CYP PUV-2000TX Manual de usuario

CH-1602TXR & CH-1602RXR

HDMI/Audio over CAT5e/6/7 Extender with 48V PoE

Operation Manual

PUV-2000TX & PUV-2000RX

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or

operate this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of ﬁ re,

electrical shock and injury to persons.

• To prevent ﬁ re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts

inside the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU

if it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sufﬁ cient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE

VR0 21/08/15 Preliminary Release

CONTENTS

1. Introduction............................................ 1

2. Applications........................................... 1

3. Package Contents ................................ 1

4. System Requirements............................ 2

5. Features.................................................. 2

6. Operation Controls and Functions....... 3

6.1 Transmitter Front Panel ....................3

6.2 Transmitter Left and Right Panels ...4

6.3 Receiver Front Panel........................5

6.4 Receiver Left and Right Panels.......6

6.5 IR Cable Pin Assignments ................7

7. Connection Diagram ............................ 8

8. Speciﬁ cations ........................................ 9

8.1 Technical Speciﬁ cation...................9

8.2 CAT5e/6/7 Cable Speciﬁ cation ...10

9. Acronyms ............................................. 10

1. INTRODUCTION

This HDMI and Audio over Single CAT5e/6/7 Transmitter and Receiver

set can send uncompressed audio/video along with controls and IP

over a single run of CAT5e/6/7 cable up to 100m. It has the added

beneﬁ t of control through the built-in RS-232 and IR ports. With LAN

serving connection and external digital and analog audio capability

that gives users the convenience of additional audio connection. The

48V PoE design can power the Receiver (PD) from the Transmitter (PSE),

eliminating the need for a separate power supply for the Receiver.

Also, the ultra-thin mechanical designs allow ﬂ exibility mounting

position saving more space and make presentation orderly and tidy.

2. APPLICATIONS

• 48V PoE from Transmitter (PSE) to Receiver (PD)

• Household entertainment extending and control

• Lecture room display and control

• Showroom display and control

• Meeting room presentation and control

• Classroom display and control

3. PACKAGE CONTENTS

• 1×HDMI/Audio over CAT5e/6/7 Transmitter

• 1×HDMI/Audio over CAT5e/6/7 Receiver

• 1×IR Blaster

• 1×IR Extender

• 1×48 V/0.83 A DC Power Adaptor

• 1×Power Cable

• 2×Rack Ears Sets

• 1×Operation Manual

4. SYSTEM REQUIREMENTS

Input source equipment such as DVD/Blu-ray player, host PC/Laptop

and HDMI equipped output display (TV or monitor) with ampliﬁ er or

active speakers.

5. FEATURES

• Supports HDBaseT 2.0 speciﬁ cation supporting over a single CAT6/7

cable up to 100m/328ft and CAT5e cable up to 90m/295ft

• HDMI (with 3D & 4K2K 60_YUV420 support), HDCP 2.2 and DVI

compatible

• HDBaseT 5Play™ convergence: High-Deﬁ nition (HD) Video and

Audio, 100BaseT Ethernet, PoE and Control (Bidirectional IR/RS-232

pass-through)

• Supports pass-through of HD audio formats: LPCM 2/5.1/7.1CH,

Dolby Digital 2/5.1CH, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos

and DTS-HD Master Audio

• Supports optical sampling rate up to 48kHz

• Supports Ethernet network connection

• Supports external analog and digital audio transmission

• Supports RS-232 baud rate from 110~115200bps

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Transmitter Front Panel

DC 48V POWER AUDIO IN IR IN2IR OUT1 UPDATERS-232 IN

TX RX

+−



CAT5e/6/7 OUT

HDMI IN

OPT.

OUTLAN

ARC OUT

OFF ON

1 2 3 4 5 6

DC 48V and POWER LED: Plug the 48V DC power supply into the

unit and connect the adaptor to an AC outlet and the LED will

illuminate.

AUDIO IN L/R: Connect with audio source equipment such as PC

or CD player for audio signal sending to Receiver’s AUDIO OUT L/R.

IR IN 2: Connect to the supplied IR Extender cable for IR signal

reception. Ensure that remote being used is within the direct line-

of-sight of the IR Extender.

IR OUT 1: Connect to the supplied IR Blaster Cable for IR signal

transmission. Place the IR Blaster in direct line-of-sight of the

equipment to be controlled.

RS-232 IN TX/RX: Connect to a PC or Laptop with 3-pin Relay cable

for the transmission of RS-232 commands. For receiving command

from Receiver side, the TX and Rx pin must be reversed.

