ProBio Installation Guide 0

Safety Precautions

INSTALLATION GUIDE

ProBio

Version: 1.1

Date: September 2021

ProBio Installation Guide 1

Safety Precautions

Before installation, please read the following safety precautions for user safety and to

prevent product damage.

Do not install the device in a place subject to direct sun light, humidity, dust or

soot.

Do not place a magnet near the product. Magnetic objects such as magnet,

CRT, TV, monitor or speaker may damage the device.

Do not place the device next to heating equipment.

Do not let liquid like water, drinks or chemical leak inside the device.

Do not let children touch the device without supervision.

`Do not drop or damage the device.

Do not disassemble, repair or alter the device.

Do not use the device for any purpose other than those specified.

Clean the device often to remove dust on it. While cleaning, do not splash

water on the device but wipe it out with smooth cloth or towel.

Contact your supplier in case of any problem!

ProBio Installation Guide 2

Device Overview

Not all products have a fingerprint or card function. The real product shall prevail.

ProBio

Front View Left Side View

USB Slot

Reset Button

Fingerprint Reader &

Card Reader Area

ProBio

Touch Screen

Door Bell

Camera

ProBio Installation Guide 3

Device Overview

Both ProBio devices have the same pin diagram which is provided below.

7 Pin Cable Connectors

8 Pin Cable Connectors

Tamper Alarm Button

2 Pin Cable Connectors

4 Pin Cable Connectors

12 Pin Cable Connectors

Power

Ethernet

Power Out

Wiegand In

LED

Beep

Wiegand Out

RS485

RS232

Auxiliary In

Bell

Sensor

Button

Lock

Alarm

ProBio Installation Guide 4

Product Dimensions & Installation

Product Dimensions

Mounting the Device on the Wall

7.51 in

(190.8 mm)

3.35 in

(85 mm)

5.08 in

(129 mm)

2.4 in

(61 mm)

4.05 in

(103 mm)

1.15m

Place the mounting template sticker onto

the wall, and drill holes according to the

mounting paper.

Fix the back plate onto the wall

using wall mounting screws.

Insert the device into back plate.

Use security screws to fasten

the device to back plate.

ProBio Installation Guide 5

Power Connection

Without UPS

With UPS (Optional)

Recommended Power Supply

GND

12V DC Adaptor

12V DC

UPS

GND

12V DC

12V±10%, at least 500mA (12V /3A is standard).

To share the power with other devices, use a power supply with higher current

ratings.

ProBio Installation Guide 6

Ethernet Connection

LAN Connection

Note:

The device can be directly connected to PC by using Ethernet cable.

Ethernet Cable

Network Cable Adapter

ProBio Installation Guide 7

Direct Connection

Direct Connection

Ethernet Cable

Network Cable Adapter

ProBio Installation Guide 8

RS485 Connection

RS485 Fingerprint Reader Connection

DIP Settings

RS485 Fingerprint Reader

There are six DIP switches on the back of RS485 fingerprint reader. Switches from 1-4 are

for RS485 address, switch 5 is reserved, and switch 6 is for reducing noise on long RS485

cable.

2. If RS485 fingerprint reader is powered from the terminal, the length of wire should be less

than 100 meters or 330 ft.

3. If the cable length is more than 200 meters or 600 ft., the number 6 switch should be ON

ProBio Installation Guide 9

Lock Relay Connection

Device Not Sharing Power with the Lock

Normally Closed Lock

Notes:

1. The system supports NO LOCK and NC LOCK. For example the NO LOCK (normally

opened at power ON) is connected with 'NO1' and 'COM1' terminals, and the NC

LOCK (normally closed at power ON) is connected with 'NC1'and 'COM1' terminals.

2. When electrical lock is connected to the Access Control System, you must parallel

one FR107 diode (equipped in the package) to prevent the self-inductance EMF

from affecting the system.

Do not reverse the polarities.

COM

12V

GND

12V DC Adaptor

Sensor

GND

NC1

FR107 Diode

GND
