Antari M-11 Manual de usuario

M-11

Stage Fog Machine

User Manual

- ENGLISH

Safety Information

Please read the following safety information carefully before operating the machine.

This information includes important safeguards about installation, usage, and

maintenance. Pay attention to all warning labels and instructions in this manual and

printed on the machine.

If you have questions about how to operate the machine safely, please contact your local Antari

dealer for help.

Keep this device dry.

Always connect to a grounded circuit to avoid risk of electrocution.

Before connecting the machine to power, always check the voltaged indicate on the machine

matches to your local AC voltage. Do not use the machine if AC power voltage does not match.

Disconnect the machine from AC power before servicing and when not in use.

If the supply cord is damaged, contact your local Antari dealer for replacement.

This product is for indoor use only! Do not expose to rain or moisture. If fluid is spilled,

disconnect AC power and clean with a damp cloth. If fluid is spilled onto electronic parts,

immediately unplug the machine and contact your local Antari dealer for advice.

No user serviceable and modifiable parts inside. Never try to repair this product, an

unauthorized technician may lead the machine to damage or malfunction.

For adult use only. Children being supervised not to play with the machine. Never leave the

machine running unattended.

The machine is not to be used by persons (including children) with reduced physical, sensory

or mental capabilities, or lack of experience and knowledge.

Installed in a well ventilated area. Provide at least 50 cm space around the machine.

Never add flammable liquid of any kind to the machine.

Make sure there are no flammable materials close to the machine while operating.

Only use Antari fluid. Other fluid may lead to heater clog and malfunction.

If the machine fails to work, unplug the machine and stop operation immediately. Contact

your local Antari dealer for .

Before transporting the machine, make sure the fluid tank is completely drained.

Smoke fluid may present health risks if swallowed. Do not drink smoke fluid. Store it securely.

In case of eye contact or if fluid is swallowed immediately look for medical advice.

Unpacking and Inspection

Immediately upon receiving the machine, carefully unpack the carton, check the content to ensure

that all parts are present and have been received in good condition. If any parts appear damaged or

mishandled from shipping, notify the shipper immediately and retain the packing material for

inspection.

What is included: 1 x M-11 Stage Fogger

1 x Power Cord

1 x User Manual

Product Dimensions

Product Overview

XLR 5-Pin DMX Connector

XLR 3-Pin DMX Connector

Wireless Receiver (W-2 Wireless Remote)

Two rotary knobs (Timer / Volume)

L 674.5 mm

H 284.3 mm

W 319.8 mm

Neutrik TRUE 1 Power

Connector

Setting Up

Step 1: Place the machine on a flat surface and in a suitably large area with at least 50 cm of open

space around the machine.

Step 2: Fill the fluid tank with Antari approved fluid.

Step 3: Connect the machine to a suitably rated power supply. To determine the power requirement

for the machine refer to the label on the back of the machine.

Always connect the machine to a protected circuit and ensure it is properly grounded to

avoid risk of electrocution.

Step 4: Turn on the machine and allow it to heat up. Heat up takes approximately 13 mintues. Once

the machine has reached operating temperature, the LCD display will show “Ready To Fog”. Now the

machine is ready for operation.

Step 5: To start making fog, locate the rotary knob on the right side of control panel, and press the

rotary knob to start making fog.

Step 6: To turn off the machine, press rotary knob again button and turn Powercon to the OFF

position.

Operation

Control Panel Operation

The machine can be operated with the onboard digital control interface.

