Dancover PE Series Manual de usuario

22-08-2013

3m PE Series

Party tent

Manual for

Safety Advice

Attention

In some countries approval is needed to set up a marquee/tent larger than 75 m2. It

is your responsibility to comply with local rules and regulations and to ensure that

the marquee/tent is assembled correctly.

In case of bad weather conditions, it is your responsibility to ensure the

marquee/tent is safely secured and that the marquee/tent does not cause damage

to others.

close to the tent.

The marquee/tent must be safely secured. We recommend you secure your

marquee/tent with straps and pegs as soon as it is assembled.

Make sure to check if the marquee/tent is covered by your home contents insurance.

Marquees/tents must be evacuated under extreme weather conditions.

In the event of snow always remove snow from the roof of the marquee/tent

regularly to prevent snow from building on the roof as heavy snow can cause the

marquee/tent to collapse.

In the event of rain there is a risk of rain puddles building up on top of the roof of the

marquee/tent. Heavy rain puddles can cause the roof to collapse. It is your responsi-

bility to ensure rain puddles do not build up. As a precaution, make sure theroof of

the marquee/tent is stretched out properly and adequately over the side frames of

the marquee/tent and remove rain water regularly.

Please always check our website for the latest safety advice and manuall.

Note: Marquees are intended for events and other arrangements and are as such only

meant for short term temporary assembly and the following disassembly. Dancover

warranty applies only to the normal use of the Product, normal wear and tear excepted,

in accordance with written use instructions or manual. The warranty does not apply to

3m PE instruction

Part

no.

3x4m 3x6m 3x8m 3x10m

1Frame pole 6 8 10 12

2Frame pole 6 9 12 15

3Leg 6 8 10 12

43-way

Connector 6 6 6 6

54-way

Connector 3 6 9 12

6Big peg 4 4 4 4

7Middle peg 6 8 10 12

8Small peg 23 27 31 35

9Bungeeball long 52 60 68 76

10 Bungeeball short 14 14 14 14

11 Rope 4 4 4 4

12 O-Screw 30 42 54 66

13 Roof 1 1 1 1

1 1 1 1

1 1 1

22-08-2013

14 Sidewall 2 2 2 2

15 Endwall with

large door

Endwall with

small door

Assemble instruction

Step 1

Select a flat ground for the tent, unpack the carton

and check all the parts including tubes, tent and

accessories… etc. are present same as list.

Assemble the framework of rooftop by joining the

portion (4.5) together with poles (1.2). To ensure the

screw fixed to every pole tightly.

Step 2

Attach one end of the Leg (3) to the joints (4,5)

Step 3

Cover the roof on the frame and attach it with the

bungee balls properly, take care of the tension of the

bungee balls, for if you use too many on one side of

the tent, it may become too tight to tie the other side

of it.

Step 4

Attach the remaining Legs (3) to the joints (4,5),

to built-up the framework, use the long pegs

to fix each pole into the ground.

Assemble manual

Step 5

Fold out the sidewalls and the endwalls, attach to

framework by using the bungeeballs locking the

through the eyelets that are placed on top of the

sidewalls and endwalls to ensure stability. Connect

leg cover with sidewall by Velcro. Also use the short

pegs to fix the doors to the ground.

Step 6

Tie the rope to each corner of the tent. Tie the other

end of the rope to a peg. Stick peg in ground.

Warning:

1. In order to avoid rusting pipes, oil is covering the surface of the pipes, before erecting the

tent, please remove the oil carefully first to keep the cover clean.

2. Take note that the tent needs to be handled carefullyto avoid damage.

3. Do not force the frame as they may be damage in the process.

4. Tents are meant as temporary shelter and must be evacuated under extreme weather

conditions.

5. The windows maybe a little bit sticky to each other, when you unfold the windows, please

do this as softly as you can. Or the windows might crack during the process.

Please select a suitable site for the tent to avoid the damage from underground sprinkler

systems, water, gas or electrical lines.

Contact information

Head office:

Dancover A/S

Nordre Strandvej 119 G

3150 Hellebæk

Denmark

For more information

please visit:

www.dancovershop.com

National contact

Denmark:

denmark@dancover.com

UK:

uk@dancover.com

Spain:

espana@dancover.com

Italy:

italia@dancover.com

Germany:

germany@dancover.com

Switzerland:

schweiz@dancover.com

France:

france@dancover.com

Austria:

austria@dancover.com

Sweden:

sverige@dancover.com

Finland:

suomi@dancover.com

Nederland:

nederland@dancover.com

Poland:

polska@dancover.com

Ireland:

ireland@dancover.com

Luxembourg:

luxembourg@dancover.com

Belgium:

belgique@dancover.com

Norway:

norge@dancover.com
