American Weigh Scales
CHROME-1KG (1000g x 0.1g)
User Manual
CHROME
Copyright © 2010 American Weigh Scales, Inc.
All rights reserved. Rev. 1.0
CHROME Manual
Thank you for purchasing the American Weigh
CHROME digital pocket scale. Please read all operating
instructions carefully before use. Scales are precision
measuring devices and should always be handled with
proper care. To ensure years of reliable service, keep these
simple tips in mind:
• Do not exceed the scales maximum capacity.
Overloading your scale can permanently damage it!
• Avoid exposure to extreme heat or cold. Scales
perform best at normal room temperature. If
temperatures have changed dramatically, calibration
adjustment may be necessary.
• Allow your scale to warm up for 30-60 seconds before
performing calibration adjustment(if available).
• Store your scale in a clean, dry location. Dust, dirt,
and moisture can accumulate on the weighing
sensors and electronics causing inaccuracy or
malfunction.
• Avoid using your scale in close proximity to strong
radio wave emitting devices such as computers, cash
registers, and cordless phones.
• Alwaysweighonaatandlevelsurface,freefrom
vibrations and drafts. The corner of a room is usually
the most stable.
• Gently apply all items to be weighed. Do not drop
items onto the weighing platform.
• Avoid dropping your scale. The warranty does not
cover damage due to rough treatment or overload.
• Checkthebatteriesrstifyouarehavinganytrouble
with your scale. This simple step can remedy most
scale issues.
• Do not disassemble your scale. This product contains
no user serviceable parts.
I. Part List
1. Scale
2. Cover/Expansion Tray
3. AAA Batteries (x2)
II. Key Description
III. Battery Installation
1. Beforeusingthescaleforthersttime,check
the battery compartment and remove any plastic
insulation strips or packaging that may be in place to
prevent battery drainage during shipping/storage.
2. If you are replacing the batteries, make sure the
positive and negative contacts are properly aligned.
TARE UNIT PCS
g
TARE UNIT PCS
g
Tare Key
Unit Key
ON/OFF Key
Pcs. Key
CHROME Manual
IV. Operation
1. Placethescaleonaat,levelsurfaceandpressthe
key to turn the scale on.
2. Once the start-up process completes and the scale
goes to zero you are ready to weigh.
3. Place the quantity to be weighed onto the weighing
platform.
4. Wait a couple seconds for the display to stabilize
before taking a weight reading.
V. Changing the Unit of Measure
1. Press the UNIT key to change the scales displayed
unit of measure.
2. If the scale is turned off then back on, it will default
to the last unit used.
• CHROME-1KG Units: g (gram) oz (ounce)
ozt (troy ounce) ct (carat) gn (grain) dwt
(pennyweight)
VI. Using the Tare Feature
You can use this scale’s tare feature to subtract the weight
of an empty container or vessel for net weight determination.
NOTE: The weight of the container will subtract from the
available capacity.
1. Place the empty container or vessel on the weighing
platform.
2. Press the TARE key once. The display will then
reset to zero. If the container is removed, it’s weight
will be displayed as a negative number.
3. Youmaynowllthecontainerwiththequantityto
be weighed. The display will show the net weight of
the contents.
4. To return to normal weight display (gross weight),
remove any items from the weighing platform and
press the TARE key again to re-zero the scale.
VII. Using the Counting Feature
1. Press the ON/OFF key to turn the scale on.
2. Place a sample quantity of the items being weighed
on the platform. This quantity should either be 25,
50, 75, or 100 pieces.
3. Once the weight is stable, press and hold the PCS
key to enter counting mode setup.
4. The current sample size will be displayed on the
LCD (ie. “P 25”).
5. Press the MODE key to change it between 25, 50,
75, or 100 and press PCStoconrm.Thecountwill
be displayed on the LCD. You may now add more
items. As items are remove items and the count will
update automatically.
VIII. Calibration
Calibration and adjustment are performed at the factory.
However, the weighing range can shift slightly during
shipping. Also, due to changes in local acceleration of gravity
around the world, adjustment is recommended when moving
the scale from one location to another. To check calibration:
1. Place the required calibration weight on the scale
and note the displayed value.
2. If the displayed value is not within acceptable
tolerance (see chart on the next page), adjustment
is required.
CHROME Manual
Model Acceptable
Tolerance (±)
Calibration
Weight
Recommended
Accuracy Class
CHROME-1KG 0.2g 500g OIML M2
IX. Adjustment
1. While the scale is on, press and hold the UNIT key
until the display shows CAL, then release.
2. Press the UNITkeyoncemore.Thediaplywillash
“CAL” followed by “500.0g”.
3. Place a 500 gram calibration weight on the center
of the platform.
4. Thedisplaywillash“PASS”followedby“500.0g”.
Calibration is complete.
X. Troubleshooting
• Problem: Scale will not turn on
• Solution: Check the batteries
• Problem: Displayedweightuctuatesrandomly
• Solution: Make sure your workspace is stable and
free of any air currents or vibration
• Problem: Displayed weight is inaccurate
• Solution: Perform a calibration adjustment
XI. Error Codes
1. OUTZ - Zero range has shifted. Perform calibration
adjustment. If the problem persists, the load cell may
be permanently damaged due to overloading.
2. ERR2 - Maximum capacity exceeded. Remove the
extra weight to avoid damaging the load cell.
3. L - Batteries are low. Replace the batteries.
CHROME
Max. Capacity 1000g
Readability 0.1g
Power 2 x AAA Lithium
Dimensions 4.5 x 2.5 x 0.6 in.
Platform Dimensions 2.1 x 2.4 in.
Warranty 10 Year Limited Warranty
Capacity Readability
Gram 1000.0g 0.1g
Carat 5000.0ct 0.5ct
Ounce 35.27oz 0.01oz
Pennyweight 643.0dwt 0.1dwt
Grain 15430gn 2gn
Troy Ounce 32.15ozt 0.01ozt
