Vicon Roughneck AI V2008B-W310LPR Manual de usuario

Quick Guide

Roughneck AI V2008B-W310LPR and V2008B-W818LPR

License Plate Recognition Outdoor Vandal Bullet Camera

XX324-20-02

Cybersecurity Notification: All network connected devices should use best practices for

accessing the device. To that end, these network cameras do not have a default password. A user defined

password with minimum password strength requirements must be set to access the device. See page 15of

this Quick Guide for set-up instructions.

Be sure to check Vicon’s website to be see if you have the most up-to-date camera firmware.

Vicon Industries Inc. does not warrant that the functions contained in this equipment will

meet your requirements or that the operation will be entirely error free or perform precisely as

described in the documentation. This system has not been designed to be used in

life-critical situations and must not be used for this purpose.

Document Number: 8009-8324-20-02 Product specifications subject to change without notice.

Vicon Industries Inc.

Tel: 631-952-2288) Fax: 631-951-2288

Toll Free: 800-645-9116

24-H o ur Te chnical Support: 800-34-VICON

(800-348-4266)

UK: 44/(0) 1489-566300

www.vicon-security.com

Link to Setup Guide

V2008B-LPR Series Quick Guide

Table of Contents

1Product Overview 4

1.1 Physical Characteristics 4

2Installation and Connection 7

2.1 Package Contents 7

2.2 Installation 7

2.2.1 Checking Appearance 7

2.2.2 LPR Installation Guidelines 7

2.2.3 Mounting Preparation 9

2.2.4 Mounting the Camera 9

2.2.5 Connecting the Cables 11

2.2.6 Adjusting the Camera Position 11

2.2.7 Adjusting the Protection Shield Hood 13

3Connection 14

3.1 Network 14

3.2 System Requirements 14

3.3 Connecting Process 15

3.3.1 Accessing the Camera 15

3.3.2 Connecting from a computer 15

3.4 PRONTO Device Manager 16

V2008B-LPR Series Quick Guide

WARNING

This camera operates at 12 VDC/24 VAC/PoE+ (IEEE 802.3at Class 4).

Installation and service should be performed only by qualified and experienced technicians and comply

with all local codes and rules to maintain your warranty.

We are NOT liable of any damage arising either directly or indirectly from inappropriate installation which

is not depicted within this documentation.

To reduce the risk of fire or electric shock, do not expose the product to rain or moisture.

Wipe the camera with a dry soft cloth. For tough stains, slightly apply diluted neutral detergent and wipe

with a dry soft cloth.

Do not apply benzene or thinner to the camera, which may cause the surface to melt or lens fog.

Avoid aligning the lens with extremely bright objects (e.g., light fixtures) for long periods of time.

Although this camera is waterproof and suitable for both indoor and outdoor usages, please do not

immerse the camera into water.

Avoid operating or storing the camera in the following locations:

Extremely humid, dusty, or hot/cold environments (recommended operating temperature:

-40°F to +140°F/-40°C to +60°C)

Close to sources of powerful radio or TV transmitters

Close to fluorescent lamps or objects with reflections

Under unstable or flickering light sources

Get Started

This quick guide is designed as a reference for installation of the camera. For additional information on the

camera’s features, functions, and detailed explanation of the web interface controls, refer to User’s Manual for

details. Please read this quick guide thoroughly and save it for future use before attempting to install the

camera. From this guide you will get:

Product Overview: The physical parts, features and dimensions of the camera.

Installation and Connection: The instructions on installation and wire connection for the camera.

WEEE (Waste Electrical and Electronic Equipment). Correct disposal of this product

(applicable in the European Union and other European countries with separate collection

systems). This product should be disposed of, at the end of its useful life, as per applicable

local laws, regulations, and procedures.

V2008B-LPR Series Quick Guide

FCC Compliance Statement

Information to the user: This unit has been tested and found to comply with the limits for a Class

B digital device pursuant to Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired operation. These

limits are designed to provide reasonable protection against harmful interference in a residential installation.

This unit generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance

with the manual, may cause harmful interference to radio communications. However, there is no guarantee

that interference will not occur in a particular installation.

If this unit does cause harmful interference to radio or television reception, which can be determined by

turning the unit off and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the unit and receiver.

Connect the unit to an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Caution Changes or modifications not expressly approved by the party responsible for compliance

could void the user’s authority to operate the unit.

