D9000,G & GV2 Series

Owner’s Manual Supplement

D9000, G & GV2

Series

D9000,G & GV2 Series |Owner's Manual Supplement

2 Bosch Security Systems | 5/05 | 33267F

Contents

1.0 Introduction.......................................................3

2.0 Two-Man Rule...................................................3

2.1 Description.............................................................3

2.2 Using the Two-Man Rule.......................................3

3.0 Early Ambush....................................................4

3.1 Description.............................................................4

3.2 Using Early Ambush ..............................................4

4.0 Easy Exit Control.............................................5

4.1 Description.............................................................5

4.2 Using Easy Exit Control.........................................5

5.0 Passcode Follows Scope...............................6

5.1 Description.............................................................6

5.2 Using Passcode Follows Scope.................................6

6.0 Passcode-Controlled Menu ............................7

6.1 Description.............................................................7

6.2 Using Passcode Controlled Menus ...........................7

7.0 Invisible Walk Test .........................................8

7.1 Description.............................................................8

7.2 Using Invisible Walk Test: .....................................8

8.0 Door Activated Custom Function.............10

8.1 Description...........................................................10

8.2 Using Door Activated Custom Functions: .............10

9.0 Access Level Control....................................10

10.0 Door Control ...................................................12

10.2 Using Door Control?..................................12

10.3 Cycle Door?..................................................13

10.4 Unlock Door?................................................14

11.0 Delete User [COMMAND 53] ....................15

12.0 Add/Change User - [COMMAND 56] ......17

12.1 Description.........................................................17

D9000,G & GV2 Series |Owner's Manual Supplement

Bosch Security Systems | 5/05 | 33267F 3

1.0 Introduction

This document supplements the Security System Owner’s Manual

(P/N: 71-06633-000) with the Function List features for the D9000 Series.

The instructions for the commands listed in this document replace those

commands in the Security System Owner’s Manual. Refer to the Owner’s

Manual for the operation of your new security system and its other basic

Function List features.

Place this supplement inside the Security System Owner’s

Manual.

2.0 Two-Man Rule

2.1 Description

The Two-Man Rule adds an extra step to the disarm process by requiring

two unique pass codes to disarm an area from the same keypad. Configure

this feature according to the guidelines specified in the

D9412GV2/D7412GV2 Program Entry Guide (P/N: F01U003636).

I have this feature.

I do not have this feature.

2.2 Using the Two-Man Rule

1. Ensure the keypad shows idle armed text.

2. Enter a valid pass code with the authority to Passcode Disarm by

pressing the [passcode digits] followed by the [ENTER] key.

3. The keypad shows a request for the SECOND CODE:

4. Enter a second valid pass code with the authority to Passcode

Disarm by pressing the [passcode digits] followed by the

D9000,G & GV2 Series |Owner's Manual Supplement

4 Bosch Security Systems | 5/05 | 33267F

[ENTER] key. The second pass code must be different from the

first pass code.

The area is disarmed and ready for entry.

3.0 Early Ambush

3.1 Description

Early Ambush adds an extra step to the disarm process by requiring an

additional pass code to be entered to confirm the area is secure. The

second pass code can be same as the first or a different one, depending on

the configuration. The first entry disarms the area and the second entry

stops an automatic timer from sending a duress event. Configured this

feature according to the guidelines specified in the D9412GV2/D7412GV2

Program Entry Guide (P/N: F01U003636).

I have this feature.

I do not have this feature.

3.2 Using Early Ambush

1. Ensure the keypad shows idle armed text.

2. Enter a valid pass code with the authority to Passcode Disarm by

pressing the [passcode digits] followed by the [ENTER] key.

3. Ensure the keypad shows idle disarmed text.

4. The user can now search the area; however, the user must return

before the preset Early Ambush Time expires.

5. Enter a second valid pass code with the authority to Passcode

Disarm by pressing the [passcode digits] followed by the

[ENTER] key.

6. The keypad shows confirmation that the second passcode was

accepted and that the Early Ambush Window was canceled by

showing CODE 2 VALIDATED.

The area is disarmed and ready for entry.

D9000,G & GV2 Series |Owner's Manual Supplement

Bosch Security Systems | 5/05 | 33267F 5

4.0 Easy Exit

Control

4.1 Description

The D9412GV2 / D7412GV2 Control Panels change from one armed

state to another armed state without disarming. The Easy Exit Control

feature reduces the number of keystrokes and simplifies system operation.

This feature is available by default and is always on.

4.2 Using Easy Exit Control

Switching armed states from Master to Perimeter:

1. Ensure the keypad shows idle master armed text.

2. Press the [COMMAND] key. The keypad shows SYSTEM

COMMAND.

