Volt VFL-4602-BBZ Manual de usuario

VOLT®Low Voltage Landscape Lighting

VOLT®Integrated LED Gentle & Big Splash

VFL-4601-BBZ & VFL-4602-BBZ

INSTALLATION INSTRUCTIONS

Specications and product details subject to change without notice.

reserved. [email protected] • 813.978.3700

- 1 -

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

VOLT®Integrated LED Gentle & Big Splash

VFL-4601-BBZ & VFL-4602-BBZ

Important: Please Read Before Installation

INSTALLATION INSTRUCTIONS

www.voltlighting.com [email protected] • 813.978.3700

Package Contents

A. (1) Fixture Body

Product Dimensions

3.25”

2.5”

1.5”

2.5”

- 2 - - 3 -

B. (1) Stake

This xture is intended for installation in accordance with local codes

and the National Electric Code (NEC). Failure to adhere to these codes

and instructions may result in serious injury, property damage and void

the warranty.

These instructions do not intend to cover all variations in installation,

operation maintenance or mounting situations.

1. Make sure that the power is turned OFF before installing or servicing

this xture.

2. Warning: this xture is not intended to be installed within 10 feet [3

meters] of a pool, spa or fountain.

3. This xture is intended to be used only with a power supply

(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.

4. Underground Low Energy Cable must not be buried over 6” (15.2 cm) in

order to connect to the main low voltage cable.

5. Wiring connections must be made with wire connectors that are suitable

for outdoor use.

6. Position the wire connector so that it is located within 6 inches (15.2

cm) from a building structure, a luminaire, or tting.

Important Safety Instructions

LIGHTED LAMP IS HOT!

WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.

1. Turn o/unplug and allow to cool before reducing lamp.

2. Lamp gets HOT quickly!

3. Do not touch the hot lens, guard or cowl.

4. Keep lamp away from materials that may burn.

5. Do not touch lamp at any time.

6. Use a soft cloth.

7. Oil from skin may damage lamp.

8. Do not operate the xture with a damaged or missing lens or shield.

Install Stake

Board

Stake

Soil

Ground

Determine your desired location for

mounting the xture. Hammer the

stake into the ground until ange

of stake is ush to grade. To avoid

damage to the stake, place a board on

top of the stake while hammering.

NOTE: If the ground is hard and the

stake is dicult to install, make a

crosscut in the ground using a at

shovel.

INSTALLATION INSTRUCTIONS

[email protected] • 813.978.3700

Adjust Fixture Body

Use the included Allen wrench to

unlock the set screw and adjust

the xture body to your desired

direction. Tighten the set screw

once your desired angle is achieved.

Fixture

Body

Allen

Wrench

Set Screw

Adjust

www.voltlighting.com

- 4 - - 5 -

Clear away an area on the ground

at the wireway slot on top of

the stake. Lay the luminaire

pigtail into the wireway slot and

thread the xture onto the stake.

Tighten using the lock nut to

secure it to the base.

Install Fixture Body to Stake

Fixture Body

Pigtail

Wireway Slot

Stake

Wire Connections

Strip both leads from the luminaire pigtail. Using two wire connectors

(sold seperately), connect the leads from the luminaire to the main

supply cable leads.

Pigtail

Main Supply Cable

Wire Connectors

Remove Glare Guard with Lens

Replace Lens

Loosen the thumb screws, then

remove the glare guard and the lens

from the xture body.

Remove the lens from the rubber

gasket, then replace it with the lens

you would like to use.

Fixture

Body

Glare

Guard

Glare

Guard

Thumb Screw

Gasket and

Lens

Replace Lens

VOLT®Integrated LED Gentle & Big Splash

VFL-4601-BBZ & VFL-4602-BBZ

www.voltlighting.com

- 6 -

[email protected] • 813.978.3700

- 7 -

INSTALLATION INSTRUCTIONS

Place the glare guard and the

gasketed lens back onto the

xture body and secure with

the thumb screws previously

removed. Hand tighten until snug.

Install Glare Guard with Lens

Fixture

Body

Glare

Guard

Thumb Screws

VOLT®Integrated LED Gentle & Big Splash

VFL-4601-BBZ & VFL-4602-BBZ

is-VFL-4601-4602-BBZ-ver2.pdf

Specications and product details subject to change without notice.

reserved. [email protected] • 813.978.3700

www.voltlighting.com

- 8 -

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
