AWS GeminiPRO Manual de usuario
American Weigh
Scales, Inc.
Mini Jewelry
Scale
20g x 0.001g
100 x 0.01ct
GeminiPRO Manual
Thank you for purchasing the American Weigh
GeminiPRO Mini Jewelry Scale. Please read all
operating instructions carefully before use. Scales are
precision instruments and should always be handled
with proper care. To ensure years of reliable service,
keep these simple tips in mind:
• Do not exceed the scales maximum capacity.
Overloading your scale can permanently damage it!
• Avoid exposure to extreme heat or cold. Scales
perform best at normal room temperature.
If temperatures have changed dramatically,
recalibration may be necessary.
• Allow your scale to warm up for 30-60 seconds
before performing calibration (if available).
• Store your scale in a clean, dry location. Dust, dirt,
and moisture can accumulate on the weighing
sensors and electronics causing innacuracy or
malfunction.
• Avoid using your scale in close proximity to strong
radio wave emitting devices such as computers, cash
registers, and cordless phones.
• Always weigh on a at and level surface, free from
vibrations and drafts. The corner of a room is usually
the most stable.
• Gently apply all items to be weighed. Do not drop
items onto the weighing platform.
• Avoid dropping your scale. The warranty does not
cover damage due to rough treatment or overload.
I. SCALE OPERATION
Place the scale on a horizontal at surface and set the scale
platform on the weighing surface.
1. Press [ ON/OFF ] key.
2. Wait until “0.000g” is displayed.
3. Place the object(s) on the weighing tray.
4. By pressing the [ MODE ] key, you can switch between
weighing units.
5. The weighing pan can be used by following the TARE
WEIGHING instructions below.
II. TARE WEIGHING
1. Turn on the scale as described above.
2. Place the included weighing pan on the scale platform.
3. Press the [ TARE ] button. “0.000g” will be displayed.
4. You can now add items to the pan to obtain just the weight
of the contents.
5. When all items are removed, a negative number will be
displayed. Press [ TARE ] again to zero the scale.
III. CALIBRATION
1. Press the [ ON/OFF ] key to turn the scale on.
2. Wait for the display to show “0.000g” then press and hold
the [ CAL ] key for 3 seconds until the display shows “CAL”
then release.
3. When the LCD ashes “10.000g”, place a 10g weight on the
middle of the platform.
4. The LCD will ash then ash “20.000g”. Place another 10g on
the center of the platform to make a total of 20g.
5. The LCD will display “PASS” and return to normal weighing
mode. Calibration is complete. You may now remove the
weights and turn o the scale.
IV. TROUBLESHOOTING
The primary reasons for inaccuracy or malfunction are low
batteries, incorrect calibration, overload or operating on an
unstable surface. Please keep this in mind and maintain and
operate your scale properly. This scale is a precise instrument
and must be handled with the utmost care and caution.
[Display] Elimination of errors
[Lo] Change the batteries.
[OUT2] Recalibrate the scale as shown above.
[O_Ld] You are overloading the scale. Remove the excessive
load immediately!
[UnSE] Use the scale in a more stable position
Model GeminiPRO
Capacity 20.000g / 12.860dwt / 100.00ct / 308.64gn
Resolution 0.001g /0.001dwt / 0.005ct / 0.02gn
Tolerance ±0.003g / 0.003dwt / 0.015ct / 0.06gn
Weighing Units g, dwt,ct, gn
Calibration Weight (not
Included) 10g and 20g
(calibrates linearly at 10g and 20g)
Platform Dimensions
(inches) 1.75” Ø
Scale Dimensions
(inches) 2.75 x 5.9 x 1.6”
Power 4 x AAA Batteries (included)
Warranty 10 Year Warranty
Specications
American Weigh Scales, Inc.
3285 Saturn Court
Norcross, GA 30092
www.awscales.com
