CAMEO-5K ( 11lb x 0.1oz)

User Manual

CAMEO

Copyright © 2015 American Weigh Scales, Inc.

All rights reserved. Rev. 1.0

CAMEO

Thank you for purchasing the American Weigh

CAMEO digital kitchen scale. Please read all operating

instructions carefully before use. Scales are precision

measuring devices and should always be handled with

proper care. To ensure years of reliable service, keep these

simple tips in mind:

• Use on a solid, level surface.

• Do not exceed the scale’s maximum capacity.

Overloading your scale can permanently damage it.

• Avoid exposure to extreme heat or cold. Scales

perform best at normal room temperature.

• Store your scale in a clean, dry location. Dust, dirt,

and moisture can accumulate on the weighing

sensors and electronics causing inaccuracy or

malfunction.

• Gently apply all items to be weighed. Do not drop

items onto the weighing platform.

• Check the batteries rst if you are having any trouble

with your scale. This simple step can remedy most

scale issues.

• Do not disassemble your scale. This product contains

no user serviceable parts.

• Do not immerse this product in water

• Clean with a soft damp cloth. Do not user chemicals

or harsh abrasives.

• Remove the battery if storing the scale for long

periods of time.

• Waste batteries should not be disposed of with

household waste. Check with your local authority for

battery and recycling advice.

UNIT /T

oz

lb

I. Part List

1. Scale

2. CR2032 Battery (x1)

II. Key Description

1. ON/OFF TARE - Press to turn the scale on or rezero

the scale. Hold to turn the scale off.

2. UNIT - Press to change weighing unit

III. Battery Installation

1. Before using the scale for the rst time, check

the battery compartment and remove any plastic

insulation strips or packaging that may be in place to

prevent battery drainage during shipping/storage.

2. If you are replacing the batteries, make sure the

positive and negative contacts are properly aligned.

UNIT Key

Positive Side

Facing Out

ON/OFF/TARE Key

CAMEO

IV. Operation

1. Place the scale on a at, level surface and tap the

ON/OFF/TARE key to turn the scale on.

2. Once the start-up process completes and the scale

goes to zero you are ready to weigh.

3. Place the quantity to be weighed onto the weighing

platform.

4. Wait a couple seconds for the display to stabilize

before taking a weight reading.

5. To turn the scale off, press and hold the ON/OFF/

TARE key.

V. Changing the Unit of Measure

1. Tap the UNIT key to change the scales displayed

weighing unit.

2. If the scale is turned off then back on, it will default

to the last unit used.

• CAMEO-5K Units: lb:oz (pound:ounce) oz.

(ounce) g (gram) ml (milliliter)

VI. Using the Tare Feature

You can use this scale’s tare feature to subtract the weight

of an empty container or vessel for net weight determination.

NOTE: The weight of the container will subtract from the

available capacity.

1. With the scale ON, place the empty container or

vessel on the weighing platform.

2. Press the ON/OFF/TARE key once. The display will

then reset to zero. If the container is removed, it’s

weight will be displayed as a negative number.

3. You may now ll the container with the quantity to be

weighed. The display will show the net weight of the

contents.

4. To return to normal weight display (gross weight),

remove any items from the weighing platform and

press the ON/OFF/TARE key again to re-zero the

scale.

VII. Troubleshooting

• Problem: Scale will not turn on

• Solution: Check the batteries

• Problem: Displayed weight uctuates randomly

• Solution: Make sure your workspace is stable and

free of any air currents or vibration

VIII. Error Codes

1. LO - The battery is running low. Please replace the

battery.

2. ERR - Maximum capacity exceeded. Remove the

extra weight to avoid damaging the load cell.

3. UNST - Scale is unstable. Use the scale in a more

stable position.

CAMEO

IX. Specications

CAMEO-5K

Max. Capacity 11lb / 17.6oz / 5000g / 5000ml

Readability 0.1oz / 0.1oz / 1g / 1ml

Power 1 x CR2032

Dimensions 6.3 x 9.0 x 0.5 in.

Display Dimensions 0.8 x 2.1 in.

Platform Dimensions 6.3 x 9.0 in.

Warranty 10 Year Limited Warranty

X. Capacity/Readability Charts

CAMEO-5K

11lb x 0.1oz

17.6oz x 0.1oz

5000g x 1g

5000ml x 1ml

American Weigh Scales, Inc.

Norcross, GA 30092

Made in China to our exact specications and quality control.
