CYP PU-507-KIT Manual de usuario

PU-507-KIT

5-Play HDBaseT™ Extender Kit (inc. PoE & single LAN, up to 100m)

OPERATIONS MANUAL

DISCLAIMERS

The information in this manual has been carefully checked and is

believed to be accurate. CYP (UK) Ltd assumes no responsibility for any

infringements of patents or other rights of third parties which may result

from its use.

CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be

contained in this document. CYP (UK) Ltd also makes no commitment to

update or to keep current the information contained in this document.

CYP (UK) Ltd reserves the right to make improvements to this document

and/or product at any time and without notice.

No part of this document may be reproduced, transmitted, transcribed,

stored in a retrieval system, or any of its part translated into any language

or computer le, in any form or by any means—electronic, mechanical,

magnetic, optical, chemical, manual, or otherwise—without express

written permission and consent from CYP (UK) Ltd.

Version 1.1 August 2011

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be

trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or operate

this equipment and before connecting the power supply.

Please keep the following in mind as you unpack and install this

equipment:

• Always follow basic safety precautions to reduce the risk of re,

electrical shock and injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain,

moisture or install this product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any

openings or empty slots in the unit, as you may damage parts inside

the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU if

it is damaged.

• Do not allow anything to rest on the power cabling or allow any

weight to be placed upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or

openings in the unit housing that provide ventilation and allow for

sucient space for air to circulate around the unit.

REVISION HISTORY

VERSION NO. DATE SUMMARY OF CHANGE

VS1 29/02/12 First Release

VR2 02/03/12 PoE Support (Brand only)

VS3 23/03/12 Amended PoE function

Updated the connection diagram and

the specications table

v1.01 20/09/13 Amended Link LED description

v1.02 08/10/13 Amended product description

CONTENTS

1. Introduction...........................................6

2. Applications ...........................................6

3. Package Contents ..................................6

4. System Requirements ...........................6

5. Features..................................................7

6. Operation Controls and Functions .......8

6.1 Transmitter Front and Rear Panels....... 8

6.2 Receiver Front and Rear Panels ............ 9

6.3. D-Sub 9 Pin Denitions ........................10

7. Connection Diagram .......................... 11

8. Specications...................................... 12

9. Acronyms............................................. 13

1. INTRODUCTION

The PU-507-KIT allows uncompressed HDMI signals and IP data to be

transmitted over a Single CAT5e/6 cable. This solution has the added

features of RS-232 and 2-way IR control functionality over the same

CAT5e/6 cable. These combined HDMI and control signals can be

transmitted up to lengths of 100 metres.

2. APPLICATIONS

Household entertainment sharing and control

Lecture room display and control

Showroom display and control

Meeting room presentation and control

Classroom display and control

3. PACKAGE CONTENTS

1×HDMI to CAT5e/6 (with LAN/IR/RS-232) Transmitter

1×CAT5e/6 to HDMI (with LAN/IR/RS-232) Reciever

1×IR Blaster

1×IR Receiver

1×24V/1.25 A DC Power Adaptor

Operation Manual

4. SYSTEM REQUIREMENTS

Input HDMI source equipment such as DVD/Blu-ray player and HDMI

equipped output display (TV or monitor).

5. FEATURES

v1.4 HDMI with 3D, 4k - 2k support.

HDCP & DVI compliant.

Supports HDCP repeating and CEC functions.

Uncompressed data transfer over single CAT cable (100m - CAT6; 80m -

CAT5e).

Uncompressed video 1080p, 60Hz, 48bits

Audio support up to 7.1CH & Dolby TrueHD, DTS-HD.

5Play™ convergence: HDMI, LAN, POE & Control (IR & RS232).

Supports 3D signals.

Note:

1. This system was tested with CAT-6E/23AWG cables, results may vary with

cables of a dierent specication.

2. The PoE function is designed for powering compatible receiver units

only—non-PoE receivers will need their own power supply.Receivers of

another brand may not be compatible.

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Transmitter Front and Rear Panels

RearFront

RS-232 In

LAN

HDMI In

HDMI to CAT5e/6 with LAN/IR/RS232

Transmitter

CAT5e/6 Out

Link

IR2 Extender

IR1 Blaster

DC 24V

Power

2 31 64 7 8 95

HDMI In: Connect to HDMI source equipment such as a DVD or Blu-

ray player.

LAN: Connect to an internet or network connection.

RS-232 In: Connect to a PC or laptop with D-Sub 9 pin male cable for

the transmission of RS-232 commands.

Power LED: This blue LED will illuminate when the device is

connected to a power supply.

DC 24V: Plug the 24V DC power supply into the unit and connect the

adaptor to an AC outlet.

IR 1 Blaster: Connect to the supplied IR blaster cable for IR signal

transmission. Place the IR blaster in direct line-of-sight of the

equipment to be controlled.

IR 2 Extender: Connect to the supplied IR receiver cables for IR signal

reception. Ensure that remote being used is within the direct line-of-

sight of the IR extender.

Link LED: The yellow LED will illuminate when both the input and

output signals are connected through the CAT cable. When it blinks

regularly it indicates the source is NOT sending a signal to the

transmitter but the transmitter and receiver are linked. If it blinks

irregularly it indicates an error has occurred.

CAT5e/6 Out: Connect to the reciever unit with a Single CAT5e/6

cable for tranmission of all data signals.

6.2 Receiver Front and Rear Panels

RS-232 Out

LAN

HDMI Out

CAT5e/6 to HDMI with LAN/IR/RS232

Receiver

RearFront

CAT5e/6 In

Link

IR1 Extender

IR2 Blaster

Power

2 31 65 7 84

HDMI Out: Connect to a HDMI equipped TV/monitor for display of the

HDMI input source signal.

LAN: Connect to a PC or Laptop to the Internet or network

connection.

RS-232 Out: Connect to the device that is to be controlled (via D-Sub

9 pin female cable) by RS-232 commands.

Power LED: This blue LED will illuminate when the device is

connected to a power supply.

IR 2 Blaster: Connect to the supplied IR blaster cable for IR signal

transmission. Place the IR blaster in direct line of sight of the

equipment to be controlled.

IR 1 Extender: Connect to the supplied IR receiver cables for IR signal

reception. Ensure that remote being used is within the direct line-of-

sight of the IR extender.

Link LED:The yellow LED will illuminate when both the input and

output signals are connected through the CAT cable. When it blinks

regularly it indicates the source is NOT sending a signal to the

transmitter but the transmitter and receiver are linked. If it blinks

irregulaly it indicates an error has occurred.

CAT5e/6 In: Connect to the transmitter unit with a Single CAT5e/6

cable for tranmission of all data signals.

6.3. D-Sub 9 Pin Denitions

Pin Dene TX / RX

1 N/C

2 TxD / RxD

3 RxD / TxD

4 N/C

5 GND

6 N/C

7 N/C

8 N/C

9 N/C
