DS304

Installation Instructions

Passive Infrared (PIR)

Detector

Bosch Security Systems | 1/05 | 4998122424F

EN | 21.0 Installation Considerations

1.0 Installation Considerations

• Not suitable for outdoor use.

• Point away from direct and indirect sunlight.

• Point away from glass or other objects that rapidly

change temperature.

• Do not install this detector where pets are present.

• Select a mounting location where an intruder is most

likely to cross the coverage pattern perpendicular to

the detection zones.

• Mount the detector 6.6 ft to 8.5 ft (2 m to 2.6 m)

above the floor.

2.0 Installation

Refer to Figures 1 and 2when preparing the detector.

Ensure the mounting surface is solid and

free of vibration.

1. Remove the cover by inserting a thin, flat-blade

screwdriver into the notch at the bottom of the

cover and prying up.

2. Remove the circuit board by pressing one of the

circuit board retainer tabs toward the side of the

enclosure and lifting the circuit board up and out of

the enclosure base.

3. Remove the mirror by sliding it out of its tracks.

4. Remove an appropriate wiring knockout.

5. To surface or corner mount, go to Section 2.1 Surface

or Corner Mounting. To bracket mount, go to

Section 2.2 Bracket Mounting on page 3.

2.1 Surface or Corner Mounting

1. Remove the knockout holes for either surface or

corner mounting.

2. Using the enclosure as a template, mark the location

for the mounting screws. Use wall anchors as

needed.

3. Mount the detector.

4. Insert the wiring.

5. For strain relief, attach the cable to the cable

tie with the plastic tie-down (supplied).

6. Replace the mirror and circuit board.

Figure 1: Rear Enclosure

1 - Wiring knockouts (3)

2 - Cable tie/strain relief

3 - Corner mounting holes (2)

4- Surface mounting holes (4)

5 - Circuit board retainer tabs (2)

6 - Mirror tracks (2)

7 - Bracket mounting hole

Figure 2: Circuit Board

1 - Securing screw 4 - LED

2 - Terminal strip (2) 5 - Configuration switches

3 - Tamper switch 6 - Program jumper

123

OP N

DS304| Installation Instructions |

EN | 3

DS304| Installation Instructions |

Bosch Security Systems | 1/05 | 4998122424F

3.0 Mirror Adjustment

2.2 Bracket Mounting

1. Attach the bracket to the mounting surface using the

instructions supplied with the bracket.

2. Knock out the bracket mounting hole in the

enclosure base and attach the enclosure to the

bracket using the instructions supplied with the

bracket.

3. Insert the wiring.

4. For strain relief, attach the cable to the cable

tie with the plastic tie-down (supplied).

5. Replace the mirror and circuit board.

3.0 Mirror Adjustment

1. Determine the appropriate angle for the installation

using the chart in Figure 3.

Touching the mirror surface can reduce

performance.

2. Use the angle adjustment markings shown in

Figure 4 to set the maximum detection range needed.

3. Slide the mirror forward or back until the angle

adjustment markings align with the markers on each

side of the frame. Use the chart in Figure 3 located

inside the front cover to set the correct angle.

4. Adjust the horizontal protection coverage during the

Walk Test. Refer to Section 7.0 Setup and Walk Testing

on page 5.

4.0 Wiring

Apply power only after all connections are

made and inspected.

Do not coil excess wire inside the enclosure.

Seal the wire entrance with the plug

provided.

Figure 3: Mirror Angle Adjustment

2.0 (6.5)

2.3 (7.5)

2.6 (8.5)

Broad

20 (6) 35 (10) Curtain

40 (12) 70 (20

)

-10° - 6° - 4° - 2°

-12° - 8° - 4° - 2°

-14° - 10° - 6° - 4°

Y m (ft)X m (ft)

X = maximum range Y = mounting height

Figure 5: Terminal Strip Connections

456789101

1 (SH) Shield (optional): Connection for ground

wire from shielded cable.

2 (S/U*) Set/Unset (optional): Use as an alarm

memory control input for remote panel

arming or disarming. Also used as an

electronic alarm output. Only one detector

should be connected for each detector

group.

3 (WT*) Walk Test (optional): Use for Walk Test

remote control through the control panel.

Allows a command at the control panel to

enable or disable the Alarm LED.

4 & 5 (T) Tamper: Tamper contact is normally closed

(open when cover opens). Rated 125 mA

at 28 V.

6 & 9 (SP) Spare

7 & 8 (AL) Alarm: Solid-state Form “A” relay contacts

normally closed (open on alarm). Rated

100 mA at 30 V. Do not use with

capacitive or inductive loads.

10 (-) & Input power: Use no smaller than

11(+) 22 AWG (0.8 mm) wire.

* Use a control panel or switch to 0 VDC with the

S/U and WT option control inputs. Open control

inputs are HIGH level (internal pull-up). Switch the

input to achieve the LOW level (from <1.5 V up to a

2 k

Ω

resistance maximum). The active level is

user-configurable.

Figure 4: Adjustment Selections

Mirror with expanded view showing the angle

adjustment markings.

