INSTALLATION INSTRUCTIONS

VOLT®LOW VOLTAGE LANDSCAPE LIGHTING

VOLT® Cast Brass Deck Light

ITEM: VDL-600 & VDL-6000

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

VOLT® Cast Brass Deck Light VDL-600 & VDL-6000

INSTALLATION INSTRUCTIONS

IMPORTANT: PLEASE READ BEFORE INSTALLATION

IMPORTANT SAFETY INSTRUCTIONS

813.978.3700 • [email protected] • www.voltlighting.com

This luminaire is intended for installation in accordance with local codes and the National

Electric Code (NEC). Failure to adhere to these codes and instructions may result in

serious injury, property damage and void the warranty.

These instructions do not intend to cover all variations in installation, operation

maintenance or mounting situations.

1. Make sure that the power is turned OFF before installing or servicing this luminaire.

2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M) or more from

pool, spa or fountain.

3. This luminaire is intended to be used only with a power supply (transformer) rated

maximum of 300 watts (25 AMPS) at 15 volts.

4. Wiring connections must be made with wire connectors that are suitable for outdoor

use.

5. Position the low voltage wire and wire connector so that it is located within 6 inches

(15.2 cm) from a building structure, a luminaire or tting.

6. The main low voltage cable is intended for shallow burial - less than 6 inches (152

mm).

7. If additional lengths of low voltage cable are required, please contact www.

voltlighting.com or call 1-813-978-3700.

INSTRUCTIONS PERTAINING TO A RISK OF FIRE, OR INJURY TO PERSONS

Lighted lamp is HOT!

WARNING – To reduce the risk of FIRE OR INJURY TO PERSONS.

1. Turn off/unplug and allow to cool before replacing lamp.

2. Lamp gets HOT quickly! Contact only switch/plug when turning on.

3. Do not touch the hot lens, guard or enclosure.

4. Keep lamp away from materials that may burn.

5. Do not touch lamp at any time. Use a soft cloth. Oil from skin may damage

lamp.

6. Do not operate the luminaire tting with a missing or damaged shield.

SAVE THESE INSTRUCTIONS

PACKAGE CONTENTS

813.978.3700 • [email protected] • www.voltlighting.com

A. (1) Luminaire

B. (2) Lock Screws

Product Dimensions

2”

2 1/4”

3 3/8”

Pro Technique for Hiding Lead Wire

Determine the location for the xture. Drill a hole straight

through the desired mounting location and run the lead wire

out the backside of the location so that the wires are not visible

from the front side. Use a matching trim piece and cut a groove

in the back of trim. Cover the lead wires with the matching trim

piece.

Pro Technique for Hiding Splice Connections

All xtures come with 4’ of lead wire enabling you to hide the

splice connections out of sight. If you must make a splice

connection in view, use an inline heat shrink style connection that

is less visible than traditional twist caps.

VOLT® Cast Brass Deck Light VDL-600 & VDL-6000

INSTALLATION INSTRUCTIONS

813.978.3700 • [email protected] • www.voltlighting.com

Remove Lens Assembly

Rotate the lens assembly counter

clockwise until it is stops and then

lift the lens assembly straight off.

Note: The rst time it may be

difcult because the luminaire has

a tight o-ring seal and a grease

sealant for moisture protection.

Base

Lens Assembly

Luminaire

Install Base

Attach the base onto the desired

location and secure with the lock

screws.

Note: Wall anchors are required

for certain installation conditions

e.g. Brick wall, Concrete Wall, etc.).

Mark on the wall for wall anchors

from the holes on the base.

Remove the base and drill proper

holes on the wall and then insert

the wall anchors.

Wall Anchor

Lock

Screw

Base

Wire Connections

Strip both leads from the luminaire

pigtail. Using two wire connectors

(sold separately), connect the leads

from the luminaire to the main supply

cable leads.

Luminaire

Main Supply Cable

Pigtail

Wire Connector

813.978.3700 • [email protected] • www.voltlighting.com

Install Bulb

Insert the bulb with correct wattage and

type marked on the luminaire label.

CAUTION: Do not exceed maximum

wattage marked on luminaire label.

NOTE: DO NOT touch bulb with bare

hands. Use soft cloth to handle bulb.

Bulb

Socket

Install Lens Assembly

Push the lens assembly back onto the

base aligned with the gaps on the base.

Push hard (moisture proof xture requires

force to get air out). Once the lens

assembly is ush with the base, rotate the

lens assembly until it stops and locks into

place.

Gap

Inner Shield

Install/Replace Bulb

Rotate the lens assembly and then remove it to expose the bulb and replace

it with the correct wattage and type marked on the luminaire label. And then

reinstall the lens assembly.

IMPORTANT: Halogen bulbs must be protected from moisture and dust at all

times. Always reinstall lens assembly when moved.

Specications and product details subject to change without notice.

[email protected] • www.voltlighting.com

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
