CH-506TX & RX
HDMI & IR over Single
CAT5e/CAT6
Operation Manual
CH-506TX & RX
Safety Precautions
Please read all instructions before attempting to unpack or install or
operate this equipment, and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
Always follow basic safety precautions to reduce the risk of
re, electrical shock and injury to persons.
To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
Never spill liquid of any kind on or into this product.
Never push an object of any kind into this product through
module openings or empty slots, as you may damage parts.
Do not attach the power supply cabling to building surfaces.
Do not allow anything to rest on the power cabling or allow it to
be abused by persons walking on it.
To protect the equipment from overheating, do not block the
slots and openings in the module housing that provide ventilation.
Revision History
Version No Date Summary of Change
RDV1 20110620 Preliminary Release
Table of Contents
1. Introduction ..................................................................................1
2. Applications .................................................................................1
3. Package Contents ......................................................................1
4. System Requirements ..................................................................1
5. Features ........................................................................................ 1
6. Specifications ..............................................................................2
7. Operation Controls and Functions ............................................. 3
7.1 Front Panel .................................................................... 3
7.2 Rear Panel .................................................................... 4
8. D-Sub 9 Pin Definitions.................................................................4
9. Connection and Installation ...................................................... 5
10. Acronyms .....................................................................................6
1
1. Introduction
The device that can make your home or ofce more efcient, this unit
of HDMI with RS-232 over Single CAT5e/CAT6 can transmit and receive
uncompressed audio/video, control through the built-in RS-232 and IR ports
over 100M. Hence, if you want to make your home or ofce more efcient,
get the HDMI & IR over Single CAT5e/CAT6 and prepare to be amazed.
2. Applications
• Household entertainment sharing and control
• Lecture room display and control
• Showroom display and control
• Meeting room presentation and control
• Classroom display and control
3. Package Contents
• HDMI & IR over Single CAT5e/CAT6 Transmitter x 1
• HDMI & IR over Single CAT5e/CAT6 Receiver x 1
• IR Blaster x 1
• IR Receiver x 1
• 3.5Ø to RS-232 female cable x 1
• 3.5Ø to RS-232 male cable x 1
• 5V 2.6A DC Power Adaptor x 2
• Operation Manual
4. System Requirements
Input HDMI source equipment such as DVD/Blue-Ray player and output
display with HDMI input jack.
5. Features
• HDMI 1.4 with 3D, 4k x 2k support, HDCP & DVI Compliant
• Supports HDCP repeater and CEC function
• Simultaneously uncompressed data sending over a single 100M/328ft
withCAT6 cable or 80M/262ft with CAT5e cable
• Uncompressed video 1080p, 60Hz, 48bits
• Audio support up to 7.1CH & Dolby TrueHD, DTS-HD
• 3Play™ convergence: HDMI & Control (IR & RS232)
• Installation Friendly
2
6. Specications
Transmitter
Input 1 x HDMI, 1 x IR Extender, 1 x RS-232
1 x IR Blaster
Output 1 x CAT5e/6
Receiver
Input 1 x CAT5e/6, 1 x IR Extender, 1 x IR Receiver
Output 1 x HDMI, 1 x RS-232
ESD Protection Human Body Model: ± 8kV (air-gap discharge)
± 4kV (contact discharge)
IR Frequency 20~60Hz
Dimensions (mm) 102(W) x 107(D) x 25(H)
Weight (g) 240/Tx, 245/Rx
Chassis Material Aluminum
Silkscreen Color Silver
Power Consumption TX: 2W ; RX: 6W
Operating Temperature 0°C ~ 40°C/ 32° ~104°
Storage Temperature -20°C ~ 60°C/ -4° ~140°
Relative Humidity 20~90% RH (non-condensing)
3
7. Operation Controls and Functions
7.1 Front Panel
Transmitter Receiver
IR1 Extender
RS232 Out IR2 Blaster
HDMI Out
① ② ③ ⑤
IR2 Extender
RS232 In IR1 Blaster
HDMI In
③ ④②①
①.RS-232 In/Out: Thess slots are to connect with 3.5O phone jack RS-232
cable from PC/NB equipment for sending RS-232 commands.
②.IR Extender 1/2: This slot is to connect with the IR receiver cable included
in the package for IR signal receiving.
③.IR Blaster 1/2: This slot is to connect with the IR blaster cableincluded in the
package for IR signal transmitting.
④.HDMI In: This slot is to connect with HDMI source equipment such as DVD/
Blue-Ray player.
⑤.HDMI Out: This slot is to connect with HDMI TV/monitor for display HDMI
input source signal.
7.2 Rear Panel
Transmitter Receiver
CAT 5e /6 In
Power
DC 5V
① ② ③
CAT 5e /6 Out
Power
DC 5V
③②①
①.DC 5V: These slots are where you plug the 5V DC power supply into the
unit and connect the adaptor to an AC outlet.
②.Power LED: This green LED will illuminate when the device is attached
with power supply.
③.CAT5e/6 Out/IN: These slots are to be connected with a single CAT5e/6
cable for data transmitting.
4
8. D-Sub 9 Pin Denitions
Pin Dene TX / RX
1 N/C
2 TxD / RxD
3 RxD / TxD
4 N/C
5 GND
6 N/C
7 N/C
8 N/C
9 N/C
5
9. Connection and Installation
HD Monitor
or
DVD Blu-ray
TV/Monitor
CH-506RXCH-506TX
Hub/Server
NBPC
TV
MAC
CAT5e(100M)/
CAT6(80M)
HDMI
Cable
HDMI
HDMI
Ethernet Cable
HDMI
Cable
HDMI
HDMI
HDMI
HDMI
HDMI
Cable
HDMI
HDMI
HDMI
HDMI
DC
DC
IR Extender
30°
30°
3M 3M
7M
DVD
Remote
IR Blaster
IR Blaster
IR Extender
30°
30°
3M 3M
7M
DVD
Remote
6
Acronyms A
Acronym Complete Term
CAT5e Category 5 Cable
CAT6 Category 6 cable
CEC Consumer Electronics Control
DVI Digital Visual Interface
HDCP High-bandwidth Digital content protection
HDMI High-Denition Multimedia Interface
IR Infrared