-16

-8

Bosch Security Systems | 1/05 | 4998122424F

EN | 4

5.0 Configuration

5.1 Program Jumper for the S/U Control

Terminal

Use the S/U control terminal as an alarm memory

control input by setting the jumper in the upper position

as shown in Item 1 of Figure 6.

Use the S/U control terminal as an electronic alarm

output (open collector) by setting the jumper in the

lower position as shown in Item 2 of Figure 6.

5.2 User DIP Switches

5.3 Adjusting Sensitivity

Table 1: Sensitivity Settings

DIP Switch 2 OFF

Standard Sensitivity (Default):

Recommended for maximum false

alarm prevention.

Tolerates environmental extremes.

Not recommended for curtain

patterns.

DIP Switch 2 ON

Intermediate Sensitivity:

Recommended for any location

where an intruder is expected to

cover only a small portion of the

protected area, or when you want

improved catch performance.

Does not tolerate normal

environments.

5.4 LED Setup Without S/U and WT

Remote Control Panel Inputs

Table 2: LED Setup Without Control Panel Inputs

DIP Switch Settings

LED

Operation

User DIP Switch 1

Walk Test

User DIP Switch 3

Set/Unset

Disable LED Any ON

Enable LED OFF (default)

OFF (default)

5.0 Configuration

Figure 7: User DIP Switches

12 3

OPEN

1 - Walk Test polarity (Refer to Section 5.4 LED

Setup Without S/U and WT Remote Control

Panel Inputs.)

2 - Sensitivity (Refer to Section 5.5 Setup for

Remote Control Alarm Memory and LED

Operation Using S/U and WT Inputs.)

3 - Set/Unset polarity (Refer to Section 5.4.)

1 - Alarm memory control input

2 - Electronic alarm output

Figure 6: Program Jumper Settings

S/U

AL S/U

DS304| Installation Instructions |

EN | 5

DS304| Installation Instructions |

Bosch Security Systems | 1/05 | 4998122424F

5.5 Setup for Remote Control Panel

Alarm Memory and LED Operation

Using S/U and WT Inputs

Table 3: User DIP Switch Selection

DIP

Switch

Function ON

OFF

1 Select

Walk Test

polarity

Low (0 V) =

Walk Test

active

High (12 V) =

Walk Test

active (default)

3 Select

Set/Unset

polarity

Low (0 V) =

Unset

High (12 V) =

Set

High (12 V) =

Unset (default)

Low (0 V) =

Set (default)

Ensure the control terminal program jumper is configured as

shown in Item 1 of Figure 5 on page 3 (refer to Section 5.1

Program Jumper for the S/U Control Terminal on page 4).

6.0 Remote Control Operation

Table 4: Remote Control Operation

Control Line Status

Arming

Terminal

Status

Walk Test

Terminal

Status

Detector

Status

LED Status

Set OFF or ON Memory

ready OFF

Stored

alarm

Rapid flashing

(2 Hz)

OFF

No stored

alarm OFF

Power up Slow flashing

(0.5 Hz)

Alarm

activity

ON for

4 sec

Unset

No alarms OFF

Transition

from Unset

to Set

OFF or ON Memory

cleared

OFF

6.0 Remote Control Operation

7.0 Setup and Walk Testing

Enable the LEDs before performing a

Walk Test.

1. Replace the cover and insert the cover tamper screw

(if desired).

2. Apply power to the unit.

3. Wait at least 2 min for the detector to stabilize and

no motion is detected (Figure 8).

4. Watch the LED as you walk to the farthest edge of

the coverage pattern. Walk closer to the detector by

crossing the pattern.

The LED lights when it detects you crossing the

coverage pattern.

5. Repeat from the other side.

If the desired range is not achieved, try angling the

mirror up or down to assure the coverage pattern is

not aimed too high or too low.

8.0 Maintenance

At least once a year, check the range and coverage

according to Section 7.0 Setup and Walk Testing. To

ensure continuous operation, instruct the end user to

walk through the outer edge of the coverage area daily

and observe the LED operation (if used). This also

assures an alarm output prior to arming.

Figure 8: Walk Testing

Walk test across the pattern.

Bosch Security Systems | 1/05 | 4998122424F

EN | 69.0 Coverage Patterns

9.0 Coverage Patterns

DS304| Installation Instructions |

Figure 10: Curtain Mirror Coverage (optional OMLR93)

1 - Top view

2 - Side view, mirror adjusted to -2°

3 - Front polished surface view, mirror segment for pattern reference

0 m

-8

-16

-8

-16

0 m 0 m

2 m

21 m

0 m

1.9 m

1.9 m 21 m

1 - Top view

2 - Side view, mirror adjusted to -6°

3 - Front polished surface view, mirror segment for pattern reference

Figure 9: Wide Angle Coverage

ABCDEFGHI

JKLMN

-8

-16

-8

-16

0 m

5.35 m

0 m

5.35 m 11 m

0 m

2 m

11 m

0 m

EN | 7

DS304| Installation Instructions |

Bosch Security Systems | 1/05 | 4998122424F

10.0 Specifications

Table 5: Specifications

Input Power Use only an approved limited power source.

