technical Services directly at the office identified below.

When calling for assistance, please have the following information handy:

•

Model and serial number (located on back panel)

•

Facility name

•

Other components in your system ( other control devices, LED fixture types, etc.)

Echoflex

38924 Queensway Unit #1

Squamish, British Columbia

Canada, V8B 0K8

888-324-6359 (toll-free)

+1-778 733-0111

info@echoflexsolutions.com

3 ElahoTouch User Manual

ElahoTouch Overview

ElahoTouch is an all-in-one flush or surface mounted touchscreen that provides control of up to

16 Elaho channels per Elaho space, as well as connectivity with other Elaho control and output

products.

ElahoTouch also provides local control of a full universe of DMX and sACN or Art-Net outputs,

and is an RDM controller for compatible and enabled devices.

The topics found in this manual can also be found on your touchscreen by pressing the

button.

Channels

A channel is used by ElahoTouch to control fixtures. ElahoTouch can control up to 80 channels.

There are four types of channels: an Elaho Zone, a dimmer, a group of dimmers, a device, for

example a color changing or moving fixture.

Channels need to be configured in Patch for there to be output.

Note:

Elaho channels are not patched to a DMX value, instead they communicate over

EchoConnect to other Elaho devices. Only 16 channels can be assigned per space.

Working with Dimmers / Intensity

You can use the touchscreen and select channels directly on the Channel Map. The wheel can

then be used to assign an intensity level.

Channels can be controlled by channel faders, presets, and sequences on the pages.

Selected channels

To make changes to channel values, a channel must be selected. Selection is indicated by a

thick green border around the channel cell on the Channel Map. Selection can happen in a

number of ways:

•

Touch the channel cell on the Channel Map. Touch the cell again to deselect it.

•

Touch the color chip at the top of a channel fader. Touch the chip again to deselect.

•

To deselect all selected channels, use Clear>Selection.

Channel Map

The Channel Map button (located in the Page button menu) displays a topographical map of

channels fullscreen at maximum size. You may select channels on the topographical map for

control. If multiple Spaces are enabled, tabs will appear on the Channel Map to allow you to

choose between them.
