AWS CP5-100 Manual de usuario
American Weigh Scales, Inc.
CP5-100 (100x0.01g)
CP5-650 (65 0x0.1g) User Manual
CP5-Series
Digital Pocket Scale
M
T
Zero
g
12:10 pm
Home Router
WiFi Search
Oce
Coee Shop
Meeting Today:
- 3:00pm
Tasks
CP5-Series Manual
Thank you for purchasing the American Weigh CP5-
Series digital pocket scale. Please read all operating
instructions carefully before use. Scales are precision
instruments and should always be handled with proper
care. To ensure years of reliable service, keep these
simple tips in mind:
• Do not exceed the scales maximum capacity.
Overloading your scale can permanently damage it!
• Avoid exposure to extreme heat or cold. Scales
perform best at normal room temperature. If
temperatures have changed dramatically, recalibration
may be necessary.
• Allow your scale to warm up for 30-60 seconds
before performing calibration (if available).
• Store your scale in a clean, dry location. Dust, dirt,
and moisture can accumulate on the weighing sensors
and electronics causing innacuracy or malfunction.
• Avoid using your scale in close proximity to strong
radio wave emitting devices such as computers, cash
registers, and cordless phones.
• Always weigh on a at and level surface, free from
vibrations and drafts. The corner of a room is usually
the most stable.
• Gently apply all items to be weighed. Do not drop
items onto the weighing platform.
• Avoid dropping your scale. The warranty does not
cover damage due to rough treatment or overload.
I. Battery Installation
I. OPERATION
Place Scale on a horizontal at surface.
1. Press [
ON/OFF
] key.
2. Wait until "0.0” or "0.00" is displayed.
3. Place the object(s) on the weighing platform.
4. By pressing the [
UNITS
] key, you can switch
between weighing units.
5. By pressing the [
LIGHT
] key, you can switch the
back-light on or off.
6. The removable lid can also be used as a weighing
tray.
II. TARE WEIGHING
Install Positive
Side Up
Install Negative
Side Up
Positive Terminal
Negative Terminal
CR2032 (Button Cell) Battery Installation
+
-
+
-
1. Turn on scale as described above.
2. Place a tray or container on the scale platform.
3. Press [ TARE
] and wait until "0.0" or "0.00" is
displayed.
4. You can now add items to the container or tray to
obtain just the weight of the contents.
III. PARTS COUNTING
All object must be of equal weight for counting to work.
1. Turn on scale as described above.
2. Place a sample quantity (25, 50, 75, or 100pcs) of
the material you want to count on the platform
3. Press and hold the [ PCS
] key for 2 seconds until a
number is displayed (ie. 100pcs).
4. Press [
UNITS
] to change the sample quantity to
match the number you have on the platform.
5. Press the [ PCS
] key again to conrm the number.
6. You may now remove the sample quantity and add
any amount of the material to the platform, and the
display will show a count.
7. You can switch between weighing and counting
mode by pressing [ PCS
] or [ UNITS
] respectively.
IV. CALIBRATION
Calibration is NOT required before rst use. Only
calibrate if scale is not weighing properly.
**The CP5-650 calibrates with a 500g weight (not
included). The CP5-100 calibrates with a 100g weight
(not included)**
1. Turn the scale ON.
2. Hold the [ UNITS
] key for a few seconds. The
display will show "CAL".
3. Press the key again. "CAL" will ash, followed by
the required calibration weight (ie. 500g).
3. Place the calibration weight onto the platform.
4. The display will show "PASS" then return to normal
weighing mode. Calibration is complete!
V. TROUBLESHOOTING
[Display] Elimination of errors
-----------------------------------------------
[OUT2] Recalibrate the scale (Section IV).
[EEEE] You are overloading the scale. Remove the
excessive load immediately!
[un2T] Use the scale in a more stable position
Model CP5-650 CP5-100
Capacity 650.0g
22.92oz
20.89ozt
417.95dwt
100.00g
3.527oz
500ct
1543.2gn
Resolution 0.1g
0.01oz
0.01ozt
0.1dwt
0.01g
0.001oz
0.05ct
0.1gn
Weighing Units g, oz, ozt, dwt g, oz, ct, gn
Calibration Weight (not Included) 500g 100g
Platform Dimensions (inches) 2.0 x 2.7 “ Stainless Steel
Scale Dimensions (inches) 4.5 x 2.4 x 0.5”
Power 2 x CR2032 Batteries (included)
Warranty 10 Year Warranty
Specications