3. Press [3] to Perimeter Arm.

4. The keypad display shows the Exit Delay count down.

5. Enter or exit the premises.

Switching armed states from Perimeter to Master:

1. Ensure the keypad shows idle perimeter armed text.

2. Press the [COMMAND] key. The keypad shows SYSTEM

COMMAND.

3. Press [1] to Master Arm.

4. The keypad shows the Exit Delay count down.

5. Enter or exit the premises.

D9000,G & GV2 Series |Owner's Manual Supplement

6 Bosch Security Systems | 5/05 | 33267F

5.0 Passcode

Follows Scope

5.1 Description

The Passcode Follows Scope feature is an optional arming and disarming

restriction that can be enabled on keypads with access to multiple areas.

When this feature is set to No, the keypad restricts Passcode Arming and

Passcode Disarming to the home area of the keypad. When set to Yes, this

feature allows users to arm or disarm all the areas that they and the

keypad have access to. This feature causes no restrictions to the keypad

scope as it pertains to any other command or arming method other than

Passcode Arming or Passcode Disarming.

I have this feature.

I do not have this feature.

5.2 Using Passcode Follows Scope

Arming from a keypad with Panel Wide scope and Passcode Follows

Scope enabled:

1. Ensure the keypad shows idle disarmed text.

2. Ensure you have a valid pass code with the authority to Passcode

Arm in all areas.

3. Enter your code by pressing the [passcode digits] followed by the

[ENTER] key.

4. The keypad shows ARMING: 12345678, to indicate which areas

are about to enter exit delay and arm.

5. The keypad shows the exit delay count down.

6. Exit the premises.

D9000,G & GV2 Series |Owner's Manual Supplement

Bosch Security Systems | 5/05 | 33267F 7

Arming from a keypad with Panel Wide scope and Passcode Follows

Scope disabled (default):

1. Ensure the keypad shows idle disarmed text.

2. Ensure you have a valid pass code with the authority to Passcode

Arm in all areas.

3. Enter your code by pressing the [passcode digits] followed by the

[ENTER] key.

4. The keypad shows the exit delay count down.

5. Exit the premises.

6.0 Passcode-Controlled Menu

6.1 Description

When enabled, the system prompts users to enter a passcode before

viewing the keypad function list menu. The system shows the user the

menu options allowed according to their authority level; thereby,

providing users only the commands and functions pertinent to them.

Configure this feature according to the guidelines specified in the

D9412GV2/D7412GV2 Program Entry Guide (P/N: F01U003636).

I have this feature.

I do not have this feature.

6.2 Using Passcode Controlled Menus

On a D1255 keypad with the Passcode Controlled Menu enabled:

1. Press the [ESC] key. The keypad responds with the ENTER

PASSCODE display.

2. Enter your code by pressing the [passcode digits] followed by the

[ENT] key. The first menu item that you have authority to use

appears.

D9000,G & GV2 Series |Owner's Manual Supplement

8 Bosch Security Systems | 5/05 | 33267F

On a D1260 keypad with the Passcode Controlled Menu enabled:

1. Press the [Menu>] soft key in the lower right corner. The keypad

responds with the Enter passcode: then press [ENTER] display.

2. Enter your code by pressing the [passcode digits] followed by the

[ENTER] key.

The first and second menu items that you have authority to use appear.

7.0 Invisible Walk

Test

7.1 Description

The D9412GV2 / D7412GV2 has a function list menu item that allows

the user to test invisible interior or perimeter controlled points that are

within the scope of the keypad without sending a report to the central

station. This is identical to the Service Walk Test except that it is restricted

to invisible points.

I have this feature.

I do not have this feature.

7.2 Using Invisible Walk Test:

On a D1255 keypad with the Passcode Controlled Menu enabled:

1. Press the [ESC] key.

2. Press the [NEXT] key until INVISIBLE TEST? appears.

3. Press the [ENT] key to activate the Invisible Walk Test function.

The keypad shows the number of invisible points within the scope

of the keypad: ### PTS TO TEST

4. Press the [NEXT] key to see VIEW UNTESTED?.

5. Press the [ENT] key to view the untested points. The keypad

shows the total number of untested invisible points within the

keypad scope: ### PTS UNTESTED.

6. Press the [NEXT] key to view the first point’s name.

D9000,G & GV2 Series |Owner's Manual Supplement

Bosch Security Systems | 5/05 | 33267F 9

7. Press the [ENT] key to view the point’s hardware state:

1PT### NORMAL HW if it is normal 1PT### OPEN HW if it is opened

1PT### SHORT HW if it is shorted 1PT### MISSNG HW if it is missing

8. Activate the point’s sensor and observe the appropriate state

change.

9. Press the [NEXT] key to advance to the next invisible point

within the scope of the keypad.