Standby Power No internal standby battery. Standby power must be provided by an approved limited power

source. For each hour of standby time needed, 22 mAh is required.

Supply Voltage

Range: 8 VDC to 16 VDC

Nominal: 12 VDC nominal

Maximum Ripple

(0 to 120 Hz): 2 Vpp

Voltage Monitoring: Alarm at less than 4 V

Current Consumption (at 12 V)

Quiescent: 5.5 mA

Maximum at standby

(LED on): 8.5 mA

Alarm Output

Relay Contact

(Solid-State Relay): Opens in alarm; 30 V, 100 mA; R, <20 Ω

Alarm Holding Time: 4 sec

Alarm Relay Connect to a safety extra-low voltage (SELV) circuit only.

Optional Electronic Alarm Output (alternate use of S/U Terminals)

Inactive: Open collector output

Active: Switch low through 1 kΩ

Tamper Contact

28 V, 125 mA

Connect to a SELV circuit only.

Connect the tamper circuit to a 24-hour protection circuit.

Control Inputs (Walk Test, S/U)

LOW: 1.5 V or less

HIGH: 3.5 V or more

Coverage

Wide Angle Mirror: 11 m x 11 m

Curtain Mirror: 21 m x 3 m

Walking Speeds

Wide Angle Mirror: 0.2 m/s to 3.0 m/s

Curtain Mirror: 0.2 m/s to 4.0 m/s

Sensitivity Standard or intermediate

Ambient Conditions

Storage Temperature: -20°C to +60°C

Operating Temperature: -10°C to +55°C

Air Humidity (EN60721): <95% rH, non-condensing

Housing Protection

(EN60529, EN50102): IP41/IK02

Options B338 Ceiling Mount Bracket*

OMLR93-3 Curtain Mirror

*Misaligning these brackets can reduce the detector’s range and increase the dead zone area.

10.0 Specifications

Bosch Security Systems

130 Perinton Parkway

Fairport, NY 14450-9199 USA

www.boschsecurity.us

Customer Service: (800) 289-0096

Technical Support: (888) 886-6189

4998122424F

Tabla de contenidos

Otros manuales de Sistema de seguridad de Bosch

Bosch

Bosch FMC-210-DM-G-B Manual de usuario

Bosch

Bosch Security Escort SE2005 Manual de usuario

Bosch

Bosch DS7400XiV4-EXP Manual de usuario

Bosch

Bosch Radion B810 Manual de usuario

Bosch

Bosch ND 200 LSN Manual de usuario

Bosch

Bosch D220 Manual de usuario

Bosch

Bosch B Series Manual de usuario

Bosch

Bosch NBN-733 Instrucciones de montaje

Bosch

Bosch Praesideo Manual de usuario

Bosch

Bosch DIP-3040-00N Manual de usuario

Bosch

Bosch SE3000 Series Manual del producto

Bosch

Bosch MIC-WKT-IR Manual de usuario

Bosch

Bosch Plena PLE-1CS Guía de referencia

Bosch

Bosch D621 Series Manual de usuario

Bosch

Bosch AMAX panel 2000 ICP-AMAX-P Manual de usuario

Bosch

Bosch DIVAR IP 7000 2U Manual de usuario

Bosch

Bosch CC610PB Manual de usuario

Bosch

Bosch Security Systems Manual de usuario

Bosch

Bosch Solution 16i Manual de usuario

Bosch

Bosch Radion Specialty RFBT Manual de usuario

Bosch

Bosch Spexor Manual de usuario

Bosch

Bosch DIP-7040-00N Manual de usuario

Bosch

Bosch NDA-U-PA0 Manual de usuario

Bosch

Bosch Solution 2000 Manual del propietario

Manuales populares de Sistema de seguridad de otras marcas

Inner Range

Inner Range Concept 2000 Manual de usuario

Climax

Climax Mobile Lite R32 Instrucciones de montaje

CADDX

CADDX NX-6 Manual de usuario

FBII

FBII XL-31 Series Manual de usuario

Johnson Controls

Johnson Controls PENN Connected PC10 Manual de usuario

Aeotec

Aeotec Siren Gen5 Manual de usuario

Blaupunkt

Blaupunkt SA 2700 Manual de usuario

IDEAL

IDEAL Accenta Manual del propietario

AJAX

AJAX DoubleButton Manual de usuario

Swann

Swann SW-P-MC2 Manual de usuario

Ecolink

Ecolink Siren+Chime Manual de usuario

Digital Monitoring Products

Digital Monitoring Products XR150 Manual de usuario

EDM

EDM Solution 6+6 Wireless-AE Manual de usuario

Highway Safety Group

Highway Safety Group EA401 Manual de usuario

Siren

Siren LED GSM Manual de usuario

Detection Systems

Detection Systems 7090i Instrucciones de montaje

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manual de usuario

Siemens

Siemens FDM273 Manual de usuario