CE Statement

Operation is subject to the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received, including interference

that may cause undesired operation. The manufacturer declares that the unit supplied with this

guide is compliant with the essential protection requirements of EMC directive and General Product Safety

Directive GPSD conforming to requirements of standards EN55022 for emission, EN 50130-4 for immunity,

EN 300 and EN 328 for WIFI.

This product is IP67 rated for outdoor environments and IK10 rate for impact protection. The camera also

meets regulations required to be NDAA, GSA schedule and TAA approved.

V2008B-LPR Series Quick Guide

1Product Overview

1.1 Physical Characteristics

Figure 1 - 1: Physical Dimension

Figure 1 - 2: Parts Pictorial Index

Unit: mm (in.)

V2008B-LPR Series Quick Guide

Name

Description

1 RJ-45 Ethernet/PoE Port

Connect an Ethernet cable terminated with RJ-45 connector to

the PoE RJ-45 port for both power supply and network

connectivity purposes simultaneously.

2 12 VDC or 24 VAC Port

Power the camera via a 12 VDC or 24 VAC power source. Pay

attention to the polarities when connecting to 12 VDC power

supply.

3 DI/DO Port

DI/DO (Digital Input/Output) ports are equipped for external

devices, e.g., smoke detector, siren, microphone.



Audio In: connect to external device like microphone

that receives sound for camera.



Audio Out: connect to device like speaker to transmit

sound for camera.



Alarm In: connect to external device that can trigger

alarm input signals.



Alarm Out: connect to external device to be triggered

through alarm output signals.

4 Mounting Bracket

Mount the camera onto surface. The mounting bracket is

designed with 3 axes for flexible adjustment.

5 Protection Shield Hood For minimizing the effects from rain and sunlight on image

quality.

6 Internal Interface Cover

Use a cross screwdriver to loosen the 2 screws and open the

cover so that the internal interfaces, including “RESET”,

“DEFAULT” button, “Micro SD Card Slot”, etc., are uncovered.

More details are described on the following table and figure.

Table 1 - 1: Parts Pictorial Index Description

Color Name

Red 12 VDC (+)/24 VAC (~)

Black 12 VDC (-)/24 VAC (~)

Purple Audio Out (+)

Green Audio Out (-)

Yellow Audio In (+)

Orange Audio In (-)

Brown Alarm Out (Signal)

Blue Alarm Out (COM)

Red Alarm In (Signal)

Black Alarm In (GND)

Table 1 - 2: Wire Color Code Chart

V2008B-LPR Series Quick Guide

Figure 1 - 3: Internal Interface Pictorial Index

No.

Interface

Description

1 Micro SD Card Slot Insert a micro SD card (supplied) into the slot for recording and file

storage.

2 Reset Button Press the button for 1 second to reboot the camera.

3 Default Button

Press the button for 6 seconds to restore camera’s settings to factory

default settings.

4 Status LED Solid Red

Indicates

boot up

is running. After 2 ~ 3 seconds:

- Solid Red to Flashing Green if boot up is

normal.

- Remains Solid Red if an error occurs.

- Turns off 3 minutes after a successful boot.

Flashing Amber

Indicates firmware upgrade is running.

5 Safety Wire

The safety lanyard is used to prevent the access cover from falling. Be

sure to store the safety wire inside the camera before locking the

access cover to ensure that the camera remains waterproof.

Table 1 - 3: Internal Interface Pictorial Description

V2008B-LPR Series Quick Guide

2Installation and Connection

2.1 Package Contents

Check if all items listed below are included in the packing box.

1. LPR Bullet Camera * 1

2. Plastic Anchor * 6

3. Self-tapping Screw (T10) * 6

4. T10 Security Torx Bit * 1

5. Mounting Template * 1

6. SD Card * 1

2.2 Installation

The following tools might help you complete the installation:

Drill

Screwdrivers

Wire cutters

2.2.1 Checking Appearance

When unpacking, check to see if there is any visible damage to the appearance of the camera and its

accessories. The protective materials used for the packaging should protect the camera from most accidents

during shipment. Remove the protective materials from the camera after every item is properly checked in

accordance with the list in Package Contents.

2.2.2 LPR Installation Guidelines

When used to capture license plates, in order to obtain the maximum recognition rate, the LPR camera must

be installed properly to capture license plate images that meet the required quality. There are three (3)

aspects that must be taken into account when installing the LPR camera: minimum size of the plate, scene

lighting and camera angle. This section will outline how the camera must be installed and what the most

common mistakes are.