UPDATE: This is reserved for ﬁ rmware update use only. Switch

this deep switch to left for ﬁ rmware update use, under normal

operation, leave the switch on right. Update procedure may be

done from the same RS-232 port for both Transmitter and Receiver.

6.2 Transmitter Left and Right Panels

HDMI IN

OPT.

OUTLAN

ARC OUT

OFF ON

CAT5e/6/7 OUT

12 3 4 5

Left Right

CAT5e/6/7 OUT: Connect to the Receiver unit with a single

CAT5e/6/7 cable for transmission of all data signals. Under proper

connection the green LED will illuminate to indicate PoE activated.

The yellow LED will illuminate to indicate successful connection

between Transmitter and Receiver, when it blink irregularly it

represent the link error or when not illuminate it means no link with

Receiver.

LAN: Connect to an internet or network connection. The yellow LED

will illuminate to represent the link with Receiver is steady, when

it blink irregularly it represent the link error or when not illuminate

it means no link with Receiver. The green LED will illuminate to

represent the Ethernet speed is with 100Mbit/s.

OPT. OUT: Connect to speaker for audio signal output from

Receiver’s OPTICAL IN.

ARC OUT OFF/ON SWITCH: Switch this dip switch to allows ARC

(Audio Return Channel) function to be activate or not. Switch to

OFF to disable ARC function. Switch to ON allows Receiver’s HDMI

output audio to be routed back and output to both HDMI IN and

Optical OUT on the Transmitter side.

Note: When ARC switch to ON, depending on the connected

devices of the HDMI OUT & Optical in, the ARC input/output

transmission distance may be varied. It is suggested to use cable

within 2 meters long to ensure the best audio quality.

HDMI IN: Connect to HDMI source equipment such as a DVD or

Blu-ray player.

6.3 Receiver Front Panel

OPT.

POWER AUDIO OUTIR IN1IR OUT2 UPDATERS-232 OUT

TX RXLR



CAT5e/6/7 IN

HDMI OUTLAN

OPT.

ARC

1 2 3 4 5 6

POWER LED: This LED will illuminate when device is connected with

power supply.

AUDIO OUT L/R: Connect to speaker with RCA input for audio

signal output.

IR IN 1: Connect to the supplied IR Extender cable for IR signal

reception. Ensure that remote being used is within the direct line-

of-sight of the IR Extender.

IR OUT 2: Connect to the supplied IR Blaster cable for IR signal

transmission. Place the IR Blaster in direct line-of-sight of the

equipment to be controlled.

RS-232 OUT TX/RX: Connect to the device that is to be controlled

via 3-pin Relay cable by RS-232 commands. For sending command

to Transmitter side, the TX and Rx pin must be reversed.

UPDATE: This is reserved for ﬁ rmware update use only. Switch

this deep switch to left for ﬁ rmware update use, under normal

operation, leave the switch on right. Update procedure may be

done from the same RS-232 port for both Transmitter and Receiver.

6.4 Receiver Left and Right Panels

OPT.

IN HDMI OUTLAN

OPT.

ARC

CAT5e/6/7 IN

12 3 4 5

Left Right

CAT5e/6/7 IN: Connect to the Transmitter unit with a single

CAT5e/6/7 cable for transmission of all data signals. The yellow LED

will illuminate to represent the link from Receiver is steady, when

it blink irregularly it represent the link error or when not illuminate

it means no link with Receiver. The green LED will illuminate to

represent the PoE function active.

LAN: Connect to a PC or Laptop to the internet or network

connection. The yellow LED will illuminate to represent the link with

Transmitter is steady, when it blink irregularly it represent the link

error or when not illuminate it means no link with Receiver. The

green LED will illuminate to represent the Ethernet speed is with

100Mbit/s.

OPT. IN: Connect to audio source equipment such as DVD or Blu-

ray player for audio signal sending to Transmitter’s OPTICAL OUT.

ARC IN or OPT. IN SWITCH: Switch this switch to select ARC channel.

Switch to ARC in to use HDMI OUT’s audio or switch to Optical IN to

use Optical 1’s audio.

Note: Depending on the connected devices of the HDMI OUT &

Optical in, the ARC input/output transmission distance may be

varied. It is suggested to use cable within 2 meters long to ensure

the best audio quality.

HDMI OUT: Connect to a HDMI equipped TV/monitor for display of

the HDMI input source signal.