T I MER VOL UM E

HOLD 3 SECONDS

Antari M-11

Ready To Fog

Operation - Timer Mode

Rotary knob

Action

Description

Left

Press once

Activate timer mode

Right

Press second time

Deactivate timer mode

Right

Rotate

Adjust output volume

Operation –Volume Mode

Rotary knob

Action

Description

Right

Press once

Activate volume mode

Right

Press second time

Deactivate volume mode

Right

Rotate

Adjust output volume

Setting

Rotary knob

Action

Description

Left

Press and hold for 3 seconds

Enter setting menu

Left

Rotate

Scroll through menus

Left

Press

Press once to enter

Left

Rotate

Adjust for preferred value

Right

Press

Escape from menu

Control Menu

Main Menu

Level 1

Level 2

DMX

Address

001-512

Channel Mode

1/3

Link Mode

Wired/Wireless

W-DMX

Unlink

Timer

Interval

5 –200 sec

Duration

1 –200 sec

Output Level

0 –100%

Manual

Output Level

0 –100%

Priming

Start/Stop

Heater

On/Off

Information

Software Version

VX.X

Wireless Signal

●: W-DMX present

◎: No DMX present

⊙: Link to TX lost

○: Not assigned

Fluid Level

Fine/Empty

Device Hour

XX Hour

Setting

Continuous Output

On/Off

Pump Mode

Single/Dual

Wireless Remote

Pair/Unpair

Fluid Sensor

On/Off

LCD Backlight

Auto Off/Low/Normal

Keypad Sound

On/Off

Auto Start

On/Off

Factory Reset

Proceed

Language

EN/ZH

DMX Connector Pin Assignment

The machine provides both 3 and 5-pin XLR connector for DMX connection. The diagram below

indicates pin assignment information.

Function

Ground

Data-

Data+

N/A

DMX Operation

Making the DMX Connection –Connect the machine to a DMX controller or to one of the machines

in the DMX chain. The machine uses both 3-pin and 5-pin XLR connector for DMX connection, the

connector is located on the rear of the machine.

OUT IN

DMX Channel Function

1 Channel Mode

DMX Value Range

Function

Output Level

0 –4

Off

5 –255

1 –100%

3 Channel Mode

DMX Value Range

Function

Output Level

0 –4

Off

5-255

1 –100%

Heater

0-126

Off

127-255

Pump

0 –126

Single

127-255

Dual

RDM Control

The M-11 Stage Fogger is RDM enabled, allowing control system to configure, mointor and manage.

See below table for supported RDM parameters

Value

RDM Parameter ID’s

GET Allowed

SET Allowed

0x0001

DISC_UNIQUE_BRANCH

0x0002

DISC_MUTE

0x0003

DISC_UN_MUTE

0x0030

STATUS_MESSAGE

0x0050

SUPPORTED_PARAMETERS

0x0051

PARAMETER_DESCRIPTION

0x0060

DEVICE_INFO

0x0070

PRODUCT_DETAIL_ID_LIST

0x0080

DEVICE_MODEL_DESCRIPTION

0x0081

MANUFACTURER_LABEL

0x0082

DEVICE_LABEL

0x00A0

LANGUAGE_CAPABILITIES

0x00B0

LANGUAGE

0x00C0

SOFTWARE_VERSION_LABEL

0x00E0

DMX_PERSONALITY

0x00E1

DMX_PERSONALITY_DESCRIPTION

0x00F0

DMX_START_ADDRESS

0x0200

SENSOR_DEFINITION

0x0201

SENSOR_VALUE

0x0400

DEVICE_HOURS

0x1000

IDENTIFY_DEVICE

Wireless Operation

Wireless remote control system W-2 consists of a transmitter equipped with four buttons to activate,

deactivate, increase and decrease fog output and an onboard receiver attached to the rear panel of

M-11 fog machine.

W-2 Wireless Transmitter

Press [A] button to emit fog. Press [B] button to stop. Press [C] button to increase output volume. Press

[D] button to decrease output volume.

In an unobstructed open space the effective distance is 50 meters, usage depending on obstacle level

the effective distance is 10-25 meters.

Wireless Receiver

Registering a transmitter

Transmitters can be paired or deleted from the receiver. Each receiver can pair up to 5 transmitters.

Follow the steps below to pair or delete a transmitter from a receiver.

Step 1: Press and hold the left rotary knob for 3 seconds to enter setting menu.

Step 2: Rotate the rotary knob to find the “Wireless Detect” menu.

Step 3: Follow the menu instruction to pair or delete a transmitter.

Transmitter battery replacement

If the effective distance seems to decrease, it is possible the battery level is low and requires

replacement. In order to replace the battery, undo the three screws on the back of transmitter to

release the cover. Replace with the same type and specification of battery which is 27A 12V

Fluid

Only use Antari FLR/FLG water-based liquid for the M-11

Stage Fogger. The machine is tested and calibrated with this

liquid to get the best output performance. Warranty will be

voided if any other type of liquid is used, improper use of

liquid may lead to machine failure and malfunction.

Service and Maintenance

․Do not allow the machine to become contaminated.

․Remove dust from air vents with air compressor, vacuum or a soft brush.