Installation Requirements

License Plate Size: On the image, the characters on the license plate should have an average height

between 20 and 70 pixels, with 25 pixels being a good reference value. While the software will

recognize letters of 10 pixels in height, there are certain characters in some countries that would be

difficult to discern at this size; the camera sensitivity also affects the ability to read characters of this

size. This should be taken into account when setting up the detection range.

V2008B-LPR Series Quick Guide

Camera Position

The recommended vertical angle is about 20°. The maximum recommended value is 35°. The

recommended horizontal angle is about 20°. The maximum recommended value is 35°. In a two-lane

situation, the angle between the plates and the X axis of the scene must be less than 25°.

Vertical Horizontal Angle between Plates

The suggested installation height is 3.3 – 9.8 ft (1 - 3 m). The suggested installation distance is

6.6 – 19.7 ft (2 - 6 m) for the 3.6-10 mm lens or 16 – 36 ft (5 – 11 m) for the 8-18 mm lens.

Refer to the Vicon LPR Camera Setup and Integration Guide for details on setting up the proper field-of-view

(FOV). On the Live screen on the camera interface, the Calibration pattern can be enabled; calibration lines

are shown at 20 pixels. Verify that license plates are at or above 20 pixels for optimal reading. Adjust FOV

from the main camera page.

V2008B-LPR Series Quick Guide

2.2.3 Mounting Preparation

Insert the SD card into the slot.

Refer to Figure 1-3. The SD card then has to be recognized and formatted in the camera’s GUI, Event

Setting, SD Card tab. Refer to the LPR Camera Setup Guide for details.

Use the guide pattern to mark out and prepare a mounting area.

1. Place the supplied guide pattern (template) on a mounting surface. Drill 6 mm (0.25”) outer holes x 6

at the mounting surface corresponding to the 6 indicated positions for plastic anchors.

2. Then hammer the 6 plastic anchors into the 6 drilled holes on the mounting surface.

Figure 2 - 1: Guide Pattern

2.2.4 Mounting the Camera

1. There are two ways to connect the wires, depending on your application. Pass all cables that exit from the

mounting bracket through the hole of mounting surface (Figure 2-2, Type I) or place them by the side hole of

the mounting bracket (Figure 2-3, Type II), as illustrated by the following figures.

Figure 2 - 2: Connecting the Wires Type I - Bracket Side Hole

This section is the preserved

area for cable entry space.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara de seguridad de Vicon

Vicon

Vicon Surveyor 282-00-02 Series Manual de usuario

Vicon

Vicon surveyor 2000 XX004 Instrucciones de funcionamiento

Vicon

Vicon V960-N Series Manual de instrucciones

Vicon

Vicon Cruiser SN660V Instrucciones de funcionamiento

Vicon

Vicon 240-60 Series Manual de usuario

Vicon

Vicon VN-755IPV4 Manual de usuario

Vicon

Vicon Surveyor MKII Series XX282-00-01 Manual de usuario

Vicon

Vicon V661-N-1 Series Instrucciones de funcionamiento

Vicon

Vicon VC-600W Manual de usuario

Vicon

Vicon V960D Series Manual de usuario

Vicon

Vicon V1020-WIR-180 Manual de usuario

Vicon

Vicon V962B-IR922M Manual de usuario

Vicon

Vicon SurveyorVFT SVFT-UPM-1 Manual de usuario

Vicon

Vicon CRUISER S660V Instrucciones de funcionamiento

Vicon

Vicon Cruiser SN663V-B-EX Instrucciones de funcionamiento

Vicon

Vicon Roughneck Pro V2000 Series Manual de usuario

Vicon

Vicon SVFT-C22 Manual de usuario

Vicon

Vicon Roughneck V920D Series Manual

Vicon

Vicon VC466-DSP Manual de usuario

Vicon

Vicon V905-CUBE Manual de usuario

Vicon

Vicon Roughneck V920D Series Instrucciones de instalación y funcionamiento

Vicon

Vicon Roughneck AI V2000D Series Manual de usuario

Vicon

Vicon V682-PTZ Manual de usuario

Vicon

Vicon I-Onyx VN-957DN Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Samsung

Samsung SCV-3082 Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario

Lumens

Lumens VC-A50PNW Manual de usuario