10. Repeat steps 7 through 9 until all points are tested.

On a D1260 keypad with the Passcode Controlled Menu enabled:

1. Press the [Menu>] soft key in the lower right corner.

2. Press the [Next>] soft key until the Invisible Walk Test?

appears.

3. Press the corresponding soft key to activate the Invisible

Walk Test function. The keypad shows the number of invisible

points within the scope of the keypad: ### points remain to be

tested.

5. Press the [View untested pts>] soft key to see 6 pts untested.

6. Press the [Next Pt>] soft key to view the first or next untested

point:

[Point Text]

Area #, Pt #

[Point State] HW Next PT>

7. Where [Point State] can be NORMAL,OPEN,SHORT, or MISSNG.

8. Activate the point’s sensor and observe the appropriate state

change.

9. Repeat Steps 5 through 8 until all points are tested.

D9000,G & GV2 Series |Owner's Manual Supplement

10 Bosch Security Systems | 5/05 | 33267F

8.0 Door Activated

Custom Function

8.1 Description

The D9412GV2 / D7412GV2 allow a custom function to be activated

when user credentials are presented to a D9210B Door Controller Reader.

The custom function executes as if the user performed a function at the

keypad that is associated with the door controller.

I have this feature.

I do not have this feature.

8.2 Using Door Activated Custom Functions:

Executing the door’s custom function by a user that has authority to do so

when disarming the area:

1. Ensure the area you are about to enter is armed.

2. Present your user credentials to the D9210B Door Controller

Reader. The area disarms and the custom function executes.

The area is now safe to enter.

9.0 Access Level

Control

9.1 Description

Use this function to manually enable or disable access authority levels

assigned to users. This function can be used to temporarily disable a user’s

access level instead of deleting and adding the user.

I have this feature.

I do not have this feature.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de seguridad de Bosch

Bosch

Bosch AVIOTEC IPSTARLIGHT 8000 Manual de usuario

Bosch

Bosch ISC-FPB1-W60QS Instrucciones de funcionamiento

Bosch

Bosch FK 100 LSN Manual de usuario

Bosch

Bosch Solution 2000 Series Instrucciones de funcionamiento

Bosch

Bosch VSS7915/00T Manual de usuario

Bosch

Bosch D9412GV4 Manual de usuario

Bosch

Bosch VSS7902/00T Guía de inicio rápido

Bosch

Bosch Security Escort SE2000 Series Guía de instalación

Bosch

Bosch FMC-210-DM-G-B Manual de usuario

Bosch

Bosch ITS-SPDIAL-FR Manual de usuario

Bosch

Bosch Solution 144 Manual de usuario

Bosch

Bosch LTC 8850 Series Manual de usuario

Bosch

Bosch CM728B Cómo utilizar

Bosch

Bosch Security System Manual de usuario

Bosch

Bosch AMAX panel 2100 Manual de usuario

Bosch

Bosch DIP-2040-00N Manual de usuario

Bosch

Bosch Plena Power Amplifier Guía

Bosch

Bosch Dinion LTC 0385 Manual de usuario

Bosch

Bosch AMAX 2100 Manual de usuario

Bosch

Bosch AMAX panel 2100 Manual de usuario

Bosch

Bosch FLM-420-RLE-S Manual de usuario

Bosch

Bosch BIS 2.3 Manual de usuario

Bosch

Bosch LTC 1311/20 FlexiDome I Manual de usuario

Bosch

Bosch MAP 5000 Series Manual de usuario

Manuales populares de Sistema de seguridad de otras marcas

Inner Range

Inner Range Concept 2000 Manual de usuario

Climax

Climax Mobile Lite R32 Instrucciones de montaje

CADDX

CADDX NX-6 Manual de usuario

FBII

FBII XL-31 Series Manual de usuario

Johnson Controls

Johnson Controls PENN Connected PC10 Manual de usuario

Aeotec

Aeotec Siren Gen5 Manual de usuario

Blaupunkt

Blaupunkt SA 2700 Manual de usuario

IDEAL

IDEAL Accenta Manual del propietario

AJAX

AJAX DoubleButton Manual de usuario

Swann

Swann SW-P-MC2 Manual de usuario

Ecolink

Ecolink Siren+Chime Manual de usuario

Digital Monitoring Products

Digital Monitoring Products XR150 Manual de usuario

EDM

EDM Solution 6+6 Wireless-AE Manual de usuario

Highway Safety Group

Highway Safety Group EA401 Manual de usuario

Siren

Siren LED GSM Manual de usuario

Detection Systems

Detection Systems 7090i Instrucciones de montaje

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manual de usuario

Siemens

Siemens FDM273 Manual de usuario