․Only use a damp cloth to clean the casing.

․Before storing run distilled water through the system to help prevent condensing the pump or

heater.

․It is recommended to run the machine on a monthly basis in order to achieve best

performance and output condition.

․Excessive dust, liquid and dirt built up will degrade performance and cause overheating.

Breaker Reset

Disconnect AC power before resetting the breaker. Only replace fuse with same type

and rating.

Step 1: Disconnect AC power.

Step 2: Flip breaker to ON position.

Step 3: Turn on machine for testing.

Breaker

100-120V = 15A 250V

220-240V = 7A 250V

Technical Specifications

- Input voltage

- Rated power

- Warm-up time

- Fluid consumption

- Fluid tank capacity

- Compatible fluid

- Ambient temp/ range

- Control

- DMX channels

- Connection

- Optional accessories

- Dimension

- Weight

US model : AC 100-120V, 50 / 60Hz 13.3A

EU model : AC 220-240V, 50 / 60Hz 6.67A

1600 W

13 minutes (approx)

400 ml / min (100% output)

10 Liters

Antari FLG 10 Heavy Fog Fluid

Antari FLR 10 Light Fog Fluid

0℃- 40℃(32℉-104℉)

DMX 512, Timer, Manual

Wireless (Optional)

Wireless DMX (Optional)

1 or 3 channels

Neutrik TRUE1 Connector (Power)

XLR 3-pin and XLR 5-pin (DMX)

W-DMX-PCBR Wireless DMX

WTR-20 Wireless

WTR-70 Wireless DMX and Remote

L 674.5 W 319.8 H 284.3 mm

25 kg (55.1 lbs)

Otros manuales para M-11

Tabla de contenidos

Otros manuales de Máquina de niebla de Antari

Antari

Antari B-200 Manual de usuario

Antari

Antari Z Series Manual de usuario

Antari

Antari HZ-350 Manual de usuario

Antari

Antari F-80Z Guía de solución de problemas

Antari

Antari Z-Stream Manual de usuario

Antari

Antari HZ-100 Manual de usuario

Antari

Antari Z II Series Manual de usuario

Antari

Antari FT-20X Manual de usuario

Antari

Antari Z Series Manual de usuario

Antari

Antari W-508 Manual de usuario

Antari

Antari F-1 Fazer Manual de usuario

Antari

Antari S-500 Manual de usuario

Antari

Antari X FAZER Manual de usuario

Antari

Antari HZ-350 Manual de usuario

Antari

Antari SFX-1000 Manual de usuario

Antari

Antari FT-100 Fire Training Manual de usuario

Antari

Antari M-8 Manual de usuario

Antari

Antari B-100 Manual de usuario

Antari

Antari F-6 Manual de usuario

Antari

Antari X-310PRO Manual de usuario

Antari

Antari Z-1200II Manual de usuario

Antari

Antari Z-380 Manual de usuario

Antari

Antari FT-100 Fire Training Manual de usuario

Antari

Antari HZ-400 Manual de usuario

Manuales populares de Máquina de niebla de otras marcas

Boost

Boost BOOST-FOG400LED-BK Manual de usuario

Home Accents Holiday

Home Accents Holiday FM1000-ASH Manual de usuario

EuroLite

EuroLite ZEITGEIST FOG-1200 Manual de usuario

Dyna-Fog

Dyna-Fog CYCLONE ULTRA 2734 Manual de usuario

PROEL

PROEL DRAGO HEAVY PLFD150HY Manual de usuario

Sparklyn

Sparklyn Y846 Manual de usuario

Magicfx

Magicfx CO2 Gun Manual de usuario

Ibiza

Ibiza LSM500LAS Manual de usuario

Venue Lighting Effects

Venue Lighting Effects ULTRA MINI-FOGGER Manual de usuario

High End

High End F-100 Manual de usuario

Chauvet

Chauvet ARENA 2100 FLEX Manual de usuario

Beamz

Beamz F1600 Manual de usuario

Sagitter

Sagitter SG ARS900C Manual de usuario

KISANKRAFT

KISANKRAFT KK-STF-480 Manual de usuario

Orion

Orion OT-U250PP Guía

Beamz

Beamz S2500 Manual de usuario

American DJ

American DJ Dyno-Fog II Manual de usuario

JB Systems

JB Systems FX 1700 Manual de usuario
