VOLT®Low Voltage Landscape Lighting

VOLT® Path & Area Light Stem

VSM-2407 & VSM-1203

INSTALLATION INSTRUCTIONS

Specications and product details subject to change without notice.

[email protected] • 813.978.3700

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

- 1 -

VOLT®Path & Area Light Stem

VSM-2407 & VSM-1203

Important: Please Read Before Installation

Important Safety Instructions

INSTALLATION INSTRUCTIONS

This xture is intended for installation in accordance with local codes and

the National Electric Code (NEC). Failure to adhere to these codes and

instructions may result in serious injury, property damage and void the

warranty.

These instructions do not intend to cover all variations in installation,

operation maintenance or mounting situations.

1. Make sure that the power is turned OFF before installing or servicing

this xture.

2. Warning: this xture is not intended to be installed within 10 feet [3

meters] of a pool, spa or fountain.

3. This xture is intended to be used only with a power supply

(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.

4. Underground Low Energy Cable must not be buried over 6” (15.2 cm)

in order to connect to the main low voltage cable.

5. Wiring connections must be made with wire connectors that are

suitable for outdoor use.

6. Position the wire connector so that it is located within 6 inches (15.2

cm) from a building structure, a luminaire, or tting.

LIGHTED LAMP IS HOT!

WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.

1. Turn off/unplug and allow to cool before reducing lamp.

2. Lamp gets HOT quickly!

3. Do not touch the hot lens, guard or cowl.

4. Keep lamp away from materials that may burn.

5. Do not touch lamp at any time.

6. Use a soft cloth.

7. Oil from skin may damage lamp.

8. Do not operate the xture with a damaged or missing lens or shield.

www.voltlighting.com

- 2 -

Package Contents

Product Dimensions

A. (1) Stem

[email protected] • 813.978.3700

2.5”

9”

- 3 -

22.5”

Parts Required (sold separatly)

A. (1) Hat

B. (1) Bulb

C. Stake

Max Spread Hat Pictured Here

www.voltlighting.com

INSTALLATION INSTRUCTIONS

Remove Stem Top

Loosen the stem top and remove

it from the stem.

Stem Top

Stem

- 4 -

Install Bulb

Insert the bulb with correct wattage

and type marked on the xture label

and push rmly into place.

CAUTION: Do not exceed

maximum wattage marked on

luminaire label.

Socket

Bulb

Place the stem top over the

bulb and thread the stem top

onto the stem. Hand tighten

until snug.

Install Stem Top

Stem Top

Stem

VOLT®Path & Area Light Stem

VSM-2407 & VSM-1203

[email protected] • 813.978.3700

- 5 -

Install Stake

Determine the desired location for

mounting the xture. Hammer the

stake into the ground until the ange

of the stake is ush to grade. To avoid

damage to the stake, place a board

on top of the stake while hammering.

NOTE: If the ground is hard and the

stake is difcult to install, make a

crosscut in the ground using a at

shovel.

Board

Stake

Soil

Ground

Clear away an area in the ground

at the wireway slot on the top

of the stake. Lay the luminaire

pigtail into the wireway slot and

attach the stem onto the stake.

Tighten until snug.

Install Stem to Stake

Stem

Stake

Pigtail

Wireway Slot

INSTALLATION INSTRUCTIONS

www.voltlighting.com

- 6 -

Wire Connection

Strip both leads from the luminaire pigtail. Using two wire connectors

(sold separately), connect the leads from the luminaire to the main

supply cable leads.

Pigtail

Main Supply Cable

Wire Connectors

Install Hat

Place the hat of your choice onto

the stem top and secure it with

the nial. Hand tighten until snug.

Shield

Finial

Hat of your choice

Install/Replace Bulb

Remove the nial, hat and stem top to expose the bulb. Replace it

with the correct wattage and type marked on the xture label. Then,

reinstall the stem top and hat.

IMPORTANT: Bulbs must be protected from moisture and dust at all

times. Always reinstall the stem top and hat when removed.

VOLT®Path & Area Light Stem

VSM-2407 & VSM-1203

[email protected] • 813.978.3700

- 7 -

IS-VSM-2407/1203-ver1.pdf

Specications and product details subject to change without notice.

[email protected] • 813.978.3700

www.voltlighting.com

Help Hotline:

1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

- 8 -
