StarTech.com ET90110SC Manual del sistema

10/100 Mbps RJ45 to Multimode SC Fiber Media Converter

StarTech ID: ET90110SC

StarTech.com’s high-speed ET90110SC media converters are engineered to make fiber connections simple

and reliable for even the most demanding network specialists. StarTech.com’s ET90110SC is

the perfect solution for connecting buildings to main networks.<br />

<br />

Easy to set up and install in a matter of seconds. This reliable and compact fiber optic media converter

features a heavy-duty power supply to withstand the most challenging environments. It has 6

LED indicators to ensure its continuous operation.<br />

<br />

ET90110SC easily converts between 10 Base-T or 100 Base-TX electrical Ethernet signals and

100 Base-FX optical Ethernet signals. While supporting a maximum multimode fiber optic cable

distance of 2km, it allows full wire speed of 148,800 packet per second throughput that prevents bottlenecks

and keeps your data flowing quickly and smoothly.<br />

<br />

Guaranteed compatibility with 3COM, Cisco, Lucent and Nortel networks and fully complies with

the IEEE 802.3 and 802.3u standard.

Features

> Automatically detects 10 or 100 Mbps network connection speed

> Complete set of 6 LED indicators continuously show operating status

> Compliant with IEEE 802.3u standard and guaranteed compatibility with 3Com, Cisco, Lucent,

and Nortel networks

> Easy installation and setup in seconds

> Full wire speed of 148,800 packet per second throughput prevents bottlenecks

> Heavy-Duty power supply which is engineered to withstand the most challenging conditions and

environments

> It’s compact design and weight makes it portable and unobtrusive to carry

> Standard RJ-45 connectors for connecting to UTP media, and SC connector for connecting to

fiber media

> Supports a maximum multimode fiber optic cable distance of 2 kilometers

> Supports Half-Duplex and Full-Duplex operating modes up to 200 Mbps

> Supports IEEE 802.3 10Base-T, 802.3u 100Base-TX and 100Base-FX industry standards

Specifications

> Color Beige

> Fiber Operating Mode Half/Full-Duplex

> Industry Standards IEEE 802.3u 100Base-FX

> Industry Standards IEEE 802.3u 100Base-TX

> Input Voltage 115 AC

> Interface A 1 - RJ45 Female

> Interface B 2 - SC Female

> LED Indicators 1 - Power

> LED Indicators 1 - Fiber Mode

> LED Indicators 1 - Fiber Link

> LED Indicators 1 - Ethernet Link

> LED Indicators 1 - LAN Mode

> Data Throughput 10/100 Mbps

> Max Transfer Distance 2 KM

> Operating Temperature 0 ~ 70 Celsius

> Output Current 1000 mA

> Output Voltage 9 DC

> Center Tip Polarity Positive

> Carton Quantity 12

> Wave Length 1300nm

> Shipping (Package) Weight 2.03 lb [0.92 kg]
